CT101
Stand, Bases & Pucks
2c
Secure the swivel base to the stand
using the provided screw.
1
Use the provided alcohol wipe to
clean the fixture where the stand
will be placed. Allow it to dry
completely.
2d
Optional:
If using the stud mount option with the
swivel base, insert and tighten the stud
into the threaded hole.
Note: The use of the adhesives (see
the next step) is still recommended to
prevent the rotation of the base.
Optional Swivel Base
2a
(CT1012) Installation:
Remove the 2 adhesives from the
bottom of the stand.
2e
Peel the clear film from the 2
adhesives on the bottom of the
swivel base.
2b
Route the stand's power cable
through the swivel base.
2f
Optional:
If routing the power cable across the
fixture surface, run the cable down
the channel in the bottom of the
base.
Advertisement
Table of Contents
Related Manuals for inVue CT101
Summary of Contents for inVue CT101
- Page 1 Allow it to dry Remove the 2 adhesives from the completely. bottom of the stand. CT101 Stand, Bases & Pucks Optional: Peel the clear film from the 2 Optional: Secure the swivel base to the stand...
- Page 2 Optional Adhesive Mount Optional: Press the stand against the fixture for Optional: Base (CT1013) Installation: If routing the power cable through a at least 10 seconds. If using the stud mount option from hole in the fixture, insert the cable into Step 2d, beneath the fixture, place Peel the clear film from the 2 the hole.
- Page 3 Optional Wall Mount Plate Route the power cable through the Optional: Press the stand against the fixture for (CT1014) Installation: hole in the wall mount plate. If routing the power cable through at least 10 seconds. a hole in the fixture, insert the cable Peel the clear film from the 2 into the hole.
- Page 4 Stud Mount (Included With Peel the clear film from the 2 Route the power cable and stud From beneath the fixture, place the CT1011) Installation: adhesives on the bottom of the down through a hole or slot in the large yellow washer onto the stud stand.
- Page 5 Remove the adhesive from its backing Plug the power connector on the Center the puck on the back of the Peel the clear film from the adhesive and place it on the puck. If there is a puck into the device. device and apply pressure for at least on the puck.
- Page 6 SD0765 Rev1 03/24/20 www.invue.com NA / LATAM // 704.752.6513 • 888.55.INVUE EMEA // +31.23.8900150 APAC // +852.3127.6811 © 2020 InVue Security Products Inc. All rights reserved. InVue is a registered trademark of InVue Security Products.
