INSTALLATION GUIDE
BEFORE COMMENCING INSTALLATION OR MAINTENANCE, ENSURE ELECTRICITY
IS SWITCHED OFF AT THE MAINS.
For . mm
cable* place
2
the cable into the channel
and push it down so it's
completely flat.
For . mm
cable*, remove
2
the insert in the centre.
Place the cable* into the
channel and push it down so
it is completely flat.
Align the lid pins with the
channel grooves.
Use a steady firm motion
and slide the cover closed
until you hear a 'click' sound.
This indicates the unit is now
installed securley.
UNIVERSAL POLARITY SAFE.
This product is NOT polarity sensitive,
L & N are interchangable.
Turn over for termination and unlocking guide.
ML - BSRC -XC
ML - BSRC - XC -
