- Page 1 TRG808X SERIES 80GHz RADAR LEVEL METER Product Instructions WWW.DDTOP.COM 1 / 18...
- Page 2 This manual can be downloaded from www.ddtop.com. If you do not follow this manual, the protection provided by this instrument may be damaged.
- Page 3 Dandong Top Electronics Instrument (Group) Co., Ltd has passed the ISO9001 quality system certification. The entire production process is strictly implemented in accordance with the scope of the quality system, providing the strongest guarantee for the quality of products and services. WWW.DDTOP.COM 3 / 18...
-
Page 4: Table Of Contents
8.2 Measurement Interface ......................... 13 8.3 Echo Screen .............................. 14 8.4 Setup Screen ............................. 14 9 Precautions .................................. 17 10 Fault Analysis and Troubleshooting ........................ 17 11 Disassemble................................17 11.1 Warning ..............................17 11.2 Waste Disposal ............................18 WWW.DDTOP.COM 4 / 18... -
Page 5: Safety Tips
The distance from the antenna to the surface of the measured medium is thus calculated. 2.2 Packaging Please take your packaging waste to a special recycling facility. 2.3 Storage Storage temperature -20° C to 40° C Storage humidity ≤20% WWW.DDTOP.COM 5 / 18... -
Page 6: Technical Parameters
Accuracy: ± 1mm/± 1mm ± 3mm/± 5mm Beam angle: 3° /8° Output signal: 4 to 20mA + HART RS485+Modbus RTU Ambient temperature: -40℃～+70℃ IP rating: IP67 Housing material: Aluminum alloy Process temperature: -40～150℃ Process pressure: -0.1～2.5 MPa WWW.DDTOP.COM 6 / 18... -
Page 7: Explosion-Proof Signs
The connection flange is used in conjunction with the site flange, the user is required to provide the flange standard, if the order requires a special size, the actual size shall prevail - Figure 1 to Figure 5 WWW.DDTOP.COM 7 / 18... - Page 8 Figure 1 TRG8081 Normal tempe rature High tempe rature Figure 2 TRG8082 Connection flange Connection flange Small antenna Standard antenna Figure 3 TRG8083 WWW.DDTOP.COM 8 / 18...
-
Page 9: Unpacking And Inspection
Antenna Form： Connection Method： Ambient T emperature：-40~80℃（T1~T5）/-40~60℃（T6) Medium ： IP Rating：IP67 Operating Pressure： MPa Operating T emperature： ℃ Measurement Range： Tag No： Factory No： Factory Date： Dandong Top Electronics Instrument (Group) Co., Ltd Figure 6 Nameplate WWW.DDTOP.COM 9 / 18... -
Page 10: Check Content
For conical vessels with a flat tank top, the best mounting position for the instrument is in the center of the top of the capacity so that the bottom of the vessel can be measured - Figure. 8 WWW.DDTOP.COM 10 / 18... - Page 11 - Figure. 9 Figure 9 Damp-proof Wiring Schematic Diagram Container Receiver The length of the vessel receiver should be such that the end of the antenna extends into the tank as far as possible - Figure 10 WWW.DDTOP.COM 11 / 18...
-
Page 12: Electrical Wiring
Figure 11 4～20mA Wiring Diagram Output signal: RS485 Terminal 1: Connected to 24VDC negative. Terminal 2: Connected to 24VDC positive. Terminal 6: Connected to RS485 A. Terminal 5: Connected to RS485 B. WWW.DDTOP.COM 12 / 18... -
Page 13: Instrument Configuration
Damping value: The result of smoothing the real-time value through a damping filter. Temperature: Indicates the operating temperature of the internal components of the instrument. Version number: Displays the customer-defined product model number. Communication status: Heartbeat indication of the system communication status, 1S blinks WWW.DDTOP.COM 13 / 18... -
Page 14: Echo Screen
Due to the noise floor rising near the end of the FMCW itself, the echo strength and echo strength units are not necessarily the same. 8.4 Setup Screen Basic Setup Display Diagnosis Major Setup Figure 15 Diagram of the setup screen ESC 一 Access to the main screen WWW.DDTOP.COM 14 / 18... - Page 15 The [Blind Zone Setting] and the [Range Setting] together determine the area selected by the meter's internal echo algorithm. The algorithm will ignore echoes within the blind zone, so that interference from the near end can be avoided by this option. See the table below for details. WWW.DDTOP.COM 15 / 18...
- Page 16 After selecting "Select Area" or "Exclude Area", you need to further enter the area "Start" and "End" points. The menu is displayed as shown below: 虚假回波学习 虚假回波区域 False echo mode 新建 全程 开始 0.000 清零 选择区域 结束 0.000 排除区域 WWW.DDTOP.COM 16 / 18...
-
Page 17: Precautions
Processor hardware errors 0200 Abnormal temperature sensor 0400 Processor acquisition exceptions 11 Disassemble 11.1 Warning Before disassembling, pay attention to dangerous process conditions, such as pressure, high temperature, corrosive or toxic media in the container, etc. WWW.DDTOP.COM 17 / 18... -
Page 18: Waste Disposal
11.2 Waste Disposal Please follow the current regulations in each region for waste disposal. WWW.DDTOP.COM 18 / 18...
