- Page 1 MLMux4 User's Guide Initial Release February 2022...
- Page 2 Systems of such failure during the warranty training in the use of our products. This period, Canary Systems at its option will repair document and our products are intended to be OR replace the nonconforming Product, OR used by technically qualified personnel.
- Page 3 High-Risk Activities Documentation and Release Notes Products of Canary Systems® are not fault- tolerant and are not designed, manufactured To obtain the most recent version of all Canary or intended for use as on-line control Systems® technical documentation, visit the...
- Page 4 The Canary Systems End-Users License Agreement can be found on the Canary Systems website under Software Downloads at (https://canarysystems.com/support/software-downloads/). Technical Support Canary Systems may be contacted directly via phone or email. Ongoing support via phone, email, and virtual meeting platforms such as Microsoft Teams and Zoom is available through the purchase of a support contract.
-
Page 5: Table Of Contents
2.1 Operation Details ......................................7 2.2 Enclosure Installation ....................................8 2.3 Input Protection ......................................9 2.4 Controller Connections ....................................10 2.5 Instrument Connection ....................................11 2.6 MLWebHardware Configuration ................................. 12 Section 3 ‒ Troubleshooting ............................... 13 3.1 Troubleshooting Flowchart ..................................13 MLMux4 User's Guide... -
Page 6: Section 1 - Introduction
A view of the MLMux4 is shown below. Warranty for the MLMux4 is applicable for one year from the date of shipment. The warranty does not cover failure by improper installation, misuse, or by nature including, but not limited to; flood, lightning, fire, or other catastrophe. -
Page 7: Section 2 - Operation And Installation
The MLMux4 is controlled by an MLRemote Module or other Datalogger Controller. This is done using either a single digital signal or two digital control signals. The operation of the MLMux4 is simple enough that virtually any device capable of controlling one or two 5V digital TTL/CMOS type signals can be used to control the multiplexer. -
Page 8: Enclosure Installation
Section 2 ‒ Operation and Installation 2.2 Enclosure Installation The MLMux4 can be mounted to any surface with (4) 6-32 mounting screws. Hint - The MLMux4 comes pre-installed when ordered with the MLRemote. The placement of the mounting holes is depicted in the illustration below. -
Page 9: Input Protection
12V lithium battery pack. The 12V tolerant inputs allow the MLMux4 to be field tested without the need for a datalogger connection. The enable can be wired to the 12V input while the clock input can be carefully touched to 12V. This action will cause the MLMux4 to step channels for each touch to 12 volts. -
Page 10: Controller Connections
The figure below shows an MLMux4 wired to an MLRemote using the four-channel mode using an MLMux4 harness. The MLMux4 harness includes nine multi colored wires that are precut and zip tied to fit the MLRemote / MLMux4 connection. By default, the MLMux4 ships in 4-channel mode. -
Page 11: Instrument Connection
Section 2 ‒ Operation and Installation 2.5 Instrument Connection Instruments are connected to the MLMux4 using the connectors in Group 1, Group 2, Group 3, and Group 4 at the bottom of the MLMux4. The wiring will vary depending on the Mode selection. -
Page 12: Mlwebhardware Configuration
Section 2 ‒ Operation and Installation 2.6 MLWebHardware Configuration To configure MLWebHardware to use the MLMux4 navigate to the Configure Multiplexer form of the device containing the MLMux4 to be configured and Add a new Multiplexer. See the MLWebHardware Users Guide for details on access MLWebHardware and configuring new device programs. -
Page 13: Section 3 - Troubleshooting
Section 3 ‒ Troubleshooting Section 3 ‒ Troubleshooting 3.1 Troubleshooting Flowchart If you cannot obtain readings using the MLMux4 or the readings are unstable then see the troubleshooting flowchart below for help in determining the nature of the problem. MLMux4 User's Guide...
