FUV Quick Start Guide
Follow these instructions to start your FUV.
Refer to the FUV Owner's Manual (available at
www.arcimoto.com) for details on safely operating the
FUV and on using all of its features and functions.
1) Buckle Up
Sit down in the FUV, and fasten both front Seat Belts. If
you have a passenger, make sure they are buckled up as
well.
2) Put the FUV in Neutral
Set the Direction Switch on the right grip to Neutral
(the center position, indicated by a dot).
3) Turn the FUV ON
When the FUV is OFF, the Display is black. Turn the
FUV ON via either the Key or by using the PIN keypad
on the Display as described below.
Turning the FUV ON with the Key
Insert the key and turn it to the ON position.
Turning the FUV ON via PIN
1. Press anywhere on the Display to invoke the Enter
PIN keypad.
2. Enter the 6-digit PIN assigned to the FUV.
•
FUV Quick Start Guide REV 0
•
last revised: 4/14/2022 • part# 007622
2022 FUV Quick Start Guide
Refer to the FUV Owner's Manual for details on
using the Factory PIN and setting a custom User
PIN.
3. Press ENTER to turn the FUV ON and open the To
start your vehicle screen.
Startup Screens
When the FUV is turned on, the first screen displayed is
the Arcimoto logo screen:
In a few seconds, the first of several Startup Screens
displays, providing visual instructions and queues to
start the FUV.
4) Start the FUV
As the screen indicates, press the Brake Pedal
completely down. When the Brake Pedal is pressed
sufficiently, a green check mark appears on the screen,
replacing the Brake Pedal graphic:
Note that the screen indicates if the
Brake Pedal has not been pressed
sufficiently. In this case, apply more
pressure to the brake pedal until a
green check mark appears under Press
foot brake.
