Summary of Contents for Fine Art FINE 1514 ZOOM
-
Page 2: Table Of Contents
Any future modification pertaining to content of this manual, there will be no particular notifications. FINE ART reserves all copyrights. To obtain the latest information about software update, hardware and other files, please visit FINE ART online website. -
Page 3: Safety Information
The following symbols are used to identify important safety information on the product and in this manual: - - -m Do not use the light under the harsh condition 1.Safety information WARNING! Read the safety precautions in this section before installing, powering, operating or servicing this product. - Page 4 Protection against explosion Shields must be replaced if they have become visible damaged to such an extent that their effectiveness is impaired. Protection against ultraviolet Prolonged exposure to an unshielded discharged lamp can case eye. Protection against injury due to falls To inspect that the structure and the truss hooks are in good condition and can bear about 10 times the weight of the fixture.
-
Page 5: Product Introduction
2.Product introduction 2.1 Fixture profile dimensions ●Front view Fig.(2.1-1) ●Side view Fig.(2.1-2) -
Page 6: Fixture Introduction
2.2 Fixture introduction Fig. (2.2-1) Fig.(2.2-2) Name Name Name Base assembly Display LED lens Head cover Clamp Power in Manual nut Safety cable hole Air vent LED cooling part Power out DMX in Base assembly DMX out Function button... -
Page 7: Package & Delivery
3.Package & delivery 3.1 Included Items FINE 1514 ZOOM/1514DG is pack with flight case or case or carton foam backing, 6pcs/case, 1pcs/carton. Included items listed below(shown as table 3.1-1): Accessories FINE 1514ZOOM FINE 1514DG UNIT User Manual Warranty card Clamp... -
Page 8: Installation
Make sure the installation check annually by professional person. FINE 1514 ZOOM / FINE 1514 DG can be put on stage floor or fixed on any brace or truss. Quick trigger locks can easily fix the fixture to mounting brackets shown as follows, Fig 4.1-1,4.1-2. -
Page 9: Datalink
Hang on the truss with clamps Safety cable contact Fig.(4.1-2) Please add one safety cable to the bracket. Warning 5.Tips for Data Link 5.1 DMX 512 for data transferring Note: The signal cable is type Y connection. Type Y connection—if the external flexible cable or cord of this fixture is damaged, it shall be replaced by a special cord or cord exclusively available from the manufacturer or his service agent. - Page 10 Terminator 3 pin XLR socket Terminator specification: DMX 512 a 120Ωresistor with a power (shielded wire) GND/OV of 0.25w, solderd between 2 red signal(-) pin 2 and pin 3 at the end of 3 white signal(+) respective data link. Fig(5.1-1) Connect the 3-pin output of a lighting controller to the 3-pin input of a first fixture on the link, then connect the 3-pin output of the said first fixture to the 3-pin input of a second fixture.
-
Page 11: Ac Power Supply
6.AC Power supply 6.1 Power Connection Notice:Type X attachment for power supply connection. Method of attachment of the cable or cord such that any replacement can only be made by the manufacturer, his service agent or similarly qualified person. The person must have the relevant qualification to connect the power supply. The AC power voltage shall be suitable to the lamp provided with over-loading or cree page protection.Connecting the equipment to the power supply, do not connect to silicon boxsystem, or else, it will destroy the equipment. -
Page 12: Control Panel Function Explanation
2 Display panel operational function detail Function detail ADDR IP Add:1-512 means DMX add 0-255 0-100% R Dimmer GREN 0-255 0-100% G Dimmer BLUE 0-255 0-100% B Dimmer WHIT 0-255 0-100% W Dimmer No function Color temperature,8000K to 2700K 1-255 No function MACR 10-255... -
Page 13: Technical Feature
8.Technical Feature 1Production feature explanation Light source: 15w×14LEDs (RGBW) Color temp: 2700K-8000K Input voltage: 100-240V~, 50/60Hz Input power: 190W Power Factor: PF≥0.98 Data connection: 3 pin XLR Control mode: DMX 512; master/slave control mode Optical system: 0-100% linear dimmer, electronic zoom (only for 1514 zoom) Operational interface: LED display Protection system: sensor detector, smart adjustment of power Cooling: natural convection air flow... -
Page 14: Control Channel
Soft light fading, slowly fast 1-255 No function Color cycling cycling, slowly fast 1-255 Dimmer 0-255 0-100% dimmer Spot size, small fast Zoom 0-255 ATTN: This channel is for FINE 1514 ZOOM. If for FINE 1514DG, “ZOOM”function is excluded. -13-... -
Page 15: Partscode
10.Parts Ordering 1514ZOOM Order P/N Ordering P/N Specification Item 一 120710000014 Front cover Full tempered glass 200710000009 一 200712000015 Zoom lens 一 Reflector 一 200712000016 LED board 330710100014 一 Temp switch 85±5° 290102000013 一 Cooling part 120710100011 Stepper motor 一 140102000098 Middle cover 一... -
Page 16: Attached1: Fine 1514 Zoom Fixture Exploded Drawing
Attached 1: FINE 1514 ZOOM fixture exploded drawing Item Front cover Full tempered glass Zoom lens Reflector LED support Temp switch Cooling part Stepper motor Middle cover LED driver board Power supply Display panel Rear cover Bracket assembly -15-... -
Page 17: Attached2: Fine 1514 Dg Fixture Exploded Drawing
Attached 2: FINE 1514 DG fixture exploded drawing Item Front cover Full tempered glass Lens LED support Cooling part Middle cover LED driver board Power supply Display panel Rear cover Bracket assembly -16-... -
Page 18: Attached3: Fine 1514 Zoom Light Output And Beam Angle Range
Attached 3: FINE 1514 ZOOM light output and beam angle range 7925 1981 1991 12° 27° (1/10Peak) (1/10Peak) distance(m) 0.45 0.91 1.36 1.81 2.27 2.52 Φ Φ Φ Φ Φ Φ 12°(1/2Peak) diameter(m) 0.98 1.96 2.93 3.91 4.09 5.76 27°(1/10Peak) diameter(m) Φ... -
Page 19: Attached4: Fine 1514 Dg Light Output And Beam Angle Range
Attached 4: FINE 1514 DG light output and beam angle range FINE 1514DG 9°lens 9° 15° (1/2Peak) (1/10Peak) distance(m) 0.33 0.66 0.99 1.33 1.66 1.89 Φ Φ Φ Φ Φ Φ 9°(1/2Peak) diameter(m) 0.55 1.65 2.75 15°(1/10Peak) diameter(m) Φ Φ Φ... - Page 20 FINE 1514DG 24°lens 24° 45° (1/2Peak) (1/10Peak) distance(m) 24°(1/2Peak) diameter(m) Φ0.84 Φ1.68 Φ2.52 Φ3.36 Φ4.2 Φ5.04 45°(1/10Peak) diameter(m) Φ1.6 Φ3.2 Φ4.8 Φ6.4 Φ8 Φ9.6 -19-...
-
Page 21: Attached5: Fine 1514 Zoom Wiring Diagram
Attached 5: FINE 1514 ZOOM wiring diagram -20-... -
Page 22: Attached6: Fine 1514 Dg Wiring Diagram
Attached 6: FINE 1514 DG wiring diagram -21-...
