PARTS LIST / LISTE DES PIÈCES / LISTA DE PIEZAS
ITEM NO. / ARTICLE NO. / ARTICULO NO : 156- CF155-801B
M
X3
dowel Ø8*30mm
X3
Hibisco Ø8*30mm
X3
Hibiscus Ø8*30mm
Page 1 / 4
A
X1
LEFT SIDE PANEL
X1 Panel izquierdo
X1 Panneau gauche
B
X1 BACK PANEL
X1 Placa posterior
X1 Fond de panier
C
X1
RIGHT SIDE PANEL
X1 Panel lateral derecho
X1 Panneau latéral droit
D
Drawer Front
X1
X1 Panel de bombeo
X1 Panneau de pompage
E
X1
Front Frame
X1
Marco frontal
X1
Cadre avant
F
Drawer Bottom Panel
X1
X1 Dibujar la placa inferior
X1 Dessiner la plaque inférieure
G
X1
Drawer Back Panel
X1 Despues de bombear
X1 Après pompage
H
X2
L/R Drawer Sides
X2 Placa lateral
X2 Plaque latérale
X1
TOP PANEL
X1
Techo
X1
Le toit
J
X5
Bolt Ø1/4"*32mm
X5
Perno Ø1/4"*32mm
X5
Boulon Ø1/4"*32mm
K
X1
Knob Ø31*25mm
X1
Manejar
Ø31*25mm
X1
Poignée
Ø31*25mm
L
Handle screw
Ø5/32"*19mm
X1
X1 Tornillo de la manija
Ø5/32"*19mm
X1 Vis de poignée
Ø5/32"*19mm
Advertisement
Related Manuals for Delacora 156-CF155-801B
Summary of Contents for Delacora 156-CF155-801B
- Page 1 PARTS LIST / LISTE DES PIÈCES / LISTA DE PIEZAS ITEM NO. / ARTICLE NO. / ARTICULO NO : 156- CF155-801B LEFT SIDE PANEL TOP PANEL Front Frame X1 Panel izquierdo Techo Marco frontal X1 Panneau gauche Le toit Cadre avant Drawer Bottom Panel Bolt Ø1/4"*32mm X1 BACK PANEL...
- Page 2 ASSEMBLY INSTRUCTIONS / NOTICE DE MONTAGE / INSTRUCCIONES DE MONTAJE ITEM NO. / ARTICLE NO. / ARTICULO NO : 156- CF155-801B DESCRIPTION / DESCRIPCIÓN/Description :With drawer/Con cajon/Avec tiroir Step 1. Insert the hardware on Back Panel ( Part B) into Left & Right Side Frames ( Part A&C) and press down completely to secure in place.
- Page 3 ASSEMBLY INSTRUCTIONS / NOTICE DE MONTAGE / INSTRUCCIONES DE MONTAJE ITEM NO. / ARTICLE NO. / ARTICULO NO : 156- CF155-801B DESCRIPTION / DESCRIPCIÓN/Description :With drawer/Con cajon/Avec tiroir Step 3. Make sure that all of the switch locking hardware are in the open position indicated by the straight arrow in the diagram below.
- Page 4 ASSEMBLY INSTRUCTIONS / NOTICE DE MONTAGE / INSTRUCCIONES DE MONTAJE ITEM NO. / ARTICLE NO. / ARTICULO NO : 156- CF155-801B DESCRIPTION / DESCRIPCIÓN/Description :With drawer/Con cajon/Avec tiroir Step 4.1 - Insert the Drawer Bottom (Part F) into the grooves in the side panels and press forward until the front edge goes completely into the groove in the drawer front.
