- Page 1 V 30 Optical Multi Meter Please read this manual before operating the device. Please keep this manual together with the device. 2018/03 Rev.0.1...
- Page 2 User Manual...
-
Page 4: Table Of Contents
Contents Preface Chapter 1: Overview Introduction Basic Configuration Power Supply Size and Weight Environment Condition Parameters Appearance Overview Chapter 2: Functions power-on and power saving function: Function selections Optical power meter (OPM) Visual Fault Locator (VFL) LED lamp Network cable/phone line test Charger Changing the SC/FC/ST Connectors Chapter 3: Safety... - Page 5 Troubleshooting Maintenance and Technical Support Contents...
- Page 7 Important: INNO Instrument strongly recommends all users to read this manual before operating the V30. This manual is valid for the following software version:...
-
Page 8: Preface
V30. Meanwhile, its compact structure and strong housing are ready for operation in various severe environments. This manual is only subject to the users who have already purchased V30 optical multi meter. Copying any part of this manual without any written permission by... -
Page 9: Chapter 1: Overview
Overview Introduction V30 optical multi meter is a portable and powerful instrument used in optical power measuring, VFL detecting and NET testing. Besides, LED lamp is also available. Basic Configuration Optical multi meter, Network cable/phone line test module, Alkaline battery, charger, user’s manual. -
Page 10: Parameters
Parameters Parameters Type of detector InGaAs Type of optical fiber 2.5mm of ST / SC / FC universal connectors interface Calibrated wavelengths 850 / 1300 / 1310 / 1490 / 1550 / 1625nm Optical Power Meter (OPM) Measuring range from +6 to -70dBm Accuracy ±0.02dB Linearity... -
Page 11: Appearance Overview
Appearance Overview OPM Port LED Lamp (SC, FC, ST available) VFL Port (2.5mm ferrule type) Flashing mode on/off Button for wavelength (Available under the selection (Available under functions of VFL or LED) “OPM” function) Power on/off Mini USB charger socket or function selection button Test indicator for network... -
Page 12: Chapter 2: Functions
Functions Power-on and power saving function Power-on: Quickly press “MODE” key to turn on the instrument. Power-off: Press and hold “MODE” key for 4 seconds or more until “OFF” displays on the screen. Note: This instrument will shut down automatically without receiving any opera- tion instruction for 10 minutes. -
Page 13: Function Selections
Function selections It defaults to be under “OPM” function when power-on. 4 functions including “OPM”, “VFL”, “LED” and “network cable/phone line tester” will be switched in loop mode. Optical power meter (OPM) You can switch the measuring optical wavelengths by pressing “T” button under the function of “OPM”. -
Page 14: Network Cable/Phone Line Test
Network cable/phone line test Remote module The “Network cable/ phone line test” (NET) function is used in network generic wiring and for verifying the link on-off condition of network including the sequence of testing cable connection systems. Test will begin when this NET function is enabled;... -
Page 15: Charger
Charger This instrument is rechargeable. In process of using rechargeable battery, you should shut off the instrument and charge for it in time when low battery displayed on the screen. This product can be charged by being connected with AC adapter or USB port. The indicator of remaining battery will blink during this product charging. -
Page 16: Changing The Sc/Fc/St Connectors
Power Supply via USB: Operation Procedures: Connect the cable to the MINI USB port, when the letter CHARGE will appear beside the battery icon on the screen. CHARGE Changing the SC/FC/ST Connectors As shown in the following picture, users can demount and replace the connector with a necessary one, SC connector, FC connector or ST connector available for interchange. -
Page 17: Chapter 3: Safety
Safety Safety Precautions Operating and carrying V30 should comply with the following safety rules and general specifications. Otherwise, it will violate the safety standards of manufacturing and operating this product. Users who violate these requirements should take the responsibility to the consequences. -
Page 18: Storage
Storage Batteries should be taken out from the instrument and stored in proper place if this product not in use for a long time to avoid damage to the product due to battery leakage. Maintenance and Calibration General Maintenance Avoid touch fiber-optic connectors with hard objects and clean them if •... - Page 19 Maintenance and technical support Any operation like “calibration, maintain or repair for the device” can only be carried out by qualified maintenance technician. Please contact with the engineers INNO Instrument. You can also consult any question through the following Website.
- Page 20 Please visit us on Facebook www.facebook.com/innoinstrument Copyright 2017 INNO Instrument Inc. All rights reserved. ⓒ E-22F, 30, Songdomirae-ro, Yeonsu-gu, Incheon 21990, Republic of Korea 82-32-837-5600 82-32-837-5601 Printed in Korea...
