M-WAVE TW-4/24 Manual

MANUAL TORQUE WRENCH ›TW-4/24‹
EN

1) Parts description

4
7
8

2) Instruction

1. Set the required direction of rotation at the reversible lever
2. Put the required bit socket on the 1/4" drive
3. Set the required torque by turning the knob
a) Press the knob 8
and „0" on the scale
b) Continue to turn the knob
Then torque 9.6 Nm is set ( 8 Nm + 1.6 Nm = 9.6 Nm)
4. Tighten the wrench on bolt or nut until hearing „click" sound and tool-head
force immediately.

3) Notice

1. The torque wrench has been calibrated to be accurate to ± 6 %.
2. Before the first use or being unused for long time, be sure to repeat setting the torque to highest torque for 5-10 times
so that the components within can be completely lubricated by the lubricant.
3. Always set the torque to the lowest value when the wrench is not used.
4. Keep the torque wrench clean and do not soak in any liquid.
5. Do not apply force after the preset torque is reached or otherwise the work piece/the wrench may get damaged.
6. Do not disassemble the torque wrench and please contact the local distributor if any problem or calibration demands.
7. This is a high-precision measuring instrument and should not be used like a regular rachet.
Tool-head
1
Reversible lever
2
1
Quick release button
3
1/4'' Drive
4
3
Viewing window
5
2
Cursor
6
Scale
7
Knob
8
5
6
4
8
and then turn clockwise until „8" is aligned with the cursor
7
is aligned with the indicator on the handle.
8 clockwise until „1.6" on the scale
8 Nm +
Picture 1
.
2
.
as below example (picture 1):
7 is aligned with the indicator on the handle.
Torque range: 4 - 24 Nm in 0.2 Nm increment
Bit sockets: t sockets:
Hex 3/4/5/6/8 mm
1.6 Nm N = 9.6 Nm
6 in the viewing window
1 eases (picture 2), then release
Star T10/25
Picture 2
5
Art. 880291
