- Page 1 POWER STATION FOR V-LOCK AND 3-STUD LITHIUM ION BATTERIES ONLY Models PWS-RUGGED MINI PWS-RUGGED MINI 3S OPERATING INSTRUCTIONS Revision 1.0 www.blueshape.net Printed in Malta 2019...
- Page 2 With the high output power capability of the PWS-RUGGED MINI, it is expected and very normal that the internal electronics generate some heat and the internal temperature rises to a controlled extent.
- Page 3 Package contents PWS RUGGED MINI Power Station Power cable (according to region) Operating manual The unit IS resistant to IP 65* standard but IS NOT being declared as waterproof and not intended for usage in submerged in water conditions or heavy direct rainfall Explanation of IP65 (Ingress protection rating) First digit Second digit...
- Page 4 PWS-RUGGED MINI graphic description – exterior Watertight 2-step latches Swiveling and ergonomic handle 14V outlet (max 170W) over a 4 pin XLR socket, protected with a rubber cap 28V outlet (max 260W) over a 3 pin XLR socket, protected with...
- Page 5 12. LED Display showing the actual current output delivered by each battery. 3 LEDs demonstrate a 0~10A scale 13. Battery bay #1 and bay #2 * *Note: V-Lock adapter plates are installed on PWS-RUGGED MINI 3-Stud adapter plates are installed on PWS-RUGGED MINI 3S...
- Page 6 The BLUESHAPE Power Station concept is a convenient system to integrate the power of multiple V-lock batteries into a unique source that can be tapped anywhere, anytime as a simultaneous dual DC voltage output. Moreover, the PWS-RUGGED MINI doubles up as a powerful battery...
- Page 7 If a battery becomes empty or goes in an overload state, that battery is excluded from the total output (the user is notified on the display) We strongly suggest the usage of BLUESHAPE HD and HDplus batteries because of their high current draw capabilities.
- Page 8 Accurate LED display obtained by the direct dialogue between unit and the batteries (BLUESHAPE batteries only) Data communication outlet (useful for firmware upgrades/ testing and calibration purposes at factory or even for future...
- Page 9 Interpretation of the LED display Two arrays of 3 LEDs each are used to indicate the level of current delivered instantaneously by each battery, giving the user the indication of the load each battery is withstanding: 2 green LEDs (L1, L2) 1 red LED (L3).
- Page 10 Usage with BLUESHAPE batteries PWS-RUGGED MINI Recommendations Recommended 1 = least BATTERY MODEL Capacity (Wh) Max. Discharge (A) 5 = most BV095 Mini 65Wh BV090 90Wh BV100HDplus 100Wh BV140 Mini 140Wh BV150 150Wh BV180 180Wh ...
- Page 11 28V / 48V Accessories A number of cable accessories are available for connecting the PWS-RUGGED MINI with the most popular cameras on the market. Examples: PWC33: XLR 3 pole to XLR 3 pole PWC34: XLR 3 pole to XLR 4 pole PWC44: XLR 4 pole to XLR 4 pole PWCAL: XLR 3 pole to Fisher 2 pole for ARRI...
-
Page 12: Technical Specifications
Technical specifications: Parameter Value Charging section 2 x 16.7V/65W charging units Charging type simultaneous 110V to 240V , 50/60Hz Power Source Uninterruptable by battery hot swapping Output Voltage #1 48V (selectable) +/- 3% on no load Outlet [external] 1 x 3pin female XLR Maximum output #1 280W Output Voltage #2... - Page 13 This page has been intentionally left blank...
- Page 14 This page has been intentionally left blank...
- Page 15 This page has been intentionally left blank...
-
Page 16: Warranty
Warranty BLUESHAPE Power Stations are warranted to be free from defects in materials, workmanship and functionality for a period of 18 months commencing from the date of purchase. This warranty shall not apply to any products or parts of, that have been subjected to misuse, negligence, accidental or abnormal conditions of operation.
