Operating Instructions
10L Dehumidifier with WiFi
Model: GPDH480

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GPDH480 and is the answer not in the manual?

Questions and answers

Related Manuals for Goldair GPDH480

Summary of Contents for Goldair GPDH480

  • Page 1 Operating Instructions 10L Dehumidifier with WiFi Model: GPDH480...
  • Page 3 General Care and Safety Guide YOUR SAFETY IS IMPORTANT TO US. PLEASE ENSURE YOU TAKE NOTE OF THE INSTRUCTIONS AND WARNINGS OUTLINED IN THIS MANUAL. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by the utility.
  • Page 4 General Care and Safety Guide • Never use the appliance to dry clothes. • Always unplug appliance when not in use. • When the appliance has been unpacked, check it for transport damage and ensure all parts have been delivered. If parts are missing or the appliance has been damaged, contact the Customer Services Team.
  • Page 5 General Care and Safety Guide • The appliance must not be immersed in any liquids. • There are no user serviceable parts installed in the unit. • Do not place the unit in wardrobes or other enclosed spaces as this may cause fire hazards.

  • Page 6: Operating Your Dehumidifier

    Operating Your Dehumidifier...
  • Page 7 Operating Your Dehumidifier...
  • Page 8 Operating Your Dehumidifier Always choose a safe location for the dehumidifier, keeping in mind the safety precautions outlined. Ensure all packaging has been removed from the unit before use. Please follow the below instructions. WARNING: In order to avoid overheating or fire, do not cover the dehumidifier.

  • Page 9: Power Button

    Operating Your Dehumidifier POWER BUTTON • Press the 'Power' button to turn your dehumidifier ON and OFF. After turning unit OFF, the fan will continue to run for about 2 minutes to reduce the residual heat inside the unit. After 2 minutes, the fan and the louvre will automatically close and the unit will stop running.

  • Page 10: Fan Speed

    Operating Your Dehumidifier FAN SPEED When the unit is running, the air volume can be adjusted by pressing the Fan Speed button. • Turbo: The fan runs at high speed and the dehumidification is at the maximum capacity. • Normal: The fan runs at medium speed, the dehumidification is at normal capacity.
  • Page 11 WiFi • This dehumidifier is WiFi enabled, allowing full operation of your dehumidifier from the Goldair WiFi app. • Follow the instructions in this manual under the section titled 'WiFi – Downloading and Setting up App' for information on how to operate the unit via the Goldair app.

  • Page 12: Using Your Remote Control

    Operating Your Dehumidifier USING YOUR REMOTE CONTROL The settings on the remote control are similar to the control panel. Note: Ensure you always point the remote control at the LED light screen on the front of the unit. MODE: Change settings POWER : Turn unit on/off between SMART/HEATER/DEHUMIDIFIER...

  • Page 13: Tank Full Indicator

    Operating Your Dehumidifier TANK FULL INDICATOR When the tank is full, the unit will stop running, and the Full indicator light will flash. Grip the tank by its handles and carefully pull out. Empty the water tank and reinsert it into the dehumidifier. The tank must be in place and securely seated for the dehumidifier to operate again.
  • Page 14 Download Goldair mobile APP • Open the APP Store or Google Play on your mobile phone. • Open 'Search' and enter 'Goldair' • Click 'GET' and begin to download and install. Once downloaded to your phone open the APP •...
  • Page 15 Pairing APP to Dehumidifier • On your phone tap 'Add Device' to connect to the dehumidifier. • Press the 'MODE' button on the control panel for 5 seconds until the ‘SMART’ LED light starts rapidly flashing. • Tap 'Confirm indicator rapidly blink' on your phone. •...
  • Page 16 Operating your dehumidifier from the APP Dehumidifier operation screen Device settings ON/OFF switch Change target humidity settings Change fan speed Change between dehumidify, heater and fan mode. Turn Swing/ air flow setting ON and OFF Current humidity Turn lamp ON and OFF Current temperature Turn UV setting ON and Turn Anion setting...
  • Page 17 Review device information Submit feedback Remove device from app Share device with family member: • The person you add will need to have the Goldair APP installed on their phone. • Enter your family member's details to share device operation with them.
  • Page 18 Operating your Dehumidifier from the APP Group your devices: Devices within the same group can be controlled simultaneously • Under 'Create Group' setting, select all devices you wish to group together. Click 'Save' • Enter a group name of choice. Click Save. You can now operate all devices within this group simultaneously.
  • Page 19 Operating your Dehumidifier from the APP Device is Off Device is On 'Fan Speed' icon 'Target Humidity' icon 'Mode' icon Dehumidifier Operation Screen • Tap the 'ON/OFF' icon to operate power Target Humidity Function • Tap the 'Target Humidity' Icon to amend the humidity setting. Choose between 30-80%. This function only operates in Dehumidity mode.
  • Page 20 Operating your Dehumidifier from the APP Anion Function • Tap the 'Anion' icon to turn ON or OFF. Anions or negative ions have strong absorption capabilities to absorb micro particles in the air to remove dust and bacteria. Lamp function •...
  • Page 21 Operating your Dehumidifier from the APP Schedule function The schedule in the APP has far more functionality than the dehumidifier control panel buttons. • Tap 'Schedule' icon to set schedule and timer functions Schedule edit screen 'REPEAT' icon 'POWER' icon Schedule edit screen Schedule main screen •...

  • Page 22: Safety Devices

    Operating Your Dehumidifier SAFETY DEVICES This appliance has two protection devices: • Resettable Thermal Link - this will automatically disconnect the power to the appliance at a pre-set overheat temperature. After cooling down it will reset and power on again. If this occurs, investigate what is causing the appliance to overheat. •...

  • Page 23: Caring And Cleaning

    Caring and Cleaning CARE AND CLEANING CONTINUED… • The water tank should be cleaned every few weeks to prevent growth of mould, mildew, and bacteria. • Partially fill the tank with clean water and add a little mild detergent. Swish it around and then empty the tank and rinse.

  • Page 24: Troubleshooting

    Unplug the unit and allow the temperature to rise. PROOF OF PURCHASE To receive warranty retain receipt as proof of purchase. TECHNICAL SPECIFICATION Model No: GPDH480 Supply: 220-240VAC 50Hz Max Rated Input Power: 710W Unit Capacity: 10L/day max (20°C/60%RH) Water Tank Capacity: 6.5L...

  • Page 25: Three Year Warranty

    In non-domestic use Goldair limits the voluntary warranty to three months. Goldair undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault during the warranty period.
  • Page 28 New Zealand PO Box 100707, North Shore Mail Centre, Auckland, 0745 www.goldair.co.nz Australia PO Box 574, South Morang, Victoria, 3752 www.goldair.com.au...

This manual is also suitable for:

Platinum gpdh480
