- Page 1 User Manual RS-232 USB-C Serial Adapter 16” w/ LED Indicators Model No. GM-FTDI2-LED16-C gearmo.com...
- Page 2 Contents - Summary ........................- Hardware Installation & Application ............- Performance Parameters ..................- Connector & Signals ....................- Product Dimensions & Connection Diagram ........- USB to RS-232 Communication ............... - Faults & Troubleshooting ..................gearmo.com/support...
- Page 3 USB 2.0 specifications, used to easily add a serial port to your computer, even if they are unequipped with COM port ability. Works with Windows 10 and lower! GM-FTDI2-LED16-C supports peripherals requiring a serial RS-232 connection through a USB-C type host port of your Laptop or Desktop computer. The 16 inch USB-C to serial adapter allows you to add a single serial port and monitor the status of your connections by using LED activity flashes.
- Page 4 12. Dimensions: 406.4mm x 36mm x 16mm 13. Working environment: -40°C to 85°C, relative humidity of 5% to 95% 14. Supports Win98, 2000, 2003, 2008, XP, Vista, 7, 8, 10, CE, Mac, Linux. Connector & Signals 1. Pin assignment of RS-232 gearmo.com/support...
- Page 5 Product Dimension & Connection Diagram 406.4mm 1. Standard USB Type-C male connector 2. Filter magnetic ring 3. Screened black standard USB 2.0 cable 4. Aesthetic shell (black) with LED Array 5. Standard DB9 male connector 6. Master chip of FTDI company in England gearmo.com/support...
- Page 6 Check receive indicator and see if it flashes f. Check send indicator and see if it flashes 2. Data missing or incorrect a. Check to see whether the data rate and format at both ends of the communication equipment is consistent. gearmo.com/support...
