Alvin BPR026 Set-Up & Usage Instructions

Parts Included:
A
2pcs Side
Frame, Left
and Right
Assembly Instructions:
Identify left and right side frames ( A ) by the single hole
1
at the top of each tube. These holes should face out.
Connect side frames together using back crossbar ( B )
and four Allen bolts ( I ) as shown in Figure 1. Keep bolts
slightly loose for now.
Hole
faces
out
B
I
x4
J
Figure 1
With caster holes facing down, slide front U
2
frame ( C ) most of the way into side frame tubes
as shown in Figure 2. Insert hex bolts ( L ) and
tighten gently with wrench ( M ) . The final position
of the front U frame will be adjusted later.
C
L
x2
Figure 2
Mobile Pivot Rack
Set-Up & Usage Instructions
B
1pc Back
Crossbar
C
1pc Front
U Frame
A
Right
A
Left
Caster
Hole
M
E
12pcs Pivot
Bracket
D
1pc Back
Frame
H
4pcs
Foot Glides
J
1pc Allen
Wrench
Turn entire assembly upside down on a carpet or other
3
scratch-free surface. Insert wheels ( G ) as shown in
Figure 3. Be sure each wheel is fully seated. If non-mobile
application is desired, install footglides ( H ) instead of
wheels. Return assembly to upright position.
Figure 3
F
2pcs
Adjustment
Knob
I
4pcs
Allen Bolt
K L
12pcs 2pcs
Springs Hex Bolts
D
With back panel oriented as
4
shown in Figure 4, slide back
frame ( D ) into side frame
tubes. Using a set of holes
somewhere in the middle,
insert adjustment knobs ( F )
F
and tighten gently. Final height
adjustment will be made later.
x2
Figure 4
For model BPR026
G
4pcs
Wheels
M
1pc Hex
Wrench
G
x4
