Installation/Operation Instructions
This document describes the installation and operation of the Simplex 4190-9011/
9012 Fiber Optic Audio Repeater. The 4190-9011 Master Unit and the 4190-
9012 Slave Unit are option modules that mount within a 4100 or 4120 Fire Alarm
Control Panel (FACP).
The Simplex Fiber Optic Audio Repeater is designed to "drop-and-repeat" one,
unidirectional, line-level, 600-ohm audio signal. The audio repeater uses either
62.5/125 µ or 50/125 µ fiber optic cables (for distance limitations reference
Table 4). The Fiber Optic Audio Repeater can be utilized in one-way drop-and-
repeat or self-healing ring systems.
The following is a list of additional documentation that may aid you in the
installation of the 4190-9011/9012 Fiber Optic Audio Repeater.
•
4120/UT System Card Installation Instructions ....................... 574-164
•
4100 Field Wiring Diagram ..................................................... 841-731
•
4100/4120 Interconnect Diagram ............................................. 841-869
The following topics are covered in this publication.
Topic
Cautions and Warnings
Specifications
Fiber Optic Connection
Installing the Hardware
Internal Wiring Connections
Troubleshooting
firealarmresources.com
4190-9011/9012
Fiber Optic Audio Repeater
See Page #
2
3
5
6
7
10
574-795
Rev. A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Simplex 4190-9011
Summary of Contents for Simplex 4190-9011
- Page 1 This document describes the installation and operation of the Simplex 4190-9011/ Overview 9012 Fiber Optic Audio Repeater. The 4190-9011 Master Unit and the 4190- 9012 Slave Unit are option modules that mount within a 4100 or 4120 Fire Alarm Control Panel (FACP).
-
Page 2: Cautions And Warnings
Cautions and Warnings DO NOT INSTALL ANY SIMPLEX PRODUCT THAT APPEARS DAMAGED. Upon unpacking your Simplex product, inspect the contents of the carton for shipping damage. If damage is apparent, immediately file a claim with the carrier and notify Simplex. -
Page 3: Specifications
CARRIER (ON=OK) SUPERVISION CHNL B CONTACTS FIBER XTMR CLOSED=OK CHNL A CHNL A FIBER GND - 6 SIMPLEX TIME RECORDER CO. AUDIO IN (2V P-P MAX) CARRIER (ON=OK) 4190-9011 MASTER FIBER OPTIC NOT USED FIBER AUDIO MODEM XTMR CHNL B... - Page 4 Specifications, Continued Specifications (Continued) Table 4. General Specifications Specification Description Audio General Balanced, Simplex (two wires) Bandwidth 800 Hz to 2800 Hz Input/Output 2 Volts pk-pk Impedance 600 ohms Loss of Signal Output 0.5 Amp Relay Contact Optical Power 62.5/125 Fiber 25 µw (-16 dBm)
-
Page 5: Fiber Optic Connection
CHNL A CHNL A FIBER Ground GND - 6 Audio In AUDIO IN Audio In (2V P-P MAX) CARRIER (ON=OK) 4190-9011 MASTER FIBER OPTIC NOT USED FIBER AUDIO MODEM XTMR CHNL B P/N 618-019 FIBER INSTALLATION INSTRUCTIONS: 0V - 2... -
Page 6: Installing The Hardware
Installing the Hardware Installing the Hardware The master and slave units mount in the same manner. These units are intended for use in 4100 and 4120 panels only. Follow Steps 1 through 3 and refer to Figure 3 below to install an audio repeater. Using the supplied bracket, install a 1/4-inch, 6-32 screw and star washer in each of the four mounting holes on the face of the bracket. -
Page 7: Internal Wiring Connections
Internal Wiring Connections Introduction After installing the audio repeater and bracket, three connections are required: • Audio input (or output) • Power (24 VDC) • Supervision (fault) loop Master Audio Repeater Audio The audio repeater is designed for low level audio signals. It must be interfaced Input at the 1 V p-p level. - Page 8 CHNL A FIBER CUT AND STRIP AS REQUIRED SHIELDED WHITE TAPE SHIELD BACK CARRIER (ON=OK) AUDIO IN (2V P-P MAX) FIBER BLACK 4190-9011 XTMR NOT USED MASTER FIBER OPTIC CHNL B FIBER AUDIO MODEM P/N 618-019 UN-SHIELDED BLACK 4100 POWER...
- Page 9 Wiring Precautions” in the 4100 Field Wiring Diagrams (841-731) for specific information. Power must come from an approved Simplex Power Supply. See the 4100 Field Wiring Diagrams (841-731 or 841-995) for suitable power supplies. Neatly dress all cables that are cut and stripped.
-
Page 10: Troubleshooting
Simplex Time Recorder Company branch office for repairs. Consult your local telephone directory for the phone number listing of the Simplex branch office, or call the Simplex Customer Assistance Department at (978) 632-2500, and request the telephone number for the Simplex branch office in your area. 574-795 Rev.
