PT-AE3000U / PT-AE3000E All manuals and user guides at all-guides.com CONTENTS Page Page 1 Safety Precautions 7 Measurement and Adjustments 1.1. General Guidelines 7.1. Cautions for Adjustment 1.2. Leakage Current Check 7.2. Setting Before Adjustment 1.3. UV Precaution and UHM Lamp Precautions 7.3.
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E 1 Safety Precautions 1.1. General Guidelines · For continued safety, no modification of any circuit must be attempted. · Unplug the power cord from the power outlet before disassembling this projector.
PT-AE3000U / PT-AE3000E All manuals and user guides at all-guides.com 2 Ext Option This projector has EXT OPTION in addition to standard on-screen menus. · There are SELF CHECK and FLICKER ADJUST for service, etc. 2.1. Procedure to enter EXT OPTION 1.
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E 3.1. Procedure to enter the self-check mode Select "SELF CHECK" on "EXT OPTION" menu and press "ENTER" button on the main unit or remote control unit. 3.2. Self Check Display and Contents...
PT-AE3000U / PT-AE3000E All manuals and user guides at all-guides.com 3.3. Canceling the self-check mode Press "MENU" button on the main unit or remote control unit. 4 Flicker Adjustment Mode If replacing the optical parts (LCD Panel / LCD block) or A-P.C.Board of this projector, enter the flicker adjustment mode and minimize the flicker.
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E 5 Using the SERIAL Connector The serial connector which is on the back connector panel of the projector conforms to RS-232C standard. This projector can be controlled by a PC which is connected as shown in "5.1. Connection".
PT-AE3000U / PT-AE3000E All manuals and user guides at all-guides.com 5.4. Basic Format The data sent from the PC to the projector is transmitted in the format shown below. Notes: · If sending multiple commands, check that a call back has been received from the projector for 1 command before sending the next command.
Page 11
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E Query Commands Parameters [Example] Setting to which the power is turned off in 90 minutes, using SLEEP command by a PC · When a command which does not require parameters is sent, the colon (:) is not required.
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E 6 Disassembly Instructions Warning: · Be sure to unplug the power cord from the power outlet before disassembling this projector. Caution: · While turning over a printed circuit board, be sure to put a insulating material under it to prevent a short circuit.
PT-AE3000U / PT-AE3000E All manuals and user guides at all-guides.com 6.1. Printed Circuit Board and Main Parts Location Electrical Parts Optical Parts...
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E 6.2. Removal of Upper Case 1. Lift the rear side of the top panel and disconnect the top panel Open/Close hook, then open the top panel. 6.3. Removal of A-P.C.Board 1.
PT-AE3000U / PT-AE3000E All manuals and user guides at all-guides.com 6.4. Removal of K1- and K3- 6. Unscrew the 1 screw and remove the intake air duct 1. P.C.Boards Block 1. Remove the upper case according to the section 6.2.
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E 3. Unscrew the 1 screw and remove the P.C.Board attachment fittings with R-P.C.Board. Note: · R-P.C.Board is secured. Be careful not to apply excessive force. 6.7. Removal of V-P.C.Board 1. Remove the upper case according to the section 6.2.
PT-AE3000U / PT-AE3000E All manuals and user guides at all-guides.com 4. Unscrew the 1 screw and remove the P.C.Board 11. Unscrew the 1 screw and separate the B/Q-Module block attachment fittings with R-P.C.Board. and P-Module block. Note: · R-P.C.Board is secured. Be careful not to apply excessive force.
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E 3. While pressing to shut each hook of the 2 resinous stands, remove the P-Module. Note: · When installing the lamp unit in the main unit, place 6.10. Removal of Lamp Unit...
PT-AE3000U / PT-AE3000E All manuals and user guides at all-guides.com "Removal of Upper Case". 2. Unscrew the 2 screws and remove the A-P.C.Board block. 3. Mark positions of the incidence polarizer (G). Note: · Mark accurately as possible because the marks will be used for resetting the incidence polarizer position.
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E 4. Remove the PBS array. 5. Install new PBS array. Note: · Be careful mistake direction (inside/outside, upper/lower). · Be careful not to touch the surface of PBS array. 6.14. Removal of Iris Unit 1.
PT-AE3000U / PT-AE3000E All manuals and user guides at all-guides.com 7 Measurement and Adjustments When the following components in this projector are replaced, adjustments are required. Adjust each item according to the table below. 7.1. Cautions for Adjustment · Never turn off the MAIN POWER switch until every fan completely stops.
Page 23
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E 4. Connect the service kit (extension cables). · Each flexible cable of LCD Panels (R/G/B) - Connectors (A1/A2/A3) on A-P.C.Board · Intake fan connector - Connector (A15) on A-P.C.Board · Power fan connector - Connector (A16) on A-P.C.Board ·...
PT-AE3000U / PT-AE3000E All manuals and user guides at all-guides.com 7.3.3.2. G Reflector Adjustment 1. Turn on the power and display 100 % white pattern on the screen. 2. Loosen the 1 screw fixing the mirror adjusting lever A just until the lever can be shifted.
Page 25
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E 7.4.2. Operating Procedure 1. Run software program by the keyboard entry. Note: · Use the software program as below. Adjustment Tool [AE3000] 2. The first menu is Port selection menu.
Page 26
PT-AE3000U / PT-AE3000E All manuals and user guides at all-guides.com 7.4.4. Data Setting Menu 7.4.4.1. Explanation of Buttons Micom Data [Transmission]: Reads the microcomputer data from the file and transmits it to the projector. Micom Data [Reception]: Receives the microcomputer data from the projector and writes it in the file.
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E Exit: Exits this application. 7.4.4.2. Receiving and transmitting of the data Click a target button and specify a file name. 7.4.5. Adjustment Menu 7.4.5.1. Explanation of Buttons Flicker Adjustment: Displays Flicker Adjustment menu.
PT-AE3000U / PT-AE3000E All manuals and user guides at all-guides.com Changes the setting value and transmits its data. (The 8 and 2 keys on the keyboard have the same functions.) If releasing the mouse or key after pressing it continuously, the data is transmitted once. The variable setting value is enclosed in a box and using the TAB or SPACE key allows the move of the box.
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E · Must use the window pattern of 1 080p (1 920 x 1 280). 3. Click the OK button. 7.7. Serial Number Setup Set the serial number if the A-P.C.Board is replaced and the product serial number disappears.
Page 30
PT-AE3000U / PT-AE3000E All manuals and user guides at all-guides.com 3. Click [FLTR Sensor] button. 4. When "Revision of filter sensor" window is displayed and the window will close automatically in approx. 15 minutes, the correction is completed. Notes: · If the correction cannot start normally, execute it after disconnecting the power plug of the projector and switching ON the projector again.
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E 9.2. Interconnection Block Diagram (2/2) Interconnection Block Diagram (2/2) A-P.C.Board...
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E 10 Block Diagram 10.1. Power Supply Power Supply K2-P.C.Board SWITCHING STB 3.3 V TRANSFORMER SW9101 MAIN PHOTOISOLATOR POWER DETECTOR COLD VOLT_DET 16.5 V THERMOSENSOR SWITCHING INTERLOCK REGULATOR SWITCH SWITCHING TRANSFORMER...
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E 10.3. Signal Processing (2/3) Signal Processing (2/3) (FPGA ACT) D1044 IC1030 X1006 IC1032 IC1145 (27 MHz) LCD PANEL (R) FRAME FPGA CREATION COLOR UNEVENNESS IC1013 IC1147 CORRECTION, EEPROM LCD PANEL...
Page 46
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E 10.4. Signal Processing (3/3) Signal Processing (3/3) A-P.C.Board 5V_SCL H-P.C.Board 5V_SDA HDMI IN 5V_SCL 5V_SDA IC1141 MOTOR ANGLE CONTROL SENSOR DRIVER DRIVER IC1142 5V_SCL Q1024-Q1026 BUFFERS 5V_SDA from/to (1/3)
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E 14 Replacement Parts List Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description TEEC5298 LIGHTING DUCT [MECHANICAL PARTS] TEEC5299 TOP PANEL FIX METAL 2...
Page 70
PT-AE3000U / PT-AE3000E All manuals and user guides at all-guides.com Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description TMKY229-1 LED INSULATION SHEET XQN17+CJ4FJK SCREW(OPTICAL BLOCK) TMKY230 TOP PANEL HOOK XQN2+CJ6FJ SCREW(OPTICAL BLOCK)
Page 71
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description IC1148 C3ABSG000048 D9608 B0ACEM000012 DIODE (B-PCB) IC1149 TVRQ185 D9609 B0ACEM000012 DIODE (B-PCB) IC1150 C0DBAYY00447...
Page 72
PT-AE3000U / PT-AE3000E All manuals and user guides at all-guides.com Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description L1069 J0JCC0000168 FILTER [RESISTORS] L1070 J0JHC0000078 EMI FILTER L1071 J0JHC0000078 EMI FILTER R1000 ERJ3GEYJ104...
Page 73
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R1079 EXB28V220J RESISTOR ARRAY R1164 ERJ3EKF1000 M 100 OHM, 1/16W R1080 ERJ2GEJ220 M 22 OHM, 0.063W...
Page 74
PT-AE3000U / PT-AE3000E All manuals and user guides at all-guides.com Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R1244 ERJ3GEY0R00 M 0 OHM, 1/16W R1338 ERJ3GEYJ102 M 1K OHM,J,1/16W R1246 ERJ2GEJ3R0X M 3 OHM, 0.063W...
Page 75
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R1431 EXB28V220J RESISTOR ARRAY R1518 ERJ3GEYJ221 M 220 OHM,J,1/16W R1432 EXB28V220J RESISTOR ARRAY R1519...
Page 76
PT-AE3000U / PT-AE3000E All manuals and user guides at all-guides.com Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R1711 ERJ2GEJ332 M 3.3KOHM, 0.063W C1004 F1G1C104A077 CAPACITOR R1712 ERJ2GEJ332 M 3.3KOHM, 0.063W C1005...
Page 77
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description C1094 ECJ1VC1H080C CAPACITOR C1170 ECJ2FF1A106Z C 10UF, 10V C1095 F1J1A106A024 CAPACITOR C1171 F1G1C104A077 CAPACITOR...
Page 78
PT-AE3000U / PT-AE3000E All manuals and user guides at all-guides.com Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description C1244 F1G1C104A077 CAPACITOR C1317 F1G1C104A077 CAPACITOR C1245 F1G1H1020008 CAPACITOR C1318 F1G1C104A077 CAPACITOR C1246 F1H1C105A008...
Page 79
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description C1399 F1G1C104A077 CAPACITOR C1486 F1G1C104A077 CAPACITOR C1401 F1G1C104A077 CAPACITOR C1488 F1H1C105A008 CAPACITOR C1402 F1G1C104A077...
Page 80
PT-AE3000U / PT-AE3000E All manuals and user guides at all-guides.com Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description C1565 F1G1C1030008 CAPACITOR C1639 F1G1C104A077 CAPACITOR C1567 F1H1C105A008 CAPACITOR C1640 F1G1C104A077 CAPACITOR C1568 F1H1C105A008...
Page 81
All manuals and user guides at all-guides.com PT-AE3000U / PT-AE3000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description K1KA06B00220 2P CONNECTOR TNPA4812 CIRCUIT BOARD-M3 (TEMP SENSOR) K1KA09B00112 3P CONNECTOR TXANP01VKJ8 CIRCUIT BOARD-A...
