- Page 1 FlexCom104-GPS Manual Flexible Communications PC/104 Platform With GPS Manufactured by: Tri-M Technologies Technical Manual Revision: 2014-09-22 sales@tri-m.com Toll-free (Canada & USA) 1-800-665-5600 Direct: +1-604-814-5069...
- Page 2 PREFACE This manual is for integrators of applications of embedded systems. It contains information on hardware requirements and interconnection to other embedded electronics. DISCLAIMER Tri-M Technologies makes no representations or warranties with respect to the contents of this manual, and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose.
- Page 3 CHAPTER 1 INTRODUCTION .......................... 4 ..................................4 ENERAL ESCRIPTION ......................................4 EATURES ....................................5 PECIFICATIONS CHAPTER 2 CONFIGURATION ........................6 2.1 I ...................................6 NTRODUCTION 2.2 S ................................6 OFTWARE ONFIGURATION 2.3 IRQ I ..............................6 NTERRUPT ONFIGURATION 2.4 S I/O A ...........................7 ERIAL DDRESS ONFIGURATION 2.5 P ..................................7 OWER...
- Page 4 Both Universal Socket modules supplied with 5V. No support for 3.3V socket modules • Only Multitech Universal Socket wireless modules supported. The FlexCom104-GPS is a communications platform capable of supporting two of the Multitech Universal Socket compatible devices. Embedded in the FlexCom104-GPS is a quad UART (ST16C554DIQ64) to provide communications to the two Universal Sockets, a mounting point for the FV-4H GPS and an additional serial port.
- Page 5 *Some Universal Socket modules may be large enough to violate the PC/104 form factor. UART specifications Model ST16C554DIQ64 FIFOs 16 bytes Ports Serial port specifications Protocol RS-232 Duplex RS-232 Full Figure 1: FlexCom104-GPS Dimensions 3.775” 3.55” sales@tri-m.com Toll-free (Canada & USA) 1-800-665-5600 Direct: +1-604-814-5069...
- Page 6 /dev/ttyS2 port 0x100 irq 7 uart 16850 baud_base 921600 spd_vhi 2.3 IRQ Interrupt Configuration The FlexCom104-GPS can be configured for IRQ5, IRQ7, IRQ10, IRQ11 and IRQ12 by the installation of jumper shunts on JP1 as per Table 1. Jumper JP1...
- Page 7 2.4 Serial Port I/O Address Configuration The FlexCom104-GPS I/O address can be configured by the installation of jumper shunts on JP1 as per Table 2. Table 1: Serial Port I/O Address Configuration Serial Port I/O Addresses - Hex Jumper JP1...
- Page 8 2.8 Connecting an FV-4H GPS A GPS antenna must be connected to the SMA connector on the FlexCom104-GPS for the FV-4H GPS to operate. Module2 Position GPS SMA Antenna Module1 Position 2.9 Connecting an External Serial Port The serial port has the same pin out (see Table 3.6.1) as a standard IDC serial connector, however it has 2mm pin spacing.
