SIGNATURE SERIES SUBWOOFER
INSTALLATION INSTRUCTIONS
Important Safety Information
WARNING
See the Important Safety and Product Information guide in the product box for product warnings and other
important information.
This device must be installed according to these instructions.
Disconnect the vessel's power supply before beginning to install this device.
CAUTION
Continuous exposure to sound pressure levels over 100 dBA may cause permanent hearing loss. The volume
is typically too loud if you cannot hear people speaking around you. Limit the amount of time you listen at high
volume. If you experience ringing in your ears or muffled speech, stop listening and have your hearing checked.
To avoid possible personal injury, always wear safety goggles, ear protection, and a dust mask when drilling,
cutting, or sanding.
NOTICE
When drilling or cutting, always check what is on the opposite side of the surface to avoid damaging the vessel.
It is strongly recommended that you have your audio system installed by a professional installer to ensure
optimum performance.
You must read all installation instructions before beginning the installation. If you experience difficulty during
the installation, go to
support.garmin.com
for product support.
After installing an audio system, you should run the connected speakers and subwoofers at low to medium
volumes for the first few hours of use. This helps to improve the overall sound by gradually loosening up the
moving components of new speakers and subwoofers, such as the cone, spider, and surround.
May 2022
GUID-D5444697-CFDC-4F43-AEA4-6835F0527D82 v2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FUSION SIGNATURE Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Garmin FUSION SIGNATURE Series

Summary of Contents for Garmin FUSION SIGNATURE Series

  • Page 1 You must read all installation instructions before beginning the installation. If you experience difficulty during the installation, go to support.garmin.com for product support. After installing an audio system, you should run the connected speakers and subwoofers at low to medium volumes for the first few hours of use.

  • Page 2: Tools Needed

    • Wire strippers • 12 AWG (3 through 4 mm ) or larger marine-grade, fully-tinned copper speaker wire You can purchase this wire from your Fusion ® or Garmin ® dealer: ◦ 010-12898-00: 7.62 m (25 ft.) ◦ 010-12898-10: 15.24 m (50 ft.) ◦ 010-12898-20: 100m (328 ft.) •...

  • Page 3: Mounting The Subwoofer

    Mounting the Subwoofer Before mounting the subwoofer, you must choose a location following the guidelines above. 1 Trim the template and make sure it fits in the selected location. 2 Orient the template so the Fusion logo is level. 3 Secure the template to the selected location. 4 Using a jigsaw or rotary tool, cut the mounting surface along the inside of the line on the template.

  • Page 4: Speaker Wiring

    It is the user's responsibility to comply with any such applicable laws, regulations, and standards. Garmin is not responsible for any fines, penalties, citations, or damages that may be incurred due to any such lack of compliance.
  • Page 5 Connecting the LED Wires Directly If you do not install the recommended remote control, you can set the static color of the LEDs by connecting the color LED wires from the harness to the negative (-) terminal of a 12 Vdc power source. You can splice the negative (-) wire to multiple LED wires to customize the LED color and tone.
  • Page 6 Wire Strain Relief NOTICE Failure to secure the wiring-harness connections can damage the speaker. The wires connected to the speaker and the included wiring harness use Amphenol AT Series connectors, and ™ ™ these connectors must be secured during installation to provide strain relief for the internal wire connections to the speaker.

  • Page 7: Specifications

    Specifications 10" Subwoofer Max. power 600 W RMS power 300 W Frequency response From 30 Hz to 2 kHz Sensitivity (1 W/1 m) 86 dB Impedance 4 ohms Nominal voice coil diameter 50 mm Min. mounting depth (clearance) 133 mm (5  in.) Mounting diameter (clearance) 223 mm (8  in.) Amplifier power-rating recommendation 50 to 400 W RMS, playing music Compass-safe distance 520 cm (205 in.)
  • Page 8 Dimension Drawings Side View Measurement 10" Subwoofer 12" Subwoofer 130 mm (5   in.) 204 mm (8   in.) 220 mm (8   in.) 303 mm (11   in.) A Sports model subwoofer is shown, but the dimensions are the same for the Classic model.
  • Page 9 Front View Measurement 10" Subwoofer 12" Subwoofer 275 mm (10   in.) 356 mm (14 in.) 247 mm (9   in.) 325 mm (12   in.) A Sports model subwoofer is shown, but the dimensions are the same for the Classic model. Optimum Enclosure Recommendations Specification 10" Subwoofer 12"...
  • Page 10 , the Garmin logo, Fusion ® , the Fusion logo, and True-Marine ™ are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. These trademarks may not be used without the express permission of Garmin. Amphenol ™...
