SERVICE MANUAL
1. Caution....................................................................................2
2. specification..............................................................................6
3. Alignment Procedure..................................................................7
4．Block diagram...........................................................................1
5．Scheme Diagram .....................................................................
5. Troubleshooting........................................................................26
6. PCB Layout ...........................................................................3
8. BOM list..............................................................................................................33
This m anual i s t he l atest at t he t ime of pr inting, and doe s not
include the modification which may be made after the printing, by
the constant improvement of product
TCL
LED39T3510/MS82F-AP
2

Advertisement

loading
Need help?

Need help?

Do you have a question about the LED39T3510 and is the answer not in the manual?

Questions and answers

Related Manuals for TCL LED39T3510

Summary of Contents for TCL LED39T3510

  • Page 1 SERVICE MANUAL LED39T3510/MS82F-AP 1. Caution…………………………………………………………………………2 2. specification……………………………………………………………………6 3. Alignment Procedure…………………………………………………………7 4．Block diagram…………………………………………………………………1 5．Scheme Diagram …………………………………………………………… 5. Troubleshooting………………………………………………………………26 6. PCB Layout …………………………………………………………………3 8. BOM list......................33 This m anual i s t he l atest at t he t ime of pr inting, and doe s not...
  • Page 2 SCHNEIDER ELECTRONICS GMBH-GERMANY 1. CAUTION CA UTION: Use of controls, adjustments or procedures other than those specified herein may result in hazardous radiation exposure. CA UT ION : T O RE DUCE TH E RIS K OF CA U T ION ELECTR ICA L SHOCK, DO NOT RE MOVE COVER (OR BACK).
  • Page 3 SCHNEIDER ELECTRONICS GMBH-GERMANY IMPORTANT SAFETY INSTRUCTIONS CAUTION: Read all of these instructions. Sa ve these instructions for later use . Follo w all W arnings and Instructions marked on the audio equipment. 1. Read Instructions-All the safety and operating instructionsshouldbe read before the productis operated. 2.
  • Page 4 SCHNEIDER ELECTRONICS GMBH-GERMANY PROTECTION AND LOCATION OF YOUR SET Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, etc. Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall outlet and refer servicing to qualified service personnel.
  • Page 5 SCHNEIDER ELECTRONICS GMBH-GERMANY OPERATION OF YOUR SET 18. This television set should be operated only from the type of power source indicated on the marking label.If you are not sure of the type of power supply at your home, consult your television dealer or local power company. For television sets designed to operate from battery power, refer to the operating instructions.

  • Page 6: Alignment Procedure

    第 1 页共 11 页 文件编号：CRT/SJ/FK02-2010 OEM 事业部 序号： OEM 设计中心 Alignment Procedure MS82 Series （MODEL） ： VERSION：V1.0 PREPARED BY : Xiongzp DATE : 2012-12-25 APPROVED BY : DATE :...

  • Page 7: Factory Menu

    第 2 页共 11 页 History Description of major changes Release Date V1.0 2012-12-25 1.Overview MS82L chassis is designed for Asia Pacific/South America market. Both Full HD panel and HD panel can be compatible. The signal sources include TV,AV,YPBPR/YCBCR,VGA,HDMI and USB. For YPBPR,HDMI source ,Format up to 1080p can be supported;...
  • Page 8 第 3 页共 11 页 5-SHOP Reset after production alignment;(This operation will remove all unnecessary factory value; The factory hotkey will be turn off) 6-NVM reset System initialization. Restore all data except the White Balance and ADC data ;Only for R&D. 7-SET FAC CH Preset specific factory channels for specific factory.
  • Page 9 Method 2: Press RETURN button when DESIGN HOTKEY is enabled (ON). 2、General introduction DESIGN MENU ITEMS Default Description Status Setting 1-DESIGN ON/OFF HOTKEY 2-FACTORY ON/OFF MENU 3-SHOP INIT Default setting submenu after production alignment refer to ** 4-OTHER Other set .Only for TCL R&D...
  • Page 10 第 5 页共 11 页 5-SERVICE After service menu description MENU 6-PARAM Parameter setting submenu SETTING 7-HOTEL Hotel submenu MENU 8，LANGUAGE OSD 语言设定 MENU SHOP INIT submenu ITEMS Default Description Status Setting Volume 0-100 adjustable PIC MODE STANDARD STANDARD/BRIGHT/SOFT/PERSONAL SOUND MODE STEREO STEREO/MUSIC/MOVIE/NEWS Channel 0-199 adjustable...

  • Page 11: Service Menu

    第 6 页共 11 页 SSC adjust DBC adjust DBC ENABLE DBC MODE MIU DQS0 MIU DQS1 TELETEXT SWITCH (only for MS82B/E series) TELETEXT NICAM SWITCH (only for MS82B/E series) NICAM PARAM SET SETTING ITEMS Default Description Status Setting Brightness Brightness curve.
  • Page 12 POWER LOGO OFF/TCL Power on ,panel display logo SAANDBY LOGO ON/OFF NO USE LOGO_LIGHT ON/OFF LOGO BACKLIGHT, Some model used TCL SHOW ON/OFF default ERROR CODE Erase HDCP Key Do Only for R&D Reset HDCP Key Do Only for R&D UsbHdcpkey Only for R&D...
  • Page 13 第 8 页共 11 页 5. Debugging 5.1. General Steps of debugging According to the requirement of the order, below steps are needed for appropriate setting. 1) Enter the Factory Menu, enable FAC HOTKEY. 2) Check Project ID and the version of software, release date displayed at the bottom of Factory Menu.
  • Page 14 第 9 页共 11 页 5.3.1. Signal and generator PC: Chroma2329 Pattern 42,Timing 14(1024X768@60Hz 5 MOSAIC) YPBPR: Chroma2329 pattern 103, Timing 79(100% Color Bar,720p) 5.3.2. Steps of Calibration: 1). Access to the Factory menu->ADC 2). select RGB source and see the 5 MOSAIC appear on the screen 3).

  • Page 15: Chip List Of Software Programming Before Smt

    The process of adjusting ADC and White Balance automatically is out of the range of this file, Please refer to the relevant technical file of HuiZhou factory of TCL. 6.Chip list of software programming before SMT Following chips must be programmed before SMT by tools...
  • Page 16 第 11 页共 11 页 insert the USB device to USB interface of TV set. 2,using the remote, enter the “Picture” submenu of the OSD; choosing the “contrast” item and press 9,7,3 and 5 in series, Factory Menu will appear in the left top of screen. 3,Select the “USB UPDATE”...
  • Page 17 ｐａｎｅｌＰｏｗｅｒ 12V  ｐ ａ ｎ ｅ ｌ Ｐ ｏ ｗ ｅ ｒ Ｃ ｏ ｎ ｔ ｒ ｏ ｌ Ｓ ｗ ｉ ｔ ｃ ｈ Q8013    12V ｔｕｒｎ 5V    5V  MP1494  USB  U805  Power Amplifier  12V ｔｕｒｎ 182VG  ｐｏｗｅｒ 1.26V    650mA ...
  • Page 18 VGA & audio input BACK AV1 IN R710 AV1 IN 100R VGA-VS VGA-VS GND10 GND2 AV1-V AV1-R P701 100R R711 VGA-HS VGA_BIN VGA-HS AV1-L C165 R708 R709 R727 VGA_GIN VGA_RIN R728 AVR1 AVR1 C714 560P C166 C715 560P R729 WHITE DGND R730 DGND...
  • Page 19 R524 H2_5V SAR2 H2_5V R509 H2_5V 100K R525 H2_5V GND_H2 5VAIN DGND HDMI CENNECT0R C500 DGND H2_HPD DGND R501 R502 R508 R510 R511 NC-HDMI2 R506 NC-HDMI2 H2_HPD H2_HPD H2_HPD H2_HPD HDMI_DDC_SDA R517 HPD2 SDA_SINK HDMI_HPD H2_SDA HDMI_DDC_SCL R507 SDA2 SCL_SINK HDMI_DDC_SDA H2_SCL RXC-...
  • Page 20 RESET DDR2 VREF R101 DDR POWER +3_3VSTB NORMAL POWER +2V5 NORMAL POWER +3V3 NORMAL POWER VDDC L817 L100 AVDD_DDR_1V8 +3_3V_DC +3_3VSTB +2.5V_PGA R106 L101 AVDD_DDR DVDD_NODIE_1_2V +2V5 120R 120R +2V5 ADC2P5 AVDD_DDR_1V8 VDDC-1V28 120R C102 C101 D100 MDDR_VREF 0.1U C128 0BAV99 R102 C122...
  • Page 21 close to ic ZSDA ZAGC +3_3V_DC R206 ZSCL R203 TU1_SCL 0.1U C201 C200 0.022U R201 10K R202 C202 100R TAGC 100P +3_3V_DC 500R TU1_SCL L201 DGND R207 TU1_SDA TU1_SDA C206 C207 C208 C205 470U 0.01U C204 0.1U C203 TU_IF- DGND 100P IF_N TU_IF+...
  • Page 22 BL_ON/OFF P_ON/OFF +12V VBR_OUT +3_3VSTB C802 R854 +3_3VSTB +24V/12V +12V P800 0.1U +12V +12V DIMMING BL_ON/OFF R874 L814 R885 10UH C872 P_ON/OFF 100K R819 DGND R813 100K U808 VCC=0.8(1+22/3.9)=5.3V +3_3VSTB +3_3VSTB C822 C800 L801 0.1U C819 V_AUDIO C821 C815 DGND DGND D806 0.1U...
  • Page 23 3.3V_AMP +3_3V_DC +3_3V_DC L601 +3_3V_DC 120R 3.3V_AMP R602 R601 MUTE R603 33R R604 AMP_RESET DGND R662 R663 I2S_DATA C601 C602 DGND I2S_LRCLK 3.3V_AMP L602 22UH OUT_L+ I2S_BCK C603 0.1U 0.1U C613 R611 STA380BW R612 C618 DGND 0.1U C604 C611 1000P C645 0.01U DGND...
  • Page 24 Trouble shooting 1、 Can not switch on： no switch on Check 3.3V/12V/24V of power supply Check PW Only 3.3V Check signal P—ON， Check DC-DC DIMBL—ON of main IC link part,check to PW Check the peripheral circuit of mail IC,check solder of Check reset Check IIC bus main IC,check data fo NVM...
  • Page 25 2、abnormal picture ： Abnormal picture Individual signal source All signal source bad Check the path with this Check panel ID？ signal source Check LVDS signal to main Check the peripheral circuit IC？check LVDS cable? of mail IC,updating SW,reset NVM,replace main IC Check crystal frequence？...
  • Page 26 3、 Abnormal sound： Abnormal sound Individual sound Check all sound signal source source Check the sound signal Check sound IC link to main IC Check the power of Check the peripheral Check wave filter and sound IC circuit of main IC,SW speaker？...
