Summary of Contents for Hanchen GFK-160A
- Page 1 GFK-160A Liquid Filling Machine 5-3500ml Contact us Hanchen Instrument Email：servicewang2015@hotmail.com WhatsApp: +86 13735844757 Tel：+86 13735844757...
- Page 2 *Please DO NOT use this GFK-160A liquid filling machine to fill liquid with particles, such as juice with pulp, or particles will block the diaphragm pump inside.
-
Page 3: Table Of Contents
Content Machine Introduction ................4 Parameters ..................... 4 Feature ....................4 Panel Introduction ................. 5 Installation ..................... 5 Operation ....................6 1. Test out the setting you should set..........6 2. Set parameters................6 4. Start filling..................7 Troubleshooting .................. -
Page 4: Machine Introduction
Machine Introduction GFK-160A liquid filling machine belongs to electric pump filling machine category, that it is mainly composed of a microcomputer and diaphragm pump. Its working principle is simple that the microcomputer controls the running speed and running time of diaphragm pump so that it can achieve quantitative filling results. -
Page 5: Panel Introduction
Panel Introduction Installation ① Remove the black plastic filling nozzle from tube, and pass the filling nozzle through the hole of one rod ( this rod has a bigger hole compared with another one), please pay attention to the arrow on the black filling nozzle that it represents the direction of water flow that it should be point down. -
Page 6: Operation
Operation 1. Test out the setting you should set. Recommended measuring tool: measuring cup or scale. Speed and Volume (Only for reference, different motors on different GFK-160A liquid filling machines have different rotating speed) Test liquid: water Speed(S.P) Volume(per second) unit: ml Speed(S.P) -
Page 7: Start Filling
3. Selecting data group from 0-6. I. When editing group “0”, the cursor will automatically appear. II. When editing group “1-6”, please press to choose the group you want, and then long press for about 3 seconds until there is a beep, and cursor will appear on the screen. -
Page 8: Maintenance And Cleaning Advice
Whatever speed I set, the 1. Speed controller 1. Open the machine and actual speed is the same disconnected connect the wires. 2. Speed controller 2. Replace speed broken controller. LED screen will not light 1. Power cord 1. Connect the adapter. connected.
