- Page 1 6-14 YEARS CRUISER CONSTRUCTION MANUAL Length 118 - 168 cm / 47 - 66 inch Max weight 70 kg / 153 lbs Time to build 2,5 hours...
-
Page 2: Safety Warning
WARNING - IMPORTANT NOTICE TO PARENTS Before you start constructing and use our product, please carefully read the following safety warning and download our manual from our website. This safety warning and manual contains important informa- tion relating to your child’s safety. It is your responsibility to review this information with your child and make sure they are fully aware of all the warnings before they start riding. - Page 3 SAFETY SECTION WARNING! PARENTAL SUPERVISION during unpacking and assembly to insure that surfaces may impair traction and contribute to AND APPROPRIATE USE all small parts and plastic bags are accounted possible accidents. for and kept out of the reach of children. 11.
-
Page 4: Maintenance
SAFETY SECTION OUR KITS CONTAIN SMALL PARTS WARNING! PROTECTIVE EQUIPMENT SHOULD BE WORN. This package contains small parts which, Not to be used in traffic. 50 kg max. before assembly, present a choking hazard to children under the age of three. Care should be taken during unpacking and assembly to insure that all small parts and plastic bags are accounted for and kept out of the reach of children. - Page 5 3.94in | 100mm .09inch | 180mm Profi le 7 inch wheel house Washer M8-24 Bolt M8x25 nylock T-Positioning block 22.05inch | 560mm ride CRUISER First, get all required materials stated here and then follow the instructions. Tighten the bolts with full force. Ensure that you hold the long side of the Allen key in your hand as this enables you to exert greater force.
- Page 6 TOP 3 REQUIREMENTS MAKING A GREAT INFENTO EXPERIENCE: Tighten bolts with full force (15Nm) to prevent them from coming loose. Constructing and playing always under supervision of an adult. Check frequently if all parts are still fi rmly tightened and function properly.
- Page 7 Multi angle joint Bolt M8x20 T-Positioning block ride CRUISER The positioning blocks are some of the smallest Infento parts but they are also some of the most important. They ensure that everything connects to each other properly. This prevents parts from twisting and com- ing loose when under pressure.
- Page 8 Bolt M8x20 Multi angle joint Profi le nut short T-Positioning block ride CRUISER When tightening the bolt always check whether the profi le nut remains 13 mm | 0,5” perfectly straight in the slot. If this becomes crooked, you can push against the side of the profi...
- Page 9 xle clamp ring Profi le Profi le nut short T-Positioning block Multi angle joint Bolt M8x20 3.15inch | 80mm ride CRUISER 36 mm | 1,4” V 1.3...
- Page 10 Bolt M8x20 nylock (low head) Locknut M8 L-joint T-Positioning block Knurled disc 2 stripes Bolt M8x35 ride CRUISER There are two types of knurled discs. Please see education section. 60° There are two diff erent knurled discs. One for each corner ending in a 5 (5-15-25-etc.
- Page 11 Parrellel clamp joint Bearing block Locknut M8 Positioning block 40x40_8 Stabilizer plate Bolt M8x35 ride CRUISER NUT-IN-PART-TRICK take a 5mm Allen key, slide the nut on it stick the Allen key through the part let the nut slide down V 1.3...
- Page 12 Locknut M8 Positioning block U-Block Stabilizer plate Axle clamp Bolt M8x35 ride CRUISER NUT-IN-PART-TRICK take a 5mm Allen key, slide the nut on it stick the Allen key through the part let the nut slide down V 1.3...
- Page 13 Angle limiter Locknut M8 Bolt M8x60 Washer M8-16 40º ride CRUISER V 1.3...
- Page 14 37inch | 111mm Axle Locknut M6 Bolt M6x25 12.95inch | 329mm ride CRUISER Leave a gap of at least 0.5mm when tightening the bolts. 145 mm | 5,7” V 1.3...
- Page 15 adjuster Stabilizer rubber Washer M8-16 7 inch wheel 85S black Bolt M8x45 nylock ride CRUISER V 1.3...
- Page 16 without bearings Multi angle joint Bolt M8x20 Profi le nut short T-Positioning block Bolt M8x20 nylock ride CRUISER lockbolt 6 mm | 0,2” The plastic parts of Infento are made using injection moul- ding technology where molten plastic is pressed under high pressure into a mould.
- Page 17 Locknut M8 Knurled disc 2 stripes Bolt M8x35 ride CRUISER V 1.3...
- Page 18 without bearings Profi le Multi angle joint T-Positioning block Bolt M8x20 nylock 4.72inch | 120mm ride CRUISER V 1.3...
- Page 19 Adjusting bolt Handlebar spacer Handlebar short Axle plate T-Positioning block M8x55 ride CRUISER V 1.3...
- Page 20 Brake lever left Locknut M8 Knurled disc 2 stripes Bolt M8x35 ride CRUISER 20° V 1.3...
- Page 21 Handlebar knob Locknut M6 Bolt M6x30 Handgrip ride CRUISER V 1.3...
- Page 22 Brake cable 59.06 in | 1500 mm ride CRUISER V 1.3...
- Page 23 Brake cable clip ride CRUISER V 1.3...
- Page 24 Brake cable Brake Clamping bracket adjuster 7 inch wheel house 7 inch wheel house ride CRUISER 4 mm V 1.3...
- Page 25 Spring brake system 7 inch wheel house ride CRUISER CLICK! V 1.3...
- Page 26 7 inch wheel without bearings Locknut M8 Bolt M8x55 ride CRUISER Check Check V 1.3...
- Page 27 Ducktail board Ducktail board Bolt M8x20 Profi le nut short extension + foam + foam ride CRUISER V 1.3...
- Page 28 Word mark ride CRUISER V 1.3...
- Page 29 118 - 168 cm / 47 - 66 inch CRUISER THANK YOU FOR READING ME!
