- Page 1 INSTALLATION MANUAL Remote Unit iDAS-R311 HIGH POWER Dual Band Digital Radios 43dBm per Band Passive Cooling...
- Page 2 Sunwave. The information furnished herein is believed to be accurate and reliable. However, no responsibility is assumed by Sunwave for its use or any infringements of patents or other rights of third parties resulting from its use.
-
Page 3: Table Of Contents
Connect Power and Ground Cable to A2 ........................20 A2 Mounting Dimension Spacing ............................20 Installation of the E2-O ................................. 22 Mount the E2-O in the Rack .............................. 22 Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 3 of 47 cf_support@sunwave.com... - Page 4 Dual Port SFP Transceiver ............................. 41 Optical Indicator ................................42 A2 Optical Port Description ............................43 E2-O Optical Port Description ............................43 RU Optical Port Description .............................. 45 Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 4 of 47 cf_support@sunwave.com...
-
Page 5: Overview
Digital Radio Overview CrossFire H2 is a digital transport platform supporting cellular and wideband public safety technologies on fibre optic cable using the CPRI protocol. The power amplifier technology adopts Digital Pre-Distortion, allowing for a significant improvement in power consumption compared with analogue technology. This platform is ideal for multi-operator multi- band deployments of cellular services into large coverage areas, and as an alternative for single operator RAN solutions. - Page 6 Maximum Input Power +15dBm Error Vector Magnitude <3.5% @ 256 QAM Ripple 3dB Typical Manual Gain Control 45dB @ 1dB/step (AU:30dB, RU:15dB) System Delay (AU+EU+RU) 12µS VSWR (AU/RU) 1.5:1 Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 6 of 47 cf_support@sunwave.com...
- Page 7 A2/E2: IP30 (Indoor) | RU: IP65 (Outdoor) Mechanical 440mm / 44mm / 329mm / 8.0kg A2 (Width / Height / Depth / Weight) 17.32in / 1.73in / 12.95in / 17.64lb Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 7 of 47 cf_support@sunwave.com...
-
Page 8: Preface
15.75in / 4.92in / 11.81in / 35.27lb excluding Bands 12, 13 & 14 400mm / 135mm / 300mm / 18.0kg H2-7 (Width / Height / Depth / Weight) 15.75in / 5.31in / 11.81in / 39.68lb for Bands 12, 13 & 14... -
Page 9: Site Considerations
The equipment has to operate at humidity level and temperature range as follow: Maximum humidity: 85% Operating Temperature range: -10°C to +50°C Storage Temperature range: -25°C to +70°C Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 9 of 47 cf_support@sunwave.com... -
Page 10: Dc Power Connections
Connect “-” to a low potential (0VDC from a +48VDC power supply; -48VDC from a -48VDC power supply) Cable Core Cable Length Maximum Expandable Length 14AWG Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 10 of 47 cf_support@sunwave.com... -
Page 11: Warning Marks
ALWAYS disconnect all lines and power connections before servicing or disassembling this equipment. NEVER touch the surface after the device's power on. For performance and safety reasons, NEVER disassemble and remodel the devices. Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 11 of 47 cf_support@sunwave.com... -
Page 12: Unpacking And Inspecting
Verify that the contents and quantities agree with the Delivery Packing List. Check the device model against the Delivery Packing List. Notify SUNWAVE immediately if any discrepancies are discovered, to verify whether the complete and correct shipment has been received. -
Page 13: Installation Preparation
You can mount the fan between the bottom of the device and any other. Maintain 2U clearance between the bottom of the device and any other. Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 13 of 47 cf_support@sunwave.com... -
Page 14: Installation Of The A2
Maintain 150mm clearance from the top of the device to any other planar. Maintain 150mm clearance from both sides of the device to any other planar obstructions. Installation of the A2 Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 14 of 47 cf_support@sunwave.com... -
Page 15: Mount The A2 In The Rack
43dBm Dual Band Digital Radio Mount the A2 in the Rack A2 Accessories A2 Accessories Note: the ground wire of A2 is 12AWG and 2 meter in Accessories package. Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 15 of 47 cf_support@sunwave.com... -
Page 16: Attach A2 Handle
Place the A2 in the rack. Place A2 in Rack Secure the A2 using 2 screws M6×16 on both sides and the Phillips screwdriver. Fix A2 with Screws Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 16 of 47 cf_support@sunwave.com... -
Page 17: Fan Installation
Fan Installation Secure the Fan using 2 screws M6×16 on both sides and the Phillips screwdriver Fix Fan with Screws Plug AC power lead. Plug AC Power Lead Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 17 of 47 cf_support@sunwave.com... -
Page 18: Connect Power And Ground Cable To A2
A2. Connect Power Cable at Rear Side Connect and screw the ground wire at the rear of the A2. Connect Ground Cable at Rear Side Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 18 of 47 cf_support@sunwave.com... -
Page 19: Dc Power Connections
Drill the mounting holes according to the chosen mounting accessories. Marking the position of mounting holes Attach the dowels, expansion screws, or the similar and fasten the A2 to the wall. Mounting completed Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 19 of 47 cf_support@sunwave.com... -
Page 20: Connect Power And Ground Cable To A2
Connect power cable at the rear of the unit Connect and screw the ground wire at the rear of the A2. Connect ground cable at the rear of the unit A2 Mounting Dimension Spacing Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 20 of 47 cf_support@sunwave.com... - Page 21 HIGH POWER 43dBm Dual Band Digital Radio Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 21 of 47 cf_support@sunwave.com...
-
Page 22: Installation Of The E2-O
Installing the E2-O is virtually the same as installing the A2. Please refer to the steps described in the A2 installation for the E2-O. Mount the E2-O in the Rack E2-O Accessories E2-O Accessories Note: the ground wire of E2-O is 12AWG and 2 meter in Accessories package. Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 22 of 47 cf_support@sunwave.com... -
Page 23: Attach E2-O Handle
Place the E2-O in the rack Place E2-O in Rack Secure the E2-O using 2 screws M6×16 on both sides and the Phillips screwdriver. Fix E2-O with Screws Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 23 of 47 cf_support@sunwave.com... -
Page 24: Connect Power And Ground Cable To E2-O
E2-O. Connect Power Cable at Rear Side Connect and screw the ground wire at the rear of the E2-O. Connect Ground Cable at Rear Side Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 24 of 47 cf_support@sunwave.com... -
Page 25: Mount The E2-O On The Wall
Drill the mounting holes according to the chosen mounting accessories. Marking the Position of Mounting Holes Attach the dowels, expansion screws, or the similar and fasten the E2-O to the wall. Mounting Completed Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 25 of 47 cf_support@sunwave.com... -
Page 26: Connect Power And Ground Cable To E2-O
Connect power cable at the rear of the unit Connect and screw the ground wire at the rear of the E2-O Connect ground cable at the rear of the unit Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 26 of 47 cf_support@sunwave.com... -
Page 27: E2-O Mounting Dimension Spacing
HIGH POWER 43dBm Dual Band Digital Radio E2-O Mounting Dimension Spacing Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 27 of 47 cf_support@sunwave.com... -
Page 28: Installation Of The H2Ru
HIGH POWER 43dBm Dual Band Digital Radio Installation of the H2RU Accessories List Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 28 of 47 cf_support@sunwave.com... -
Page 29: Wall Installation (Back On The Wall)
Attach and fasten the handle to the side of H2RU with screws M6×14 using T5 Wrench. Attach and fasten the Bracket I to the back of H2RU with screws M6×14 using T5 Wrench. Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 29 of 47 cf_support@sunwave.com... - Page 30 Mark the position of the drilling holes in the mounting Bracket II. Note: R=13mm. Drill 4 holes at the marked positions. Note: H=70mm Attach the dowels, expansion screws or the like and fasten the Bracket II to the wall. Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 30 of 47 cf_support@sunwave.com...
- Page 31 Tips: use Bracket II as a reference to control each devices’ separation distance before hanging and locking H2RU up. Hang the H2RU on the mounting bracket II and fasten with nuts M10. Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 31 of 47 cf_support@sunwave.com...
- Page 32 HIGH POWER 43dBm Dual Band Digital Radio Fasten the Bracket I and II with screws M6×14. Connect and lock the power cable at the H2RU rear side Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 32 of 47 cf_support@sunwave.com...
- Page 33 HIGH POWER 43dBm Dual Band Digital Radio Connect and screw the ground cable at the H2RU’s left side Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 33 of 47 cf_support@sunwave.com...
-
Page 34: Wall Installation (Side On The Wall)
Attach and fasten the handle to the side of H2RU with screws M6×14 using T5 Wrench. Attach and fasten the Bracket I to the left side of H2RU with screws M6×14 using T5 Wrench. Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 34 of 47 cf_support@sunwave.com... - Page 35 Mark the position of the drilling holes in the mounting Bracket II. Note: R=13mm. Drill 4 holes at the marked positions. Note: H=70mm. Attach the dowels, expansion screws or the like and fasten the Bracket II to the wall. Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 35 of 47 cf_support@sunwave.com...
- Page 36 Tips: use Bracket II as a reference to control each devices’ separation distance before hanging and locking H2RU up. Hang the H2RU on the mounting bracket II and fasten with nuts M10. Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 36 of 47 cf_support@sunwave.com...
- Page 37 Fasten the Bracket I and II with screws M6×14. Connect and lock the power cable at the H2RU rear side Connect and screw the ground cable at the H2RU left side. Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 37 of 47 cf_support@sunwave.com...
- Page 38 HIGH POWER 43dBm Dual Band Digital Radio Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 38 of 47 cf_support@sunwave.com...
-
Page 39: Pole Installation
Connect the ground cable and power cable. Extra accessories are required for pole installation and purchased separately. Note: The diameter of Pole shall not be over 110mm or less than 55mm. Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 39 of 47 cf_support@sunwave.com... -
Page 40: H2Ru Mounting Dimension Spacing
HIGH POWER 43dBm Dual Band Digital Radio H2RU Mounting Dimension Spacing Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 40 of 47 cf_support@sunwave.com... -
Page 41: Optical Connection
B. The optical receiver and transmitter terminals of the optical module can be determined by the triangular mark on the optical module. The triangular mark in the yellow box and the red and blue lines indicate the optical fibre connections. Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 41 of 47 cf_support@sunwave.com... -
Page 42: Optical Indicator
Figure below. When the optical module is unplugged or not synchronized, the indicators are red, as shown in the left pair of indicators. Check whether both indicators turn green after connecting one pair of optical modules. If the indicators are red, the terminal has not synchronized. Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 42 of 47 cf_support@sunwave.com... -
Page 43: A2 Optical Port Description
Obtain the required lengths of optical fibers for all the optical connections and connect the fibers on the front panel of the Expansion Unit. The interface type of SFP transceivers is an LC connector. Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 43 of 47 cf_support@sunwave.com... - Page 44 Connection for RU OP14 Connection for RU Alarm Alarm IN Alarm Alarm OUT CONSOLE Connection for local PC through CAT-5 for local monitoring STATUS Indicates device operating status Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 44 of 47 cf_support@sunwave.com...
-
Page 45: Ru Optical Port Description
Connection for RU at the next lower level Master Indicates Master OP port operating status Indicates device operating status DEBUG Connection for local PC through CAT-5 for local monitoring Reserved Electrical Power Line Interface Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 45 of 47 cf_support@sunwave.com... - Page 46 Le rayonnement de la classe b repecte ISED fixaient un environnement non contrôlés.Installation et mise en œuvre de ce matériel devrait avec échangeur distance minimale entre 400 cm ton corps.Lanceurs ou ne peuvent pas coexister cette antenne ou capteurs avec d’autres. Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 46 of 47 cf_support@sunwave.com...
- Page 47 HIGH POWER 43dBm Dual Band Digital Radio Contact us today: www.sunwave.com © Sunwave IM_CF_H2 v1.0.0 | 47 of 47 cf_support@sunwave.com...
