Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
Email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2021 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
21j
58205 57732
Advertisement
Table of Contents
Related Manuals for HAUL MASTER 58205
Summary of Contents for HAUL MASTER 58205
- Page 1 (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference. Visit our website at: http://www.harborfreight.com 58205 57732 Email our technical support at: productsupport@harborfreight.com When unpacking, make sure that the product is intact and undamaged.
-
Page 2: Important Safety Information
Service Have your tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the tool is maintained. Page 2 For technical questions, please call 1-888-866-5797. Item 58205 57732... -
Page 3: Specific Safety Warnings
SAVE THESE INSTRUCTIONS. Specifications Item 58205 57732 Rated Capacity 1500 lb. 1000 lb. Lift Range 13-7/8″ - 26-1/4″ 12-3/4″ - 22-3/4″ Travel 12-3/8″ 10″ Wheel Diameter 6″ 6″ Item 58205 57732 For technical questions, please call 1-888-866-5797. Page 3... -
Page 4: Installation Instructions
4" to 5" location. b. Allow room on both sides of the mounting location for the Jack to swing up to its horizontal position. Page 4 For technical questions, please call 1-888-866-5797. Item 58205 57732... - Page 5 7. Attach the safety chain (sold separately). to the level of the towing vehicle’s hitch. Jack positioned for use Jack rotated for travel/storage Steps to rotate Jack Figure B: Jack Positions Item 58205 57732 For technical questions, please call 1-888-866-5797. Page 5...
-
Page 6: Cleaning, Maintenance, And Lubrication
Outer Tube Assembly Washer, 3.5mm Nylon Washer Washer, 5mm Cylindrical Pin Inner Tube Assembly Lock Nut, M12 Wheel, 6″ Bolt, M12x80 Mounting Bracket Bolt, M10x110 Mounting Strap Spring Washer Nut, M10 Page 6 For technical questions, please call 1-888-866-5797. Item 58205 57732... -
Page 7: Please Read The Following Carefully
Parts List and Assembly Diagram - 58205 1500 lb. Jack Part Description Grooved Pin Vertical Bevel Gear Horizontal Bevel Gear Adjusting Washer Square Bushing Outer Tube Assembly Handle Lock Nut, M10 Handle Sleeve Handle Screw Cap Screw, M10x25 Bracket Cover... -
Page 8: Limited 90-Day Warranty
Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
