UniPi Technology Patron S107 Quick Start Manual

Models:
Unipi Patron S107, S117, S167, S207, M207, M267, M527, M567, L207, L527
PLEASE RETAIN THIS DOCUMENT FOR FUTURE REFERENCE
WARNING
The unit can be powered only by a power source in compliance with the unit's specifications. Using an unsuitable power
supply can result in damage to the unit or connected devices. Unplug all power supplies and voltage sources before
any manipulation with the unit – danger of electrical injury or component damage!
Do not use the controller in potentially explosive environments! The controller can be installed only by trained personnel
with sufficient qualification. The unit can be installed only in a suitable environment following the product's technical
specifications (indoor space with suitable temperature and humidity, waterproof distribution boxes, etc.).
All connected peripherals should comply with all standards and regulations relevant to the country and the intended
use.
Working conditions
Power supply (SELV)
Power consumption
Power supply
pole reversal protection
RS232
1-Wire bus
Compliance information
Unipi Patron complies with the requirements
of EMC, LVD and RoHS regulations relevant
for European Union states.
General info
www.unipi.technology
24 V DC
Max: 12 - 20 W (see the
unit's datasheet)
Ano
RS485 #2
Digital outputs
Technical and safety information
Ingress protection
(IEC 529)
Working and storage
temperature
Installation
Analog I/O
Digital inputs
2x USB 2.0
+24V DC
WEEE Directive Statement for the European Union
Unipi Patron units cannot be disposed of as household
waste. Different rules for handling electric waste may
apply in other jurisdictions.
Technical support, Knowledge Base
IP20
Working: 0 °C .. +55 °C
Storage: -25°C .. +70°C
On a 35mm DIN rail in a
distribution box
(holder included)
RS485 #1
100Mbit ETH
Customizable LEDs
https://kb.unipi.technology
