Summary of Contents for Hidromasajes Estilo BR -0502S
Page 1
4. A switch for the supply of the hot /cool water must be MODEL :BR -0502S installed,when stop to use this product the water supply switch and the power source switch should be turned off.
Page 2
Sketch Installation 1. Adjust the feet-screw to make the bathtub horizontal. 2. Connect the drainpipe to the cloaca. 3. Fix shower head and pillow. 4. Connect to the cool(blue) and hot(red) water pipe. 5. Connect to power source, then fill water to have a test. Parameter drainage V o l tage: 2 20V - 2 4 0V...
Page 3
Construction instruction Construction plan of water and electricity : : Model Size BR-0502S 1800x1500x700mm Overlook view of product Front view of product Front view of ground board Overlook view of ground board Side-glance drawing of ground board Three-dimensional drawing of ground board NOTE please confirm the ground board and bathtub height is on the same level before install, if any difference, please adjust bottom screw to make the height same, then, install the bathtub, ensure all bottom feet stand on the ground.
