Page 1: Parts List
PARTS LIST Model 2623 (120V/230V) ISSUE: Dec. 2001... - Page 2 Parts No. Name of Parts 986001 Arm 986004 Face plate 000 081 706 +- Binding head screw 4*I4 (cr) 986005 Cutter (1) 986006 Cutter (2) 000 082408 +- Binding head screw 3*6 000 087908 T screw 3*8 986002 Front plate 000 082202 +- Binding head screw 3.5*8 986127 Detachable foot 11 000 010 003 Rapid nut M4*0.7...
- Page 3 Parts No. Name of Parts 986007 Front plate 986008 Spool 986014033 Bobbin cover plate (small) 986013032 Bobbin cover plate (big) 986015 Handle 321143000 Bobbin winder stopper 000081603 +- Binding head screw 4*12 000 071 105 Hexagon nut 4-3-7 986009 Spool pin 986010 Bobbin winder regulate lead shaft 986011 Threading guide 986047 Threading guide spring...
- Page 4 22 000 080 901 Flat head screw 3*6 986033 Presser regulate crank (A) 986034 Presser regulate crank (B) 986031 Presser regulate dial 986032 Presser regulate dial spring 730118 Feed lifting spring bracket D:\SHARON\986-1\986ed-1 2623 Parts No. Name of Parts 986160 Lamp cover (120v) 03/14 3D-03/12...
- Page 5 Parts No. Name of Parts 986040 Zigzag regulate (3D) 986044 Regulate spring 986041 Zigzag crank (3D) 986043 Zigzag regulate nut 000081304 +- Binding head screw 4*6 986042 Regulate base 000 001 207 Snap ring E-4 000 081 407 +- Binding head screw 4*8 986035 BH connecting crank base 986036 BH connecting crank spring 11 000 081 304 +- Binding head screw 4*6...
- Page 6 Parts No. Name of Parts 000 079103 Hexagon socket screw 4*4 986051 Needle bar crank supporter shaft 986050 Needle bar crank supporter 000 001 207 Snap ring E-4 730096 Needle bar crank pin 730102 Through thread body spring 986054 Through thread body 730103 Through thread bar spring 986055 Through thread bar 10 000 006 914 Spring pin 2*12...
- Page 7 Parts No. Name of Parts 000 082 408 +- Binding head screw 3*6 986045 Thread rgulator base 000081407 +- Binding head screw 4*8 868060 Thread tension regulate flat (L) 868059 Middle plate 868060 Thread tension regulate flat (r) 868138 Washer 5.6*l5*l 730110 Thread tension connecting plate 868113 Spring set position plate 868115 Thread tension regulate spring...
- Page 8 Parts No. Name of Parts 218023 Bobbin 730155 Bobbin case magnet 730024 Bobbin regulate plate 730025 Bobbin regulate spring 730149 Bobbin case 730173 Regulate screw (2) 730172 Regulate screw (1) 730168 Oil core 730143 Hook race shaft 730144 Hook race 000 087012 T screw 3*8 730150 Bobbin case set stop plate 730142 Hook race cover...
- Page 9 Parts No. Name of Parts 986637 Thread take-up complete (986158) 281146005 Needle bar connecting rod 730098 Needle bar crank pin 10 321 031 004 Thread take-up crank 574057006 Set screw SM15/64-28*4 101 040008 Set screw SM15/64-28*6.5 13 000 006 408 Spring pin 3*20 14 000 001 310 Thrust washer 13*20*0.25 868003 Upper shaft bushing 986061 Handle bracket...
- Page 10 Parts No. Name of Parts 986067038 Feed regulate dial 730111 Pin 000 079000 Hexagon socket screw 3*4 986504 Regulate dial plate 000 081 407 +- Binding head screw 4*8 986072038 Zigzag regulate dial 000 001 207 Snap ring E-4 986063 Clutch rod 730037 Clutch rod spring 986074 Zigzag shrapnel 266009009 Screw M3*O.5*6...
- Page 11 Parts No. Name of Parts 730122 Lower shaft ring 000 079103 Hexagon socket screw 4*4 000 013 430 Thrust washer 8.2*l2*0.25 730123 Lower shaft bushing 730124 Lower shaft bushing plate 000 081 407 +- Binding head screw 4*8 730113 Feed lifting cam 730115 Feed lifting connecting spring 730121 Lower shaft gear 000 079309 Hexagon socket screw 5*5...
- Page 12 Parts No. Name of Parts 730138 Feed dog base crank 986076 Feed rock shaft 168105 Feed dog base 168100 Feed dog 000 082408 +- Binding head screw 3*6 730139 Feed dog spring 730117 Feed lifting crank 730171 Screw 000 071105 Hexagon socket nut 4-3-7 10 000 001 207 Snap ring E-4 11 000 002 404 Snap ring CS-4.5 281 040009 Plain washer 5.1*7.3*0.5...
- Page 13 Parts No. Name of Parts 986 121 Pattern show shaft 000 001 300 Snap ring E-5 730 219 Pattern selector gear 000 079 000 Hexagon socket screw 3*4 986 116 Base (Front) 000 071 105 Hexagon nut 4-3-7 986 093 Control crank shaft 986 092 Control crank 986 095 Pattern selector crank holder 000 082 501 +- Pan head screw 3*8...
- Page 14 000 081 407 +- Bbinding head screw 4*8 986136 Switch box base 000 087300 +- Binding head T screw 3*12 986133 Switch show plate (120v) 986134 Switch show plate (230v) D:\SHARON\986-1\986ed-1 美國 2623 Parts No. Name of Parts Motor 13/14 3D-03/12...
- Page 15 986013032 Spool pin cap (large) 321405025 Oiler 32l406015 Buttonhole opener with brush 321403012 Screwdriver (large & small) 4C-335B Foot control (120v) YC-190 Foot control (230v) Book C-013 Soft dust cover 730010012 Spool pin D:\SHARON\986-1\986ee-1 2623 美國 Parts No. Name of Parts 12/13 14/14 3D-03/12...
