Gardman Gallic Arch 07735 Assembly Instructions

Gallic Arch
Assembly Instructions
Components Supplied
Ref Description
A Straight tube
Size: 1.05m x 19mm
1 / 3 /
(3'5 x ")
2 4
(approx.)
B T joints
C Moisture
protection
sleeve
D Top left
Curved tubes
E Top right
Curved tubes
F Struts
Size: 0.41m x 16mm
1 /
(16" x ")
2
(approx.)
G Ground hole
maker
H Assembly
screws
Illustration Qty
8
14
10
2
2
7
1
14
Tools Required (not supplied)
Phillips cross-head screwdriver
Mallet
Tape Measure
Before You Start
• Layout all of the component parts and
make sure you have all of the parts listed.
• When you are ready to start, make sure
that you have the right tools to hand,
plenty of space and a clean dry area for
assembly. Always try to assemble the
product as close as possible to the
intended location.
• Remove all plastic bags and dispose of
safely.
• Retain the instructions for future use.
Caution
This pack contains small items which should
be kept away from children.
Consumer Helpline
If you have any problems or queries with
this product then please contact our
helpline number: 01406 372227,
or write to: Gardman Ltd. High Street,
Moulton, Spalding, Lincs, PE12 6QD.
Fax: +44 (0) 1406 372233.
07735
