VX-3X08-BU(S)
VX-3108-BU(S), VX-3208-BU(S)
User Guide
V 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VX-3 08-BU Series and is the answer not in the manual?

Questions and answers

Summary of Contents for AEI VX-3 08-BU Series

  • Page 1 VX-3X08-BU(S) VX-3108-BU(S), VX-3208-BU(S) User Guide V 1.0...
  • Page 2: Package Contents

    1 Over view The SIP BYOD master is an SIP telephone to Wi-Fi connection adaptor that provides voice communication. Read this QIG carefully to learn how to operate this product and take advantage of its features. Package Contents When unpacking the device, ensure all the following items are present and undamaged. If anything appears to be missing or broken, contact your dealer for a replacement.
  • Page 3 Name Description Function keys HOLD (2 line only) Press to put an active call on hold. MUTE (single line only) Press to mute MIC. Press to access dialing instructions. VOLUME Press to increase or decrease the volume of the ringer tone, handset, or the volume of the current call.
  • Page 4: Connecting The Phone

    Connecting the Phone The following illustration shows how to install the handset and battery. 3. Web Configuration Web Login To setup the VX-3x08 handset from web configuration manually, boot the handset to the AP mode. Please remove the phone battery, press and hold the red button , and then install the battery.
  • Page 5 WIFI Setup the Wi-Fi SSID, Password and the IP type. WIFI SSID: The WIFI SSID WIFI PASSWORD: The WIFI Password WIFI IP Type: Default is DHCP. VoIP Setup the SIP account Switch: Check “Enable” to enable SIP registration or “Disable” to disable the SIP account temporarily.
  • Page 6 Authentication Name: Authentication Name is for SIP authentication. Password: Password of the SIP account Register Domain: FQDN, SIP domain name or IP address of the SIP server For example, voip.aeicommunications.com or 172.8.12.11 Register IP: IP address of the SIP Server If the listening port of the SIP Server is different from 5060, please add the port to at end of address.
  • Page 7: Speed Dial

    Speed Dial SPEED DIAL 1 ~ 7: 7 scrollable service keys. SPEED DIAL 8 ~ 10: the physical hard service keys from left to right respectively. System Server: The IP address information of the server, for example, 192.168.1.54. The phone will retrieve the .cfg file.
  • Page 8: Quick Commands

    To upgrade the phone firmware. Parturition Upgrade ˙ To upgrade the phone User Interface. Information ˙ To display the phone information. Factory Rest ˙ To reset phone to factory default. Pair Mode ˙ To connect VX handset to other AEI Wi-Fi master phone.
  • Page 9 5. Operations Answering a Call An incoming call is indicated by a ringing tone and a flashing indicator at the top of handset. You can answer the call by doing the followings: Press the LINE (LINE1/LINE2) key on the handset to answer the call. Making a Call Press LINE key will see all dialing description for this phone set.
  • Page 10: Record Of Revision

    Record of Revision Date Ver. Description 2022/6/14 First issue...
