Page 1
Unpacking and assembly instructions Model 6210...
Page 2
Required tools and capacity for unpacking One scissor One powerdrill with a philips head screw tip The unpacking includes mo- ments of heavy lifting which re- quires four people UNPACKING INSTRUCTIONS 6210...
Page 3
Move on by removing the screws at the side of the crate that is marked out with an attention slip (shown to the right) and lift off the side. Unscrew the remaining screws on the remaining sides of the pallet and lift of the sides. UNPACKING INSTRUCTIONS 6210...
Page 4
The crate comes with articles that are not assembled to the - One protective cover for the frame table, carefully remove these articles and set them aside. - One arm rest for the right side of the table. UNPACKING INSTRUCTIONS 6210...
Page 5
Step 5: Remove the plastic cover on the squeeze protection Carefully peel off the white protective plastic on the squeeze protection on the left-hand side of the table. UNPACKING INSTRUCTIONS 6210...
Page 6
Step 6: Install the protective cover Gently click the protective cover into position on the left side of the table’s base in between the legs. UNPACKING INSTRUCTIONS 6210...
Page 7
ATTENTION! Do NOT lift the table off the pallet from another location than shown in the pictures to the right. UNPACKING INSTRUCTIONS 6210...
Page 8
An ADDvise Group Company SONESTA MEDICAL INC SONESTA MEDICAL AB INDUSTRIVÄGEN 7 2 DEBUSH AVENUE UNIT C3 MIDDLETON; MA 01949, USA 171 48 SOLNA, SWEDEN +46 8 502 572 80 + 1 630-519-3450 INFOUS@SONESTAMEDICAL.SE INFO@SONESTAMEDICAL.SE ORDER@SONESTAMEDICAL.SE ORDER@SONESTAMEDICAL.SE UNPACKING INSTRUCTIONS 6210 WWW.SONESTAMEDICAL.SE WWW.SONESTAMEDICAL.SE...
