STAGE 1
Ensure you have all the correct items
before you begin the assembly
process.
STAGE 4
Stand the small pedestal inside the
large bowl encasing the pump; attach
one end of the black tubing over the
pump's nozzle.
H5215F5RL
Leonesco Fountain
STAGE 2
Stand the pedestal upright with the
large bowl on top ensuring the large
bowl is central to the pedestal.
STAGE 5
Sit the tall pedestal on top of the small
pedestal feeding the tubing through as
you stand it up.
STAGE 3
Feed the pump cable through the hole
in the large bowl and feed all the way
through until the there is approx 10cm
of cable between the pump and the
bowl. Wrap the large rubber stopper
around the cable and force into the
hole creating a water tight seal.
STAGE 6
Wrap the smaller rubber stopper
around the tubing and force down into
the hole creating a water tight seal.
1 of 2
Advertisement
Table of Contents
Related Manuals for HENRI Kelkay Leonesco
Summary of Contents for HENRI Kelkay Leonesco
- Page 1 1 of 2 H5215F5RL Leonesco Fountain STAGE 1 STAGE 2 STAGE 3 Ensure you have all the correct items Stand the pedestal upright with the Feed the pump cable through the hole before you begin the assembly large bowl on top ensuring the large in the large bowl and feed all the way process.
- Page 2 2 of 2 H5215F5RL Leonesco Fountain STAGE 7 STAGE 8 STAGE 9 Feed the end of the tubing through Insert the large trap door into the open The fountain is now ready for water, the top finial and stand on top of the space at the bottom of the fountain.
