SE046713043E Ver.ppt11E
CONTENTS
● FEATURES and SPECIFICATIONS.................................2,3
● OPERATION ....................................................................3,4
● CONNECTORS ..................................................................5
● SYSTEM CONFIGURATION ..............................................6
● BLOCK DIAGRAM ..............................................................7
● DISASSEMBLING PROCEDURES ............................. 8~13
● PARTS LIST.................................................................14,15
● ELECTRICAL PARTS LIST........................................ 16~27
● SCHEMATIC DIAGRAM
PCB-MAIN ..............................................................34,35
PCB-PANEL.................................................................36
PCB-MONI ..............................................................37,38
● VOLTAGE .........................................................................39
● WAVEFORM .....................................................................40
MITSUBISHI MOTORS
SERVICE MANUAL
RSE (Rear Seat Entertainment)
MITSUBISHI ELECTRIC CORP. SANDA WORKS
ED-330BE-R1,-WS
Model :
MELCO Code : 3AB241,250
PART No. : 8750A291YA, MZ360424EX
Copyright (C) Mitsubishi Electric Corporation.
ED-330BE-R1,-WS
2013 Oct.
Your company internal use only.
