Airtocheck RM-402T Quick Manual

Technical specifications
Dimensions: 33,5 cm. x 29 cm. x 14,5 cm.
Weight: 3,4 kg.
Electricity grid: 100-240V AC 50/60 Hz 25W
Temperature: 5 to 45 °C; non-condensing (in use)
Temperature: -20 to 60 °C; non-condensing (in storage)
Humidity: 10% to 80% relative humidity, non-condensing (in use)
Humidity: 10% to 90% relative humidity, non-condensing (in storage)
Waterproof: IP 54 (closed case)
Printer type: Thermal
Printer roll: Width 56 mm.; diameter 45 mm.
Printer resolution: 203dpi (8dots/mm)
Battery back-up: 7 hours maximum, depending on the number of channels used, use of printer and
accessories.
Pressure range: -40 / +1 Pascal
Display: 4.3" TFT 480 x 272, CTP
Internal memory: 4 days maximum, depending on the number of channels used.
Included: Manual, Adapter, 8 mm hose, SD-card, print roll
SMS feature: Yes (SIM card required)
Modem feature: Optional (SIM card with data subscription required for web-based version)
Communication: GSM/GPRS
SD storage: Yes
Memory capacity: Dependent on SD card capacity
Measuring points: 2 channels (RM-402T) or 4 channels (RM-404T)
Span accuracy: 3%
User alarm: Each channel 1 x high, 1 x low alarm
Connections: External horn Airtocheck
External relay block Airtocheck
8 mm hose connection
CE certification: Yes
Quick guide AIRTOCHECK monitor
RM-402T / RM-404T
