R
R90
Manual 1.6 en

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R90 and is the answer not in the manual?

Questions and answers

Related Manuals for d&b audiotechnik R90

Summary of Contents for d&b audiotechnik R90

  • Page 1 Manual 1.6 en...
  • Page 2 General information R90 Manual Version: 1.6 en, 02/2022, D2403.EN .01 Copyright © 2022 by d&b audiotechnik GmbH & Co. KG; all rights reserved. Keep this document with the product or in a safe place so that it is available for future reference.

  • Page 3: Table Of Contents

    Contents Contents R90 Touchscreen remote control........4 1.1 Scope of supply................4 1.2 Intended use................4 1.3 Technical specifications.............. 4 R90 Hardware..............5 2.1 Power supply................5 2.2 Fitting the power supply cable........... 5 2.3 LAN .................... 6 2.4 USB....................6 2.5 Ground connection..............

  • Page 4: R90 Touchscreen Remote Control

    D2403.EN .01 R90 Manual 1.2 Intended use The R90 Touchscreen remote control is a dedicated solution to control any d&b audio installation. It is intended as an additional remote control device to recall presets and scenes and provide quick access to basic functions, such as global power, mute, level, and grouping, without using the d&b R1 Remote control software.

  • Page 5: R90 Hardware

    2.1 Power supply To operate the R90, an exernal 24 VDC power supply capable of delivering a minimum of 12 W (500 mA) is required. To supply power to the device, use the power socket [X101].

  • Page 6: Lan

    When connecting cables to the device, please observe the following order: 1. Disconnect all devices involved from their power supplies. 2. Connect all cables to the R90 and to the devices to be connected. 3. Ensure that all screw connections between connectors and sockets are tight.

  • Page 7: R90 Software

    R90 Software R90 Software 3.1 Software Terms of Use The software installed on the R90 shall only be used to the extent intended/documented. d&b shall not be liable for any damage resulting from any other or non-conforming use. You may not decompile, copy, alter, or enhance the software installed on the R90 or its source code in any form.

  • Page 8: Settings

    R90 Software 3.3 Settings 3.3.1 Login Once the device has booted, selecting «Settings» on the bottom right of the touchscreen opens the R90 login screen. By factory default, the login data is: User name: Admin Password: Admin Select and hold the «View» button to show the entered password for verification.
  • Page 9 PIN (one to eight numbers). ↳ If the PIN input field is left empty, the PIN function is disabled. Screen locking settings "Auto-locking" To see the PIN in plain text, select and hold the «View» button. d&b R90 Manual 1.6 en...

  • Page 10: Project Setup

    1. Select an empty field within the «IP Address» column. 2. Enter the corresponding IP address. 3. Repeat Step 1 & 2 for all devices to be added. 4. Select «Read device data» to detect the device type(s) automatically. Device setup d&b R90 Manual 1.6 en...
  • Page 11 R90 Software AmpPresets Before presets can be set on the R90, they must first be created in R1 or on the device. For more information on how to create presets, see the device manual, which can be downloaded from the related product page at www.dbaudio.com.
  • Page 12 3. In the list, you can choose saved presets of the selected devices or scenes of the matrix devices (e.g. DS100) to assign them to the R90 presets of the selected column. Assign presets 4. Select «Apply» to save your settings.

  • Page 13: System Time And Date

    Load and save a project 1. Place the project folder in the root folder of your USB drive. 2. Plug in your USB drive to the R90. 3. Select «Scan» ↳ The «Load Project» dialog updates and lists all available projects.

  • Page 14: R90 Web Remote Interface

    In addition, the R90 provides an integrated Web Remote interface which allows full access to the device using a standard web browser. Provided the IP settings of the R90 are set in System config Þ «Network settings», to access the R90 via web remote, please proceed as follows: 1.

  • Page 15: R90 Log

    R90 Log R90 Log The log window displays two different types of information: ▪ System messages triggered by R90. ▪ Messages triggered by connected devices. When a new system or amp message appears, a red circle with an exclamation mark is added to the log button on the menu bar.
  • Page 17 www.dbaudio.com...
