- Page 1 FB250/Fleet One Inmarsat FleetBroadband/Fleet One Installation & Operation User Guide...
- Page 2 This serial number will be required for all troubleshooting or service inquiries. © 2020 Intellian Technologies, Inc. All rights reserved. Intellian and the Intellian logo are trademarks of Intellian Technologies, Inc., registered in the U.S. and other countries. Intellian may have patents, patent applications, trademarks, copyrights, or other intellectual property rights covering subject matter in this document.
-
Page 3: Table Of Contents
Chapter 1. Precautions 1.1 Warnings, Cautions, and Notes 1.2 General Precautions Chapter 2. Certifications Chapter 3. Introduction 3.1 Introduction of FB250/Fleet One 3.2 Features of FB250/Fleet One 3.3 Overview of FleetBroadband 3.3.1 BGAN Services Chapter 4. Planning Installation 4.1 Selecting Installation Site 4.1.1 Avoiding RF Interference... - Page 4 FB250/Fleet One - Marine Satellite Communication System 6.6.3 Connecting DC Power to BDU 6.6.4 Connecting BDU to ADU (Antenna) 6.6.5 Connecting BDU to Devices using LAN Port (RJ45) 6.6.6 Connecting BDU to Device using WAN Port 6.6.7 Connecting BDU to POTS Phone (RJ14) 6.6.8 Connecting BDU to External Devices...
- Page 5 Table of Contents 8.8.4 Phone/PABX 8.8.5 Data 8.8.6 Satellite 8.8.7 SMS 8.8.8 Service Profile 8.8.9 Service User Group 8.8.10 Device Registration 8.8.11 Traffic Flow Template (TFT) 8.8.12 USIM 8.8.13 External GPIO 8.8.14 Restricted Dialing 8.8.15 Multi Voice 8.8.16 NSD 8.8.17 MST 8.9 Tools 8.9.1 Software Upgrade 8.9.2 Backup and Restore...
- Page 6 Figure 20: Attach Cable Tray to BDU Figure 21: Attach Rackmount Plate to BDU Figure 22: Mount BDU Assembly into 19” Rack Figure 23: System with Connected Devices for FB250 and not Fleet One Figure 24: BDU Back Panel View Figure 25: DC Power Connector Pinout...
- Page 7 Table of Contents Chapter 7. Operating BDU Figure 39: BDU Front Panel...
-
Page 8: Chapter 1. Precautions
FB250/Fleet One - Marine Satellite Communication System Chapter 1. Precautions 1.1 Warnings, Cautions, and Notes WARNING, CAUTION, and NOTE statements are used throughout this manual to emphasize important and critical information. You must read these statements to help ensure safety and to prevent product damage. - Page 9 Precautions * DO NOT SHIP VIA RAIL: Ensure not to ship any system via Rail. * Shock Hazard: To minimize shock hazard and to protect against lightning, you must connect the equipment chassis and cabinet to an electrical ground. Make sure the system is correctly grounded and power is off when installing, configuring, and connecting components.
-
Page 10: Chapter 2. Certifications
(2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Changes or modifications made to this equipment not expressly approved by Intellian Technologies, Inc. may void the FCC authorization to operate this equipment. -
Page 11: Chapter 3. Introduction
Intellian Fleet One provides simultaneous voice and IP data up to 150 kbps. Intellian FB250 provides up to 284 kbps IP data and 128 kbps streaming IP with VoIP service and SMS, and it is compatible with the GSM network standard. -
Page 12: Overview Of Fleetbroadband
FB250/Fleet One - Marine Satellite Communication System 3.3 Overview of FleetBroadband 3.3.1 BGAN Services The Broadband Global Area Network (BGAN) is a global Satellite Internet Network using portable terminals. The terminals are usually connected to a laptop computer to access broadband Internet in remote locations, where a line-of-sight to the satellite exists. - Page 13 Introduction Fleet One Coastal Coverage and rate regions NOTE The above map depicts Inmarsat’s expectations of coverage but does not represent a guarantee of service. The availability of service at the edge of coverage areas fluctuates depending on various conditions. NOTE...
-
Page 14: Chapter 4. Planning Installation
FB250/Fleet One - Marine Satellite Communication System Chapter 4. Planning Installation The antenna installation requires precaution and safety measures. Failure to follow the correct installation process may lead to injury of the installer and/or cause damage to the system. In order to maximize the performance of the system, a thorough review of this installation guide is strongly recommended, as well as executing the installation process as it is noted in this manual. -
Page 15: Rf Hazard Precautions
Planning Installation 4.1.2 RF Hazard Precautions The antenna is designed to be used with radiation transmitting equipment manufactured by others. Exposure to RF radiation, including exposure associated with improper use of the transmitting equipment, may be hazardous to people who work close to the Above Deck Unit. Ensure the safety of personnel who work with in the system. -
Page 16: System Package
Intellian’s web-based software. The BDU contains user interfaces and controls all communication between the ADU and the local communication devices such as phones, and computers, etc. -
Page 17: Packing List
Before beginning installation, make sure you have all the included components. The ADU Package & BDU Package are provided in one box. NOTE: The USIM card is provided by the service provider and may be packaged separately. Above Deck Unit (ADU) Package for FB250 Item Q'ty... - Page 18 FB250/Fleet One - Marine Satellite Communication System 19-inch Rack Mount Kit (Optional) The 19-inch Rack Mount Kit can be purchased separately. When this kit is supplied, it is packaged in the BDU Package. Item Q'ty Size Description AC Power Cord (USA) 1.5 m...
-
Page 19: System Cables
4.3.1 Antenna RF Cable (Connecting ADU - BDU) Intellian provides the Antenna RF Cable (LMR200, 25 m) for connecting ADU and BDU. Due to the signal losses across the length of the RF coax on L-Band, Intellian recommends the following 50 Ω coax cable types for standard system installations. -
Page 20: Unpacking System Package
FB250/Fleet One - Marine Satellite Communication System 4.4 Unpacking System Package Follow the steps for easy and safe unpacking. The system package consists of two sub-packages that an ADU Package and a BDU Package. Unit: mm (inch) BDU Package ADU Package Figure 5: Unpacking System Package (with ADU &... -
Page 21: Figure 7: Unpacking Adu Package
Planning Installation 2. Take out the ADU package including an Antenna Mounting Template, an ADU Bolt Kit, an Antenna RF Cable, and an ADU Unit. Antenna Mounting Template ADU Bolt Kit Antenna RF Cable ADU Unit Figure 7: Unpacking ADU Package... -
Page 22: Chapter 5. Installing Adu
FB250/Fleet One - Marine Satellite Communication System Chapter 5. Installing ADU 5.1 Antenna Dimensions Confirm the height and diameter of the antenna unit shown in the following figure before installing it. Unit: mm (inch) Ø250 (9.84) Ø291 (11.45) Ø291 (11.45) -
Page 23: Adu Mounting Hole Pattern
Use the mounting holes to secure the antenna to the desired mounting surface. Intellian offers the Antenna Pole Mount Kit (separate purchase) that uses holes (with M6 Bolts) to mount the antenna on a pole. -
Page 24: Mast Designing (Installation Example)
FB250/Fleet One - Marine Satellite Communication System 5.3 Mast Designing (Installation Example) The installation mast must be robust enough to prevent flex, vibration, and sway when an external force is exerted on the mast with antenna and radome. Refer to the following mast drawings for more details. -
Page 25: Figure 10: Recommended Mast Design
Installing ADU Mounting Plate Ø220 (8.66) Unit: mm (inch) Bolt Hole Ø175.4 (6.9) 8 (0.31), 4 ea 45º * NOTE: There is no need to install gusset at the top end of the mast. Plate Thickness Min. 6 (0.23) Max. 8 (0.31) Support Pedestal, 125A Pipe (5 inches) Figure 10: Recommended Mast Design... -
Page 26: Mounting Antenna
5.4.2 Mounting Antenna on Pole (Optional) Intellian offers the Antenna Pole Mount Kit (separate purchase) to mount the antenna on the pole. The kit is designed to work on the 40 A pole. The kit has mounting holes that match the inner hole with M6 bolts on the bottom of the antenna. -
Page 27: Figure 12: Installing 40 A Pole Bushing Inside Pole Tube
Installing ADU x Three Times M12 x 12 L Use a torque wrench. Socket Set Screw *Pole Tube 40 A Pole Bushing 40 A Pole Figure 12: Installing 40 A Pole Bushing inside Pole Tube The position between the end of legs of the pole bracket must be aligned with the BOW direction. Place the pole bracket onto the pole tube then tighten them using bolts. -
Page 28: Connecting Antenna Rf Cable
FB250/Fleet One - Marine Satellite Communication System 5.5 Connecting Antenna RF Cable The cable must be routed from the antenna and through various areas of the ship to end up at the Below Deck Unit. When pulling the cables in place, avoid sharp bends, kinking, and excessive force. After placement, seal the deck penetration gland and tie the cable securely in place. -
Page 29: Chapter 6. Installing Bdu
Chapter 6. Installing BDU The Intellian offers two versions of BDU installation, one can be installed to the surface of the wall or desktop, and one can be installed to the 19-inch rack frame using the BDU Rack Mount Kit (separate purchase). - Page 30 FB250/Fleet One - Marine Satellite Communication System Unit: mm (inch) 280 (11.02) 315 (12.40) 42 (1.65) 485.7 (19.12) Figure 17: BDU Dimensions (19-inch Rack Mounting Type_Optional)
-
Page 31: Bdu Mounting Template
Installing BDU 6.3 BDU Mounting Template The BDU mounting holes must be in the exact same place as shown in the provided mounting template below. 300 mm (11.81") Drill Hole Ф 3.8 mm (0.14") diameter in 4 positions Figure 18: BDU Mounting Template... -
Page 32: Mounting Bdu
FB250/Fleet One - Marine Satellite Communication System 6.4 Mounting BDU The BDU can be mounted in any orientation but for best performance, Intellian recommends that it is mounted horizontally. WARNING Ensure that the cables connected to the BDU are long enough to prevent damage when the BDU is pulled out from the rack. -
Page 33: Figure 21: Attach Rackmount Plate To Bdu
Installing BDU 2. Using the Screws supplied, attach the rackmount plate to the BDU. Rackmount Plate Pan Head Screw (with Spring & Flat Washer), M4 x 16 L (4 ea) Figure 21: Attach Rackmount Plate to BDU 3. and fasten the screws to the rack. Make sure that the BDU assembly is mounted securely according to the requirements for your 19”... -
Page 34: Antenna System Configuration
(including 2 analog phones and 16 sip phones). The BDU communicates directly with SIP phones on any of the LAN user ports ( FB250 : LAN 1, 2, 3, or 4 / Fleet One : LAN 1 or 2). The SIP phones register directly to the SIP server in the BDU. -
Page 35: Bdu Cable Connection
Installing BDU 6.6 BDU Cable Connection 6.6.1 BDU Back Panel View The following figure shows the BDU back panel. * NOT supported for Fleet One. WAN (Wide Area Grounding Power Antenna (TNC) Network) Wi-Fi GPIO USIM **PoE (Power * LAN (Local Area POTS (Plain Old Telephone Card over Ethernet) -
Page 36: Figure 26: Antenna Connector (Tnc) Pinout
FB250/Fleet One - Marine Satellite Communication System Antenna Connector (TNC) RF TNC Female Conductor Function Inner Data, 48 V DC Power Outer Ground Figure 26: Antenna Connector (TNC) Pinout LAN Connectors (1~4) (RJ45) 1 2 3 4 5 6 7 8... -
Page 37: Figure 29: Gpio Connector Pinout
Installing BDU General Purpose Inputs/Outputs (GPIO) Connector The BDU has a dedicated 16-pin connector to provide a GPIO (General Purpose Input/Output) interface to the external devices. All wires for the GPIO connector must use AWG 24 unscreened wire type. 16-Pin Terminal Block Signal Explanation Signal... - Page 38 FB250/Fleet One - Marine Satellite Communication System To use External GPIO, connect the external power (DC 12 V ~ 24 V). Refer to the External GPIO Block Diagram below. External GPIO Block Diagram INPUT 1 INPUT 2 Programable Digital Input...
-
Page 39: Connecting Dc Power To Bdu
6.6.3 Connecting DC Power to BDU You can supply DC power to the BDU in the following methods depending on the power supply available in the vessel. Intellian provides a DC Power Cable, an AC-DC Adapter (optional), and a Terminal Block for the power connections. - Page 40 How to Use Terminal Block WARNING Turn off the power before installing the wire nut connector. WARNING Intellian provides a 3-position double-row barrier terminal block as below. Terminal Block: KH-6060-3P Position 1 Position 2 Position 3 Barrier type terminal strip:...
- Page 41 Installing BDU Black (negative) For the DC power wires, Red (positive) and Black (negative), you can connect each wire with other wires using the terminal block. Red (positive) 1. Open the top cover of the terminal block. 2. Unscrew the 1st position terminal using a Phillips screwdriver. Insert the ring connector of the Red (positive) wire to the terminal and tighten the screw back into the terminal.
-
Page 42: Connecting Bdu To Adu (Antenna)
6.6.5 Connecting BDU to Devices using LAN Port (RJ45) Intellian provides the Ethernet Cable. Connect the Ethernet Cable from the Port 1, Port 2, Port 3, or Port 4 on the back of the BDU to the LAN port on the devices such as SIP Phone or Computer. -
Page 43: Connecting Bdu To Device Using Wan Port
Installing BDU 6.6.6 Connecting BDU to Device using WAN Port Intellian provides the Ethernet Cable. Connect the Ethernet Cable from the WAN port on the back of the BDU to the RJ-45 port on the devices such as LTE modem. -
Page 44: Connecting Bdu To External Devices
External Devices Figure 36: BDU to External Devices Connection 6.6.9 Connecting Wi-Fi Antenna to BDU Intellian provides the Wi-Fi Antenna for Wi-Fi connection. Plug the Wi-Fi Antenna into the Wi-Fi port on the back of the BDU. Wi-Fi Antenna Wireless... -
Page 45: Inserting Usim Card
Installing BDU 6.6.11 Inserting USIM Card The system requires a USIM card from the service provider to use the terminal and configure the settings of the BDU. 1. Find the USIM card slot on the BDU and open the cover. 2. -
Page 46: Chapter 7. Operating Bdu
FB250/Fleet One - Marine Satellite Communication System Chapter 7. Operating BDU The BDU and ADU are connected by a single coaxial cable through which power and Ethernet data are delivered between the BDU and ADU. The BDU is responsible for all the terminal management, system monitoring, control, error detection, and maintenance operations. -
Page 47: Powering On System
Operating BDU 7.2 Powering On System Use the power ON/OFF button on the BDU’s front panel. Wait for all LED indicators to turn green to indicate the system is completely powered up. 7.3 Making POTS Phone Call To make POTS phone calls, do as follows: 1. -
Page 48: Enabling Poe
1. Connect an Ethernet cable from the LAN Port 1 or LAN Port 2 on the back of the BDU to devices. The network connection is established automatically. 2. Use the following IP address to access the Intellian AptusLX Web page. • IP Address: 192.168.200.1 (Default) 3. -
Page 49: Activating Data Connection
7.5.1 Registering Device The device registration option is available only when you log in with the admin account (intellian). 1. Connect an Ethernet cable from the LAN Port 1 or LAN Port 2 on the back of the BDU to devices. The network connection is established automatically. -
Page 50: Activating Data Connection
FB250/Fleet One - Marine Satellite Communication System 7.5.2 Activating Data Connection When logging in with the admin account (intellian), all the service groups are displayed for devices including non-registered devices. Device registration is not required when you are logged in with admin account (intellian). -
Page 51: Using Grandstream Voip Phone Call
Operating BDU 7.6 Using Grandstream VoIP Phone Call Use the Grandstream VoIP phone to make VoIP phone calls. Recommended VoIP Phones • Grandstream GXP16 Series: 1610, 1615, 1620, 1625, 1628, 1630 • Grandstream GXP17 Series: 1760, 1780 • Grandstream GXP21 Series: 2120, 2130, 2135, 2140, 2160, 2170 •... - Page 52 FB250/Fleet One - Marine Satellite Communication System 4. Go to Account > Account 1 > General Settings. 5. According to the AptusLX setting, enter the values for General Settings. 192.168.0.1 AptusLX VoIP Phone Enter the values according to the AptusLX setting The engineer needs to remember the default IP (SETUP >...
- Page 53 Operating BDU AptusLX VoIP Phone Go to SETUP > Phone/PABX. Extension 10X Input values for Account Name / SIP User ID / (ex.101,102) is used for analog phones. For VoIP Authenticate ID / Name / Voice Mail Access phones, used Extension 20X to assign desired Number according to the AptusLX setting.
-
Page 54: Using Wireless Devices Through Wi-Fi
2. Connect an Ethernet cable from any LAN ports (Port 1~ Port 4) on the back of the BDU to the LAN port of PC. The network connection is established automatically. 3. Use the following IP address to access the Intellian AptusLX Web page. • IP Address: 192.168.0.1 (Default) 4. -
Page 55: Using Mobile Phone Call
Operating BDU 7.8 Using Mobile Phone Call 7.8.1 Installing Mobile Application To be able to use a mobile phone call you must install a compatible mobile application. Intellian recommends using the following mobile application: Grandstream Wave App • App Store: https://apps.apple.com/us/app/grandstream-wave/id1029274043?ls=1 •... -
Page 56: Setting Mobile Phone
7.8.3 Setting Mobile Phone Using Grandstream Wave App (Recommended) through Mobile Phone To make a call on your mobile phone, Intellian recommends using the Grandstream Wave app. Follow the steps below to set up your mobile phone. • Account Name: My phone 201 •... -
Page 57: Chapter 8. Using Aptuslx
Using AptusLX Chapter 8. Using AptusLX 8.1 Introduction With the embedded AptusLX software, the antenna can be monitored, controlled, and diagnosed remotely, anytime through the TCP/IP protocol. It saves your time and cost generated by various maintenance activities such as operating firmware upgrades, tracking parameter resets, and system diagnosis, etc. 8.2 Accessing Internal Webpage of BDU The network is automatically configured by DHCP with no additional PC IP configuration. -
Page 58: Login
FB250/Fleet One - Marine Satellite Communication System 8.3 Login The Intellian software Aptus provides different user access levels to protect the system for safe operation. Depending on the user access level, the accessible range of functions in the software can be limited. -
Page 59: Top Menus
Using AptusLX 8.4 Top Menus Once you log in, the following information and menus are displayed. The overall state of the system is always displayed in the top menu. Item Description Displays the status of the satellite network connection. • Off: The system has not detected the Satellite network. •... -
Page 60: Account Menu
Disconnect Button Data connections. ⑪ Select the Intellian button to manage your account details and select the Account Button Logout menu to log out of the AptusLX web page. 8.5 Account Menu Click the Intellian button to manage the user account. -
Page 61: Logout
Click the Apply button to set the password to the new password. For the next login, the new password is required. If you have forgotten your ID and/or password, you can reset depending on your account level. The admin account (intellian) allows you to reset the guest ④ Reset ID/ account (guest). -
Page 62: Dashboard
FB250/Fleet One - Marine Satellite Communication System 8.6 Dashboard The Dashboard menu is displayed as below to provide quick monitoring of the antenna status. The Dashboard helps you arrange panels on a single screen while providing you with a broad view of a variety of information at once. -
Page 63: Satellite Data Connection Control
Registration menu, ‘Unregistered device’ is you are logged in with admin account displayed and the data cannot be used. For (intellian). Activate the data connections on device registration, refer to the “7.5 Activating the dashboard with the activation buttons to Data Connection”... -
Page 64: Satellite Connection Statistics
FB250/Fleet One - Marine Satellite Communication System 8.6.2 Satellite Connection Statistics Description Displays Satellite Connection Statistic. You can check Incoming/Outgoing usage for satellite call and each profiles usage for satellite data. When logging in with the admin account When logging in with a guest account (guest);... -
Page 65: Status
Using AptusLX 8.7 Status This menu displays the Network, Wi-Fi, Phone/PABX, Data, USIM, Terminal Info, and External GPIO function. 8.7.1 Network NOTE Item Description ① Network Displays the information about a network and ports. Displays the network information in use. •... -
Page 66: Wi-Fi
FB250/Fleet One - Marine Satellite Communication System 8.7.2 Wi-Fi Item Description ① Wi-Fi Displays Wi-Fi access information. Displays the Wi-Fi access point configuration. • Status: Displays the Wi-Fi status (Active / Inactive). • SSID: Displays the SSID network name. • MAC Filter: Displays the MAC address filtering status (Enabled/Disable). -
Page 67: Phone/Pabx
Using AptusLX 8.7.3 Phone/PABX Item Description ① Phone/PABX Displays the phone and Private Automatic Branch Exchange (PABX) status. Displays the extension number and details. • Extension: Displays the registered extension. ② Extension • Inbound Line: Displays the inbound line in use through the blue indicator. Management •... -
Page 68: Data
FB250/Fleet One - Marine Satellite Communication System 8.7.4 Data Item Description ① Data Displays the data setting status. Displays the data route status (Routing Policy, Satellite Link, WAN Link). ② Routing This Wan Link menu is not available for Fleet One model. -
Page 69: Usim
Using AptusLX 8.7.5 USIM NOTE Item Description ① USIM Displays information about the USIM card. Displays the USIM card information in use. • Connected: Displays the connection status of the USIM card. The USIM must ② be inserted. Configuration • IMSI: Displays a unique identifier to the USIM card. •... -
Page 70: Terminal Info
FB250/Fleet One - Marine Satellite Communication System 8.7.6 Terminal info Item Description ① Terminal info Displays the system terminal information. ② Displays BDU information in use. ③ Displays ADU information in use. ④ Modem Displays the modem information in use. -
Page 71: Setup
Using AptusLX 8.8 Setup This menu sets and displays the Network, Wi-Fi, Firewall, Phone/PABX, Data, Satellite, SMS, Service Profile, Service User Group, Device Registration, Traffic Flow Template, USIM, External GPIO, Restricted Dialing, Multi Voice, NSD, and MST function. 8.8.1 Network NOTE Item Description... -
Page 72: Wi-Fi
FB250/Fleet One - Marine Satellite Communication System 8.8.2 Wi-Fi Item Description ① Wi-Fi Sets the Wi-Fi access information. Sets the Wi-Fi access point configuration. • Activate: Sets the Wi-Fi function by toggling the activation button (Enabled/ Disabled). • SSID: The SSID is the network name shared among all devices in a wireless network. -
Page 73: Firewall
Using AptusLX 8.8.3 Firewall Item Description ① Sets the firewall, network security system, which monitors and controls Firewall incoming and outgoing network traffic based on predetermined security rules. Sets the firewall configuration. • Activate: Sets the firewall function by toggling the activation button (Enabled/ Disable). - Page 74 FB250/Fleet One - Marine Satellite Communication System Creating Firewall Rules (Example): To block www.youtube.com, 1. Click the Add( ) button. On the pop-up window, enter the settings. Click the Update button to save. Enter each value accurately as the following.
- Page 75 Using AptusLX 3. Try to open www.youtube.com on your web browser. Once applied, the user will not be able to access the website. 4. Make sure you can open websites other than www.youtube.com.
-
Page 76: Phone/Pabx
FB250/Fleet One - Marine Satellite Communication System 8.8.4 Phone/PABX Item Description ① Phone/PABX Sets the phone and Private Automatic Branch Exchange (PABX). Sets the extension number and details. • Edit( ) button: To edit the registered extension, click the Edit( ) button. -
Page 77: Data
Using AptusLX 8.8.5 Data Item Description ① Data Sets the data settings. Selects the Routing Config (None, Satellite Only, WAN Only). ② Routing Config Click the Apply button to apply the settings to the system. This function is available in the WAN Only mode of the Routing Config. Sets the WAN Link configuration. -
Page 78: Satellite
FB250/Fleet One - Marine Satellite Communication System 8.8.6 Satellite Item Description By the satellite setup, the terminal automatically finds and connects to the most ① Satellite appropriate satellite in the default mode. In an area available with multi BGAN satellites, select a satellite to use for the registration on the BGAN network. -
Page 79: Sms
Using AptusLX 8.8.7 SMS Item Description The BGAN system provides a Short Messaging Service (SMS) for sending and ① receiving SMS messages (Standard 3G, up to 160 characters per SMS) to and from the terminal. All received SMS messages are stored in the inbox. Unread messages are marked with a New icon. - Page 80 FB250/Fleet One - Marine Satellite Communication System Sending SMS message 1. Click the Sender number field in the list of SMS Inbox. Then the pop-up window is opened. 2. Type in the message in the Message field (Standard 3G, up to 160 characters per SMS). Check the number of written characters counted under the message field.
-
Page 81: Service Profile
Using AptusLX 8.8.8 Service Profile Item Description A profile includes Quality of Service (QoS) settings and other which define the data transmission mode on an interface. For example, a profile defines whether the traffic class should be a Background or Streaming. •... - Page 82 FB250/Fleet One - Marine Satellite Communication System Item Description Displays information of predefined service profiles. When you set up a service user group, you select the profiles to use. Select one primary profile and one secondary (optional) profile for the service user group.
-
Page 83: Service User Group
Inmarsat BGAN network. Group NOTE: For FB250, the maximum Streaming bit rate is 128 kbps. Displays the service user group list and information. • Edit( ) button: To edit the profile, click the Edit( ) button. Then the pop-up window is opened. -
Page 84: Device Registration
FB250/Fleet One - Marine Satellite Communication System 8.8.10 Device Registration Item Description ① Device Register the MAC address of the device for using the data service, and assign a Registration service user group to the device. Displays device registration list and information. -
Page 85: Traffic Flow Template (Tft)
Using AptusLX 8.8.11 Traffic Flow Template (TFT) Item Description By the Traffic Flow Template (TFT), set up each type of traffic differently for the best performance. When you need more than one type of traffic, use both primary and secondary ①... -
Page 86: Usim
FB250/Fleet One - Marine Satellite Communication System 8.8.12 USIM NOTE Item Description ① USIM Sets the use of a PIN to access the terminal. Select Enabled or Disable to use a PIN. • Enable: You must enter a PIN before you can change settings or make calls or data sessions. -
Page 87: External Gpio
Using AptusLX 8.8.13 External GPIO Item Description ① Select the external General Purpose Inputs/Outputs (GPIO) settings from the External GPIO drop-down list. ② Inputs Select the input settings from the drop-down list. ③ Outputs Select the outputs settings from the drop-down list. -
Page 88: Restricted Dialing
FB250/Fleet One - Marine Satellite Communication System 8.8.14 Restricted Dialing Item Description ① Restricted Set up the terminal for restricted dialing. Dialing Set whether to use restricted dialing or not (Enable/Disable). ② Restricted Dialing Click the Apply button to apply the settings to the system. -
Page 89: Multi Voice
Using AptusLX 8.8.15 Multi Voice This function works for FB250 depending on network availability. It is not available for the Feet One model. Item Description This function is not available for Fleet One model. ① For each FB system, the BGAN normally supports one call at a time. If you wish... -
Page 90: Nsd
FB250/Fleet One - Marine Satellite Communication System 8.8.16 NSD This function is available in the Satellite Only mode of the Routing Config. Item Description This function is available in the Satellite Only mode of the Routing Config. Set the Routing Config in the “8.8.5 Data” on page 77. -
Page 91: Mst
Using AptusLX 8.8.17 MST Item Description The Maritime Safety Terminal (MST) performs all mariner interactions with ① the Maritime Safety Data Service (MSDS), including the processing of vessel generated Distress Alerts that are initiated by the dedicated distress button. Sets the maritime service function. •... -
Page 92: Tools
FB250/Fleet One - Marine Satellite Communication System 8.9 Tools This menu sets and displays the Software Upgrade, Backup & Restore, Reset, Logs, Diagnostic, and Support function. 8.9.1 Software Upgrade Item Description ① Software Upgrades antenna software firmware. Upgrade Browse and select the package firmware file to upload and click the Upload button. - Page 93 Using AptusLX Package Firmware Update Procedures: 1. Browse and select the upgrade package file to upload. Click on the Upload button to transfer the Firmware package file (*.bin) to the BDU module. 2. The antenna firmware state will appear in the pop-up window. Check the current version and the new version.
-
Page 94: Backup And Restore
FB250/Fleet One - Marine Satellite Communication System 8.9.2 Backup and Restore Item Description ① Backup and Backs up user configuration files to PC and Restores the antenna settings. Restore ② Saves user configuration files to PC. Click the Backup button to apply the Backup settings to the system. -
Page 95: Reset
Using AptusLX 8.9.3 Reset Item Description ① Reset Resets the antenna system and factory reset. ② Click the Reboot button to reset the antenna system. The user configuration is Reboot not reinitialized. ③ Click the Factory Reset button to initialize the antenna system. The user Factory Reset configuration is initialized. -
Page 96: Logs
FB250/Fleet One - Marine Satellite Communication System 8.9.4 Logs Item Description ① Logs Downloads the antenna log data. Displays the antenna log list. ② • Download Log File: Any log data (.tgz) within a month can be downloaded. Log Download... -
Page 97: Diagnostic
Using AptusLX 8.9.5 Diagnostic Item Description ① Diagnostic Executes antenna diagnosis test to check the antenna status. ② Hardware Test Sets the hardware test function by toggling the activation button (Active/ Mode Status Inactive). The activation button must be selected to the "Active" in the previous step. ③... -
Page 98: Support
FB250/Fleet One - Marine Satellite Communication System 8.9.6 Support Item Description ① Support Downloads the User Guide. ② Manual The user guide file (.pdf) can be downloaded. Click the Download button. -
Page 99: Chapter 9. Specification
GNSS GPS, GLONASS 1 ea, 2FF Push-Push type with locking User Authentication structure Ethernet for FB250 4 ea, RJ45 Female TCP/ IP Connection, including 2 Port PoE Ethernet for Fleet One 2 ea, RJ45 Female TCP/ IP Connection with 2 Port PoE... -
Page 100: Environmental Specification
FB250/Fleet One - Marine Satellite Communication System 9.2 Environmental Specification Test Intellian Standard Operational IEC-60945 (-25 °C to + 55 °C / Power On) IEC-60945 (-40 °C to + 80 °C / Powered On and Temperature (ADU) Survival a non-functional state) Storage IEC-60945 (-40 °C to + 85 °C / Power off) -
Page 101: Chapter 10. Warranty Policy
(3) YEAR of parts and TWO (2) YEAR of factory repair labor to return the system to its original operational specification. Warranty periods commence from the date of shipment from Intellian facility, or date of installation which is come sooner. Providing maximum 6 months Warranty additionally if submission of authorized form which is described installation occurs within 6 months from the shipment date. -
Page 102: Chapter 11. Appendix
FB250/Fleet One - Marine Satellite Communication System Chapter 11. Appendix 11.1 Appendix A. Tightening Torque Specification This table shows the recommended values of tightening torques. Bolt Size Tightening Torque (N-m) M2.5...
