ViewStation FX Display Troubleshooting

Display Options

Troubleshooting the VGA Output Display

© 2002 Polycom, Inc.
There are several display options available while using Visual
Concert FX in a point-to-point call, depending on monitor
configuration:
Monitors
One monitor
Two monitors
Three monitors
Four monitors
VGA connected to ViewStation FX
VGA connected to Visual Concert FX

VGA Input Calibration

Visual Concert FX automatically analyzes the input signal from your
computer and calibrates the VGA output for optimal display
characteristics. In some rare instances, it may be necessary to
calibrate the VGA input of the Visual Concert FX unit.
To calibrate the VGA input from the Visual Concert FX unit, go to the
ViewStation FX VGA Input Calibration screen (System Info>Admin
Setup>Video/Camera>VGA Input) to manually adjust the following
calibration parameters:
Phase
Visual Concert FX Display
Main monitor
Monitor two
Monitor two
Monitor two
FX VGA monitor
Visual Concert FX VGA monitor
The Phase option provides subtle phase
adjustment. Adjust this parameter if your
display appears slightly out of focus
when showing extremely fine images.
