Embedded
Solutions
MODEL P104-DIO-96
USER MANUAL
FILE: mp104-dio-96.A1j
ADL Embedded Solutions GmbH, Eiserfelder Straße 316 D-57080 Siegen,
ADL Embedded Solutions, Inc. 4411 Morena Blvd., Suite 101
Germany P. +49 (0) 271 250 810 0 F. +49 (0) 271 250 810 20
San Diego, CA 92117-4345 P. +1 858 490-0597 F. +1 858 490-0599
e-mail: sales@adl-europe.com; web:
www.adl-europe.com
e-mail: sales@adl-usa.com; web:
www.adl-usa.com
Advertisement
Related Manuals for Embedded Solutions P104-DIO-96
Summary of Contents for Embedded Solutions P104-DIO-96
- Page 1 MODEL P104-DIO-96 USER MANUAL FILE: mp104-dio-96.A1j ADL Embedded Solutions GmbH, Eiserfelder Straße 316 D-57080 Siegen, ADL Embedded Solutions, Inc. 4411 Morena Blvd., Suite 101 Germany P. +49 (0) 271 250 810 0 F. +49 (0) 271 250 810 20 San Diego, CA 92117-4345 P. +1 858 490-0597 F. +1 858 490-0599 e-mail: sales@adl-europe.com;...
- Page 2 This document may contain or reference information and products protected by copyrights or patents and does not convey any license under the patent rights of ADL Embedded Solutions, Inc., nor the rights of others.
- Page 3 Chapter 3: Option Selection ..................10 Figure 3-1: Option Selection Map................10 Chapter 4: Address Selection ..................11 Chapter 5: Programming .................... 12 Table 5-1: Base Registers ..................12 Table 5-2: Control Register Bit Assignments ............13 Chapter 6: Connector Pin Assignments..............15 Manual P104-DIO-96...
- Page 4 1A fast blow fuse in your circuits in order to avoid possible damage to the host computer. The board occupies 32 bytes within the PCI I/O space. The base address is assigned by the system. Refer to the Option Selection Section of this manual for a detailed description. Manual P104-DIO-96...
- Page 5 • Power Required: 290 mA typical at 5V (all I/O pins disconnected, all I/O ports set as inputs) Environmental • Operating Temperature: -20ΕC to +70ΕC • Storage Temperature: -50ΕC to +120ΕC • Humidity: 0 to 90% RH, non-condensing Manual P104-DIO-96...
- Page 6 Figure 1-1: Block Diagram Manual P104-DIO-96...
- Page 7 START | RUN and type d:install, click OK or press K. Follow the on-screen prompts to install the software for this board. LINUX Please refer to linux.htm on the CD-ROM for information on installing under linux. Manual P104-DIO-96...
- Page 8 This will select the signal with the shortest trace on the CPU board (signal group 3). Place the SEL-1 switch to the left and SEL-2 to the right to select signal group 1, place the SEL-1 switch to the right and SEL-2 to the left to select signal group 2. Manual P104-DIO-96...
- Page 9 Position the slide switches to select the clock, IDSEL, and interrupt signal group. Install the card in a PC/104-Plus stack. Install I/O cables at P1 and P2. Inspect for proper fit of the card and cable and then tighten the screws Figure 2-1: PC/104 Key Information Manual P104-DIO-96...
- Page 10 Most PCI bus signals are common to all four boards in the PCI stack. However, there are four unique signal groups, one for each board. The slide switches select which signal group goes to each card. The card in the stack closest to the CPU board must get signal group 0. Figure 3-1: Option Selection Map Manual P104-DIO-96...
- Page 11 PCIFind uses the Vendor ID and Device ID to search for your board, then reads the base address and IRQ. If you want to determine the base address and IRQ yourself, use the following information. The Vendor ID for the card is 494F. (ASCII for "IO") The Device ID for the card is 0x0C69. Manual P104-DIO-96...
- Page 12 Group 1 CMD Base+E Group 3 Port C Group 3 Port C Group 2 CMD Base+F Group 3 CMD Group 3 CMD Base+10 Reserved Reserved Reserved Reserved through Base+1E Base+1F Reset Card Reset Card Table 5-1: Base Registers Manual P104-DIO-96...
- Page 13 Because many motherboard’s reset circuits do not accurately wait for the 3.3V power supply to finish the power-on sequence, before using the board at each power-up it is necessary to issue a single “Write to Base +1F” to “Reset” the onboard circuitry. Manual P104-DIO-96...
- Page 14 X=INP(BASEADDR)'Read Port A Y=INP(BASEADDR+2)/16'Read Port C Hi To set outputs high ("1") at Port B and the lower nybble of Port C: OUT BASEADDR+1,&HFF'Turn on all Port B bits OUT BASEADDR+2,&HF'Turn on all bits of Port C Lo Manual P104-DIO-96...
- Page 15 Chapter 6: Connector Pin Assignments Note that the board uses four 50-pin Headers, each with equitable pinouts. Assignment Assignment Port C Hi Port C Lo Port B Port A +5 VDC Manual P104-DIO-96...
- Page 16 Embedded Solutions ADL Embedded Solutions GmbH, Eiserfelder Straße 316 D-57080 Siegen, ADL Embedded Solutions, Inc. 4411 Morena Blvd., Suite 101 Germany P. +49 (0) 271 250 810 0 F. +49 (0) 271 250 810 20 San Diego, CA 92117-4345 P.
