ASSEMBLY INSTRUCTIONS
INSTALLATION
Position the plank on the substructure. Depending on the wood
1
type, it may be necessary to keep a distance between the plank
and the substructure (TENAX spacer, EPDM band 3 mm, etc.).
The advantages of the procedure are better back ventilation
and the prevention of waterlogging.
Position the drill tool on the plank in alignment with the
2
substructure.
For any type of wood, the mounting points should be
3
pre-drilled using a step drill (3.3 mm to 4.5 mm).
© by E.u.r.o.Tec GmbH · Last updated 03/2022 · Subject to changes, additions, typesetting and printing errors.
E.u.r.o.Tec GmbH • Unter dem Hofe 5 • D-58099 Hagen
Tel. +49 2331 62 45-0 • Fax +49 2331 62 45-200 • E-Mail info@eurotec.team
Deck construction and landscaping
DRILL TOOL 50X
Page 1 of 2
www.eurotec.team
Advertisement
Table of Contents
Related Manuals for Eurotec DRILL TOOL 50X
Summary of Contents for Eurotec DRILL TOOL 50X
- Page 1 © by E.u.r.o.Tec GmbH · Last updated 03/2022 · Subject to changes, additions, typesetting and printing errors. E.u.r.o.Tec GmbH • Unter dem Hofe 5 • D-58099 Hagen www.eurotec.team Tel. +49 2331 62 45-0 • Fax +49 2331 62 45-200 • E-Mail info@eurotec.team...
- Page 2 ≥ 6 mm must be used to prevent the tool from getting jammed or even damaged. If you are not familiar with how this product is used, and particularly with the product’s intended use, please contact our Application Technology department (technik@eurotec.team). Page 2 of 2 ©...
