- Page 1 WOOD CHIPPER BE-WCGR3XXX OPERATIONS & PARTS MANUAL FOR MODELS: • BE-WCGR3R65 • BE-WCGR3H65 PURCHASE DATE MODEL NO. SERIAL NUMBER DEALER 102.105B MANUAL CODE:...
- Page 2 INDEX Warning symbols Features, Specifications & Safety Assembly Knife Removal and Replacement Operation Transporting, Storage & Maintenance Trouble Shooting Exploded View & Parts List BE-WCGR3xxx USER MANUAL...
-
Page 3: Warning Symbol
WARNING SYMBOL WARNING: This is the warning symbol to get your high attention for the instruction notice, which should be followed to avoid the potential serious personal injury. Anyone to use this equipment should read all the instructions of this manual. Keep this instruction manual for future reference. Do not allow children to operate this wood chipper. -
Page 4: Specifications
FEATURES Discharge chute Engine In-feed Bin Body SPECIFICATIONS ITEM NO. WCGR3R65 Chipping Capacity Max. 3” Chipping Knives Reduction Rate 15:1 Wheel Size (IN) 13x5 Wheel Material Rubber Wheel Type Pneumatic Gross Weight (LB) Assembled Dimension (IN) 72.5x28.3x42.4 Packing Dimension (IN) 33.5x27.6x45.3 SAFETY LABELS BE-WCGR3xxx USER MANUAL... -
Page 5: General Operating Safety
GENERAL OPERATING SAFETY 1. Read, understand, and follow all instructions in the manual and on the unit before starting 2. Locate the Chipper on a flat, level, sturdy surface capable of supporting the weight of the Chipper and any additional tools and equipment. 3. - Page 6 spark plug. Wait for 5 minutes for the machine to cool down. Inspect the unit for any signs of damage or foreign material in the chipping or shredding areas. Remove any solid material that may be preventing the unit from operating properly. •...
- Page 7 Gasoline Fires and Handling Fuel Safely Use extra care in handling gasoline and other fuels. They are flammable and vapors are explosive. 1. When storing extra fuel be sure that it is in an appropriate container and away from any fire hazards. 2.
-
Page 8: Unpacking The Container
UNPACKING THE CONTAINER Remove the wooden plate in the top. At least two people hold up the package and move it from the top. ASSEMBLY Install the Wheels(See Figure 1) 1. Put the wheel (A) onto the axle (B), Make sure the wheel disc flat side faces the machine. - Page 9 Install the Discharge chute (See Figure 3) 1. Install the discharge chute (A) with the engine base by using M8x16 bolts (B) and Spring washer (C) and Flat washer (D) to tighten. Figure 3 Install the Handwheel (See Figure 4) 1.
-
Page 10: General Operation
KNIFE REMOVAL AND REPLACEMENT This chipper shredder is equipped with two chipper knives mounted on the cutting disk. When the knives get dull or show visible nicks, the machine will lose its self- feeding action and the material has to be pushed in. - Page 11 Operation Location 1. Select an area with firm, level ground, covered by dirt or grass. 2. Do not operate on wet or slick surfaces, or near bystanders. 3. Locate and organize the materials to be processed so that you don’t have to walk in front of the inlet or discharge openings, and so you have adequate room to work safely.
-
Page 12: Transporting And Storage
TRANSPORTING AND STORAGE 1. Always observe safe refueling and fuel handling practices when refueling the unit after transportation or storage. 2. Never store the unit (with fuel) in an enclosed poorly ventilated structure. Fuel vapors can travel to an ignition source (such as a furnace, water heater, etc.) and cause an explosion. Fuel vapor is also toxic to humans and animals. - Page 13 Engine Maintenance Refer to the engine manual included in your package for information on engine maintenance. Your engine manual provides information and a maintenance schedule for performing the following tasks: 1. Always check oil level before starting engine. Refer to engine manual for capacity and type of oil to use. 2.
-
Page 14: Troubleshooting Chart
TROUBLESHOOTING CHART 1. While normal care and regular maintenance will extend the life of your equipment, prolonged or constant use may eventually require that service be performed to allow it to continue operating properly. 2. The troubleshooting guide below lists the most common problems, their causes, and remedies. 3. - Page 15 EXPLODED VIEW & PARTS LIST 27、28 46、47 12 13 BE-WCGR3xxx USER MANUAL...
- Page 16 PARTS LISTS BE-WCGR3R65 NO. DESCRIPTION PART# NO. DESCRIPTION PART# Circlips 102.105B.100 Bolt M8x25 102.105B.124 Wheel 102.105B.101 Side cover 102.105B.125 Flange nut M8 102.105B.102 Bearing cover 102.105B.126 Belt cover 102.105B.103 Bearing cover plate 102.105B.127 Bolt M8x16 102.105B.104 Box cover (Only apply on 102.105B.128 electric start engine) Key parallel pin...
- Page 17 BE-WCGR3xxx USER MANUAL...
- Page 18 B RA B E R EQ .CO M WGSALES@BRABEREQ.COM PHONE: 604-850-7770 FAX: 604-850-7774 TOLL FREE PHONE: 1-877-588-3311 TOLL FREE FAX: 1-800-665-7334 BE-WCGR3xxx USER MANUAL...
