Power Box
DR-ID 1200PB
Operation Manual
2nd Edition : April 2016
897N120972A
This Operation Manual describes details on how to operate the power box
DR-ID 1200PB and cautions to be observed when operating it.
Please read the Operation Manual, System Operation Manual and other manuals
for the related products before actually operating the power box.
After reading this manual, store it nearby the power box so that you can see
it whenever necessary.
For Safe Operation
System
Configuration
(Product Overview)
Basic Operation
Daily Inspection and
Maintenance
Appendix
Maintenance and
Inspection

Advertisement

Table of Contents
loading

Related Manuals for FujiFilm DR-ID 1200PB

Summary of Contents for FujiFilm DR-ID 1200PB

  • Page 1 Inspection This Operation Manual describes details on how to operate the power box DR-ID 1200PB and cautions to be observed when operating it. Please read the Operation Manual, System Operation Manual and other manuals for the related products before actually operating the power box.
  • Page 2 897N120972A DR-ID 1200PB Operation Manual...
  • Page 3 Introduction The power box DR-ID 1200PB is a device which supplies power to the flat panel sensor and connects between the flat panel sensor, image processing unit and control cabinet. The power box DR-ID 1200PB is an optional item of DR-ID 1200.
  • Page 4 897N120972A DR-ID 1200PB Operation Manual...

  • Page 5: Table Of Contents

    Changing the Direction of the Flat Panel Sensor Connector ........3-2 3.1.4 Checking the Connection between the Flat Panel Sensor and the Connector ..3-2 Starting Up and Shutting Down the DR-ID 1200PB ..........3-2 3.2.1 Starting Up the DR-ID 1200PB ................3-2 3.2.2...
  • Page 6 897N120972A DR-ID 1200PB Operation Manual...

  • Page 7: Chapter 1 For Safe Operation

    For Safe Operation Chapter 1 1.1 Safety Before using the DR-ID 1200PB, read this section thoroughly to ensure that you use the product properly. Electric Shock Warnings and Cautions WARNING The power supply to this device is AC100 to 240V.
  • Page 8 Because this equipment is not explosion-proof, do not use combustible and explosive gases near the equipment. WARNING Flammable gasses may stay in the room after disinfection. If you turn the system on just after disinfection, ensure that the room is well ventilated before powering on the system. 897N120972A DR-ID 1200PB Operation Manual...
  • Page 9 If any of the following occurs, immediately turn off the power of each unit, unplug the power cable from the outlet, and then contact our official dealer or FUJIFILM Representative. ● When smoke, strange odor, or abnormal sound is present.
  • Page 10 After connecting this system to the network with other systems,confirm that the other systems are not affected. If they are affected, take countermeasures such as network separation. CAUTIONS If the length of the network cable to be used is 2m or more, be sure to use a HUB. 897N120972A DR-ID 1200PB Operation Manual...
  • Page 11 System Isolation Instructions WARNING To ensure complete system isolation, never install any unauthorized items. When it is necessary to install authorized optional items, contact our official dealer or FUJIFILM Representative. WARNING Keep the products other than those used for patients out of their reach to ensure appropriate system isolation.
  • Page 12 CAUTIONS Install the system in accordance with what is provided by IEC 60601-1:2005 + A1:2012 Chapter 16. Contact our official dealer or FUJIFILM Representative for installation (except the flat panel sensor) of the system. CAUTIONS Do not hit or drop the equipment. Otherwise, injury or damage to images, etc. may result.

  • Page 13: Chapter 2 System Configuration (Product Overview)

    *1 For detail specification of image processing unit, please refer to “DR-ID 300CL Operation Manual”. *2 The length of the network cable to be used between the DR-ID 1200PB and the DR-ID 1200MC is 2 meters. When the distance between the DR-ID 1200PB and the DR-ID 1200MC is 2 meters or longer, install a commercially available HUB.

  • Page 14: Unit Names And The Functions

    LAN cable supplied with this product to a HUB, and connect an additional LAN cable via the HUB. 2.3 Locations of Labels and Signs Locations of labels and signs affixed to the DR-ID 1200PB, and the relevant safety signs are shown below. 2.3.1 Locations of Labels DR-ID 1200PB Rating Label...

  • Page 15: Safety And Other Symbols

    EEE. At the same time, your cooperation in the correct disposal of this product will contribute to the effective usage of natural resources. For more information about waste, please contact our official dealer or FUJIFILM Representative. Year of manufacture Refer to Instruction Manual/Booklet 2.3.3 Symboles de sécurité...
  • Page 16 897N120972A DR-ID 1200PB Operation Manual...

  • Page 17: Chapter 3 Basic Operation

    Before connecting the connector to the fl at panel sensor, make sure that the power box is turned on. If the connector is connected to the fl at panel sensor with the power box turned off, the fl at panel sensor turns off. 897N120972A DR-ID 1200PB Operation Manual...

  • Page 18: Changing The Direction Of The Flat Panel Sensor Connector

    Insert the power cable of the power box into an outlet. Make sure that the power status LED is lit in blue. Start up the flat panel sensor with the initial settings properly made by our official dealer or FUJIFILM Representative. 897N120972A...

  • Page 19: Performing An Exposure

    When performing an exposure, make sure that the READY status lamp on the flat panel sensor is lit. 3.2.3 Shutting Down the DR-ID 1200PB Disconnect the SE connector from the flat panel sensor, and then disconnect the power cable of the power box from the outlet.
  • Page 20 897N120972A DR-ID 1200PB Operation Manual...

  • Page 21: Chapter 4 Daily Inspection And Maintenance

    4.1 Daily User Inspection and Maintenance During maintenance and inspection, strictly observe precautions contained in “Chapter 1 For Safe Operation” in this manual for you to use the DR-ID 1200PB under best conditions. 4.1.1 Periodical Inspection Inspection Every Three Months...
  • Page 22 897N120972A DR-ID 1200PB Operation Manual...

  • Page 23: Appendix A Specifications

    Specifications Appendix A A.1 Specifications Specifications of the DR-ID 1200PB are shown below. A.1.1 Power Supply Conditions Rated voltage : 100-240V~ Input current : 2-0.84A Frequency : 50-60Hz A.1.2 Environmental Conditions (1) Operating Conditions Temperature : 15°C (15%RH) - 30°C (80%RH) Humidity : 15%RH (15°C) - 80%RH (30°C) (no dew condensation)

  • Page 24: External View And Weight

    A.2 External View and Weight The external view and weight of the DR-ID 1200PB are shown below. Specifications, dimensions and weight are subject to change for improvement without prior notice. A.2.1 DR-ID 1200PB Width Depth Height Weight (mm(in.)) (mm(in.)) (mm(in.))

  • Page 25: Appendix O Use Of Optional Items

    This item is required when securing the power box to the floor of the examination car. Retaining Bracket for PB Retaining Bracket for PB Identification Label Contact a FUJIFILM dealer for installation of the Retaining bracket for PB. 897N120972A DR-ID 1200PB Operation Manual...
  • Page 26 897N120972A DR-ID 1200PB Operation Manual...

  • Page 27: Maintenance And Inspection

    Maintenance and Inspection 1 Maintenance and Inspection Items Assigned to Specified Dealer For periodical inspection of the equipment and necessary arrangements, consult our official dealer or local representative. 897N120972A DR-ID 1200PB Operation Manual...
  • Page 28 FUJIFILM MEDICAL SYSTEMS U.S.A., INC. 419 WEST AVENUE, STAMFORD CT 06902, U.S.A.
