Connecting to a Display: HoverCast
19
HoverCast Wireless HDMI
Pilot X/S comes equipped with state-of-the-art wireless
interactive casting technology called HoverCast. Using
the HoverCast Receiver, Pilot X is capable of casting a
high
Unlike other wireless casting technologies, HoverCast has
virtually no loss in image clarity and no noticeable delay
does not use a WiFi network or interfere with local WiFi
networks.
When used with a Touch-USB enabled display
(supported by most "interactive" panels and projectors),
HoverCast also sends the user's touch inputs from the
display back to the tablet. This allows the user to control
their tablet from the display.
How Does HoverCast Work?
HoverCast is composed of two main components: the HoverCast Wireless Antenna (preinstalled
on the Pilot X/S Tablet) and the HoverCast Wireless Receiver (an accessory to be plugged into
the intended display). The Antenna and Receiver are pre-paired one-to-one out of the box, so they
will connect automatically when set-up properly. There is no software to install or passwords to enter.
HoverCast Wireless
Antenna
The HoverCast wireless signal travels similarly to a beam of light. Light doesn't pass through walls,
so neither will the HoverCast signal.
Antenna and HoverCast Wireless Receiver are used in the same room.
HoverCast will only work when the HoverCast Wireless
Wireless
HDMI
Wireless
Touch
HoverCast Wireless
Receiver

Advertisement

loading
Need help?

Need help?

Do you have a question about the Pilot X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HoverCam Pilot X

  • Page 1 HoverCast is composed of two main components: the HoverCast Wireless Antenna (preinstalled on the Pilot X/S Tablet) and the HoverCast Wireless Receiver (an accessory to be plugged into the intended display). The Antenna and Receiver are pre-paired one-to-one out of the box, so they will connect automatically when set-up properly.
  • Page 2 Connecting to a Display: HoverCast 20 HoverCast works best when the tablet s HoverCast Wireless Antenna is directly facing the HoverCast Wireless Receiver (which will be placed near the output display). For boosted reception, you can angle the tablet s HoverCast Wireless Antenna forwards by 20º. Increasing the tilt angle of the radio signal can potentially increase signal strength.
  • Page 3 Connecting to a Display: HoverCast HoverCast Set-Up While there is no software to set up or passwords to enter, the right steps must be followed in the ology. Install the Receiver: Install the HoverCast Wireless Receiver on or near the intended output display by hand-tightening the retention nut clockwise until the the unit is secure.
  • Page 4 Connecting to a Display: HoverCast 22 Switch on the Pilot X/S Tablet via the Tablet Sleep/Wake Button and switch on your output display, making sure the corresponding HDMI input is selected. Next, plug the power line in to turn on HoverCast.The indicator lights will begin a rapid flashing sequence until a connection is formed.
  • Page 5 HoverCast Positioning Guide The HoverCast Wireless Receiver’s front must face Make sure the HoverCast Wireless receiver is not outwards, towards the receiver and away from any walls mounted backwards. The front of the receiver should or cavities. face wherever the tablet will be used most frequently. Front of overCast Rear of overCast Wireless Receiver...
  • Page 6 HoverCast Positioning Guide 24 Do not tuck the HoverCast Wireless Receiver behind Be sure to mount the HoverCast Wireless Receiver panels or in other enclosed spaces. The receiver should facing away from walls, and in plain sight. be mounted high and within line-of-sight of the antenna. When using with a ceiling-mounted projector, make sure Do not place the HoverCast Wireless Receiver facing the front of the HoverCast Wireless Receiver is directed...
  • Page 7 HoverCast Troubleshooting If you are having issues connecting the HoverCast system, please contact HoverCam Technical Support: HoverCam Technical Support support@thehovercam.com +1 (866) 201-2056...
