1
Description of the ThermaCheck M1 Series camera ............................................................................................. 2
2
What's in the Box .................................................................................................................................................. 2
3
Initial Setup ........................................................................................................................................................... 3
4
Display Features .................................................................................................................................................... 4
5
User Interface Functions ....................................................................................................................................... 5
5.1
System settings and information ............................................................................................................ 5
5.2
Interactive calibration function ............................................................................................................ 5
5.3
Mask Detection ..................................................................................................................................... 7
5.4
Screening Capture History ..................................................................................................................... 7
5.5
Temperature Threshold Setting ............................................................................................................ 7
6
Temperature Screening Location .......................................................................................................................... 8
6.1
Typical Setups............................................................................................................................................... 9
7
Mounting Options ................................................................................................................................................. 9
8
Why doesn't ThermaCheck need a blackbody? .................................................................................................... 9
9
Can ThermaCheck be used to diagnose illness? ................................................................................................. 10
10
Thank you ............................................................................................................................................................ 10
(v1.3)
www.planckvisionsystems.com
TC160M1
User Manual
ThermaCheck
TM
M1
1
Advertisement
Table of Contents
Related Manuals for Planck VISION SYSTEMS ThermaCheck M1
Summary of Contents for Planck VISION SYSTEMS ThermaCheck M1
-
Page 1: Table Of Contents
TC160M1 User Manual ThermaCheck Contents Description of the ThermaCheck M1 Series camera ..................... 2 What’s in the Box ..............................2 Initial Setup ................................3 Display Features ..............................4 User Interface Functions ............................5 System settings and information ......................5 Interactive calibration function ......................5 Mask Detection ............................. -
Page 2: Description Of The Thermacheck M1 Series Camera
1 Description of the ThermaCheck M1 Series camera The ThermaCheck M1 Series camera uses AI software to identify and screen subjects for elevated body temperature and the presence of a facial mask. Realtime video of the screening subjects and screening results are displayed on a monitor connected to the camera through a standard HDMI interface. -
Page 3: Initial Setup
User Manual 3 Initial Setup Steps shown in Figure 3 may be followed for the initial setup of the ThermaCheck M1 camera. The camera head mounts to a 1/4-20" threaded screw (a standard for camera tripods). Typical mounting hardware for the ThermaCheck M1 camera is shown in Section 7. -
Page 4: Display Features
HDMI interface on the side of the camera head. Principle features of the ThermaCheck M1 display are shown in Figure 4. Features indexed in Figure 4 are described in Table 1. Figure 4: ThermaCheck M1 main display... -
Page 5: User Interface Functions
5 User Interface Functions Screening parameters for the ThermaCheck M1 camera may be set through the user interface when a mouse is connected to the USB port provided in the camera’s rear pig-tail. Access to settings are obtained by selecting, with the mouse, the appropriate display icon. - Page 6 TC160M1 User Manual 1) Procedure supports calibration on a human subject or blackbody, as selected with the radio button shown in Figure 7(a). 2) Enter the temperature of the calibration subject in the dialog box shown in Figure 7(a). The calibration subject should be at approximately the same distance from the camera as the screening subjects, as detailed in Figure 8.
-
Page 7: Mask Detection
TC160M1 User Manual Calibration subject Camera 3.5ft (1m) 13ft (4m) TC160M1 Human or Blackbody Figure 8: Calibration subject should stand at approximately the same distance from the camera as the screening subjects. Mask Detection Toggles the state of mask detection between: On - and Off - Screening Capture History The historical record of screening pictures can be reviewed. -
Page 8: Temperature Screening Location
6 Temperature Screening Location Preferred environmental conditions for the ThermaCheck M1 operation are 60 - 90˚F (16 - 32˚C) and less than 85% relative humidity. The best screening location will have a mostly dark indigo color in the background of the thermal image. -
Page 9: Typical Setups
Notes: The ThermaCheck M1 camera has great flexibility of installation options shown in Section 7. 7 Mounting Options The ThermaCheck M1 camera connects to a standard ¼”-20 thread, used by traditional cameras and mounting systems as shown in Figure 12. -
Page 10: Can Thermacheck Be Used To Diagnose Illness
Infrared Imaging: Principles and Practices. CRC press, 2007. 10 Thank you Thank you for purchasing a ThermaCheck M1 camera. We develop our products to deliver reliable, long lasting performance, and want to make sure you are satisfied with your purchase. For more product information visit www.planckvisionsystems.com, and feel free to get in touch with us at...
