❾
Release tab
10
Indents for double sided mounting tape
11
Mounting holes
12
Power cable slot
4
10
11
12
Mounting your
Alarm.com
Smart Chime
❶
Plug in the Alarm.com Smart Chime
and ensure you have enough cable to
run from the outlet to the mounting
location.
❷
Drill holes in the desired mounting
location and use drywall anchors and
screws as required.
❸
Leave enough of the screw head out of
the wall and mount the chime using
the mounting holes (see image).
❹
If desired, place the adhesive strips
provided on the back of the device to
adhere to the wall.
5
