Inferno ROLLER G1 Construction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
118 - 168 cm / 47 - 66 inch
Length
Max weight
Time to build
ROLLER
CONSTRUCTION MANUAL
118 - 168 cm / 47 - 66 inch
70 kg / 153 lbs
2 hours
6-14
G1
YEARS

Advertisement

loading
Need help?

Need help?

Do you have a question about the ROLLER G1 and is the answer not in the manual?

Questions and answers

Related Manuals for Inferno ROLLER G1

Summary of Contents for Inferno ROLLER G1

  • Page 1 6-14 118 - 168 cm / 47 - 66 inch YEARS ROLLER CONSTRUCTION MANUAL Length 118 - 168 cm / 47 - 66 inch Max weight 70 kg / 153 lbs Time to build 2 hours...

  • Page 2: Safety Warning

    WARNING - IMPORTANT NOTICE TO PARENTS Before you start constructing and use our product, please carefully read the following safety warning and download our manual from our website. This safety warning and manual contains important informa- tion relating to your child’s safety. It is your responsibility to review this information with your child and make sure they are fully aware of all the warnings before they start riding.
  • Page 3 SECTION SAFETY WARNING! PARENTAL SUPERVISION during unpacking and assembly to insure that surfaces may impair traction and contribute to AND APPROPRIATE USE all small parts and plastic bags are accounted possible accidents. for and kept out of the reach of children. 11.

  • Page 4: Maintenance

    SAFETY SECTION OUR KITS CONTAIN SMALL PARTS WARNING! PROTECTIVE EQUIPMENT This package contains small parts which, SHOULD BE WORN. before assembly, present a choking hazard to Not to be used in traffic. 50 kg max. children under the age of three. Care should be taken during unpacking and assembly to insure that all small parts and plastic bags are accounted for and kept out of the reach of children.
  • Page 5 .33 inch | 110 mm 4.72 inch | 120 mm 6-14 Clamping par Profi le Multi angle joint Bolt M8x20 Profi le nut short T-Positioning block holes without threa 7 inch | 360 mm 15.75 inch | 400 mm ride ROLLER First, get all required materials stated here and then follow the instructions.
  • Page 6 TOP 3 REQUIREMENTS MAKING A GREAT INFENTO EXPERIENCE: Tighten bolts with full force (15Nm) to prevent them from coming loose. Constructing and playing always under supervision of an adult. Check frequently if all parts are still fi rmly tightened and function properly.
  • Page 7 without bearings 6-14 Clamping par Multi angle joint T-Positioning block holes without threa Bolt M8x20 nylock ride ROLLER Tighten the bolts with full force. Ensure that you hold the long side of the Allen key in your hand as this enables you to exert greater force.
  • Page 8 If your Kit contains a white fastener bag with 12 Nock Washers, please follow the steps on this page. If not, please skip to the next page of the 6-14 manual. Nock washer M8-16 ride ROLLER This is the 7’’ Wheelhouse. Before being able to use this part, you need two Nock Washers M8-16.
  • Page 9 Positioning block 3.94 inch | 100 mm 6-14 7 inch wheel house Washer M8-24 T-Positioning block Bolt M8x25 nylock ride ROLLER Most nuts that you use for Infento are self-locking. This means that they cannot vibrate loose. On the inside of the bolt you will see a plastic washer that ensures it cannot turn freely, even if there is no...
  • Page 10 without bearings 3.54 inch | 90 mm 3.94 inch | 100 mm 6-14 Profi le Bolt M8x20 Profi le nut short Multi angle joint T-Positioning block Bolt M8x20 nylock 11.02 inch | 280 mm 12.60 inch | 320 mm ride ROLLER lockbolt V 1.7...
  • Page 11 6-14 Clamping par Bolt M8x20 Profi le nut short Multi angle joint holes without threa T-Positioning block Bolt M8x20 nylock ride ROLLER 3.94” | 100 mm V 1.7...
  • Page 12 T-Positioning block holes without thread 13x2.75-8 13x2.75-8 6-14 Locknut M8 Knurled disc 2 stripes Knurled disc 2 stripes Bolt M8x35 ride ROLLER Depending on your There are two types of Kit, the knurled knurled discs. Please discs can be of a diff...
  • Page 13 5.12 inch | 130 mm 6-14 Clamping par Profi le Bolt M8x20 Multi angle joint Profi le nut short holes without threa T-Positioning block 17.32 inch | 440 mm ride ROLLER V 1.7...
  • Page 14 Bolt M8x20 6-14 Bolt M8x20 (low head) L-joint T-Positioning block Parrellel clamp joint ride ROLLER V 1.7...
  • Page 15 If your Kit contains a white fastener bag with 12 Nock Washers, please follow the steps on this page. If not, please skip to the next page of the 6-14 manual. Nock washer M8-16 ride ROLLER This is the U-block. Before being able to use this part, you need two Nock Washers M8-16.
  • Page 16 13x2.75-8 6-14 Bolt M8x20 Profi le nut short U-Block T-Positioning block ride ROLLER 4.13” | 105 mm If your U-block or Kit doesn’t have the M8-16 Nock Washers, you can use the regular M8-16 washers as shown here. V 1.7...
  • Page 17 Multi angle joint holes without threa 5.91 inch | 150 mm Bolt M6x16 6-14 Profi le nut short Positioning block T-joint Bolt M8x40 ride ROLLER Depending on your Kit, the T-joint might look like this. The new T-joint doubles as a profile connector (part A) Profi...
  • Page 18 Bolt M8x20 15 inch | 80 mm 3.54 inch | 90 mm 6-14 Bolt M8x20 Profi le (low head) T-Positioning block L-joint Parrellel clamp joint 40 mm 11.02 inch | 280 mm ride ROLLER V 1.7...
  • Page 19 Multi angle joint 5.91 inch | 150 mm Bolt M6x16 6-14 Positioning block Profi le nut short T-joint Bolt M8x40 ride ROLLER V 1.7...
  • Page 20 Washer M8-24 Driven rim without bearings 6-14 Bearing block T-Positioning block 40x40_Hexa 19 Bolt M8x20 nylock ride ROLLER 3.94” | 100 mm V 1.7...
  • Page 21 Handgrip Profi le nut short 6-14 Handlebar short Multi angle joint Positioning block Bolt M8x25 Positioning block Axle plate ride ROLLER V 1.7...
  • Page 22 holes without thread 13x2.75-8 T-Positioning block 13x2.75-8 6-14 Locknut M8 Knurled disc 2 stripes Knurled disc 2 stripes Bolt M8x35 ride ROLLER 20° V 1.7...
  • Page 23 Multi angle joint holes without threa Handgrip Toothed belt 154T 6-14 Clamping par Handlebar extension Handlebar short Multi angle joint Positioning block belt pulley 46T holes without threa Axle plate Bolt M8x45 ride ROLLER V 1.7...
  • Page 24 holes without thread 13x2.75-8 T-Positioning block 13x2.75-8 6-14 Locknut M8 Knurled disc 2 stripes Knurled disc 2 stripes Bolt M8x35 ride ROLLER 20° V 1.7...
  • Page 25 Multi angle joint holes without threa T-Positioning block Profi le nut short Parrellel clamp joint extension 6-14 Angle limiter Bearing block Positioning block Locknut M8 isc 1 stripe 40x40_8 Multi angle joint 40º Bolt M8x25 ride ROLLER V 1.7...
  • Page 26 Brake caliper holder Bolt M6x25 Locknut M6 T-Positioning block 6-14 Bearing block Washer M8-16 Bolt M8x60 Locknut M8 pulley protection 28T 40x40_Hexa 19 ride ROLLER V 1.7...
  • Page 27 Multi angle joint holes without threa T-Positioning block Profi le nut short Parrellel clamp joint extension 6-14 Angle limiter Bearing block Positioning block Locknut M8 isc 1 stripe 40x40_8 Multi angle joint 40º Bolt M8x25 ride ROLLER V 1.7...
  • Page 28 Brake caliper holder Bolt M6x25 Locknut M6 T-Positioning block 6-14 Bearing block Washer M8-16 Bolt M8x60 Locknut M8 pulley protection 28T 40x40_Hexa 19 ride ROLLER V 1.7...
  • Page 29 Positioning block Bolt M8x40 nylock 22.05 inch | 560 mm 23.62 inch | 600 mm without bearings 6-14 8 inch Bearing Axle Washer M8-24 protection cap Driven rim .06 inch | 103 mm 4.37 inch | 111 mm Bolt M8x20 nylock ride ROLLER V 1.7...
  • Page 30 6-14 Inner tube Tire 8 inch Driven rim 13x2.75-8 13x2.75-8 ride ROLLER Note! Pull the tire over the The valve points downwards. rim and infl ate the tire to max 1.5 bar. V 1.7...
  • Page 31 Steering fl ange 6-14 Spacer Spacer 13 inch 0.04inch | 1 mm 0.08inch | 2 mm Bolt M8x20 Driven wheel Wheel lock ring 8-42 ride ROLLER double check! V 1.7...
  • Page 32 T-Positioning block holes without thread 13x2.75-8 13x2.75-8 6-14 Locknut M8 Knurled disc 2 stripes Knurled disc 2 stripes Bolt M8x35 ride ROLLER V 1.7...
  • Page 33 6-14 Protect cap Brake lever left ride ROLLER If your protect cap has a hole, use a M8x12 countersunk bolt to fasten it V 1.7...
  • Page 34 Driven rim Bolt M8x25 belt pulley 28T 6-14 Bolt M6x30 Locknut M6 without bearings Handlebar knob Handgrip ride ROLLER V 1.7...
  • Page 35 Driven rim Bolt M8x25 belt pulley 28T 6-14 Bolt M6x30 Locknut M6 without bearings Handlebar knob Handgrip ride ROLLER V 1.7...
  • Page 36 4 inch wheel 6-14 Brake cable Brake cab .37 in | 1000 mm 59.06 in | 1500 mm ride ROLLER V 1.7...
  • Page 37 belt pulley 46T 40x80_he 6-14 Brake cable clip ride ROLLER V 1.7...
  • Page 38 6-14 Brake cable Brake Clamping bracket adjuster 7 inch wheel house 7 inch wheel house ride ROLLER 4 mm V 1.7...
  • Page 39 Spring 6-14 brake system 7 inch wheel house ride ROLLER CLICK! V 1.7...
  • Page 40 T-Positioning block Toothed belt 100T 6-14 Locknut M8 Bolt M8x55 ride ROLLER check V 1.7...
  • Page 41 6-14 Square nut M6 Bolt M6x50 Seatboard Filler Seatboard Tail Seatboard Base ride ROLLER If you have this type of seat in your Kit, please skip to the next page. If not, follow the instructions below to construct your seatboard. Put the M6 square nuts in place before...
  • Page 42 Bolt M5x6 6-14 Ducktail board Ducktail b Bolt M8x20 Profi le nut short + foam extension ride ROLLER V 1.7...
  • Page 43 Bolt M8x20 nylock 6-14 Word mark ride ROLLER V 1.7...
  • Page 44 118 - 168 cm / 47 - 66 inch ROLLER THANK YOU FOR READING ME!
