Rivulis S2000 Quick Start Manual

Rivulis S2000
Micro Sprinkler
The Rivulis S2000 Micro Sprinklers are the ideal choice for a wide range of applications including irrigation, cooling, and
frost protection for orchards and groves. Built to last, the Rivulis S2000 Micro Sprinkler line incorporates a strong bridge,
Built-In Anti-Insect Device, and a wear resistant design. The S2000 Micro Sprinkler delivers a consistent spray pattern at a
low angle, avoiding low hanging branches. The sprinklers can be configured with add-on features such as a spinner with a
Range Limiter, for a smaller wetting diameter around young trees or a trunk protector to keep the spray away from the tree
trunks. The sprinklers can be installed on the ground with a plastic stake or hung from a wire.
The Rivulis S2000 Flow Regulated Micro Sprinkler has the added feature of flow regulation, extending the use of the
sprinklers to applications with sloping fields and long lateral runs.

Product Features

Anti-insect device
Standard or flow Regulated models

Applications

Orchards

Product Options

Flow rates
S2000: 8, 10, 14, 16, 20, 26, 33 gph
S2000 Flow Regulated: 6, 8, 11, 14, 19,
25, 33 gph
Optional: detachable built-in range limiter
on the gray spinner provides a restricted
wetting diameter of 1.64'-1.96
Operating Guidelines
Operating pressure range: 22-50 psi
Rivulis
I r r igat i on
