Page 1: Digital Audio Player
AH68-01036A (Rev 2.0) Digital Audio Player Digital Audio Player MP3, WMA file playback 64MB/128MB internal memory FM Radio Voice Recording D. I. Y. Support Fashion Backlight Long time playback (15 hours) High-Speed USB YP-90S (64MB) YP-90H (128MB) -
Page 2: Table Of Contents
Contents Preparations Features ...4 Components ...5 Location of Controls ...6 Inserting Batteries ...7 Basic Usage Listening to Music with yepp...8 Setting up Volume/Hold Functions ...9 Changing Modes...10 Recording Voice ...11 Searching for Music/Voice Files ...12 Listening to FM ...14 Additional Usage Loop Repeating ...16 Setting up Menu ...17 Repeating Tracks ...18... -
Page 3: Features
Features CD quality sound. Fashion Backlight Miniature Design Small and light. Voice Recording D.I.Y. Support Max. 480 minutes recording Logo Embellishment available (128MB standard) Adjustable Scroll Speed Adjustable Contrast High Speed USB Fast Downloading Speed MP3, WMA file Playback MAX. 5Mbps Components Earphones Carrying case... -
Page 4: Location Of Controls
Location of Controls Front Earphones Jack Microphone Display Window Voice Recording Button Rear Play/Stop/ Forward/Backward Button MENU/Mode/Loop Repeating Button Volume LCD panel seems to be misty. Please peel off the tape from USB Cable the LCD panel. Connection Port Inserting batteries Press and pull the cover in the Inserting batteries to the right poles (... -
Page 5: Listening To Music With Yepp
Listening to Music with yepp First, insert batteries and connect the earphones to the player. Playing Music Stopping Music (Power On) When you press the button, the When you press the yepp logo appears and a music/voice the music stops. file/FM is played. -
Page 6: Changing Modes
Changing Modes Changing to Voice Mode Stop playing music and press the button short to change to voice mode. Press the button to play. Changing to Music Mode Stop playing voice and press the button short twice to change to music mode. -
Page 7: Searching For Music/Voice Files
Searching for Music/Voice Files Searching for Specific Parts in a Track (Music/Voice file) Press the to find and listen to the part you choose. Release the There you’ll Be love Tr001 00:04:35 VI002.WAV Tr001 00:04:35 Searching for Music/Voice Files in Play Press the button for longer while playing to play the next track. -
Page 8: Listening To Fm
Listening to FM FM On / Off Press the button during FM reception to turn the radio Off, and repress it to turn On. 103.50MHz 103.50MHz Ch01 STOP Ch01 Changing the FM Channels Press the button short during FM reception to move to the previous/next channel. -
Page 9: Loop Repeating
Loop Repeating Loop Function Starting Point While playing music/voice files, Press the press the button short at the last point of the loop. the first part that you want to set up the loop. flickers in the display. Press the button short to cancel the loop. -
Page 10: Repeating Tracks
Repeating Tracks Track Repeating Function In MENU, select 1.Play mode. In PLAY MODE, use the button to move to the mode you want and press the button to select. Normal: To play all the tracks in order one time. Shuffle: To play tracks at random. Repeat one: To repeat one track. -
Page 11: Managing Files (Deleting/Formatting)
Managing Files Deleting In MENU, select 5. File In File, select Delete and the mode the target file is in. Move to the file to delete and press the button to select. The file is deleted. Select Cancel to exit the mode. Formatting In MENU, select 5. -
Page 12: Customizing Options (Setting)
Customizing Options Setting Up Function In MENU, select 4. Setting Use the button to move to the function you want to change and select the function by using the button. Contrast Press the button to set up the contrast. Backlight Backlight ON Never: No Backlight 1 sec. - Page 13 Display 1. Information Play time: displaying current play time Compression: displaying compression rate Remain time: displaying remained play time Free memory: displaying remained memory Total time: displaying total play time Display 2. Logo Default Setting Default: "yepp" logo User define: displaying user-defined logo None: displaying no logo.
-
Page 14: Installing Software (Pc)
Installing Software (PC) Insert the installation CD into CD-ROM drive. Then the picture appears as shown below. Select [yepp Audio Manager] [yepp Audio Manager Install]. Click [Next] for a series of windows that appear. Before using yepp Audio Manager, make sure to set up options (refer to p.39) How to delete the yepp Audio Manager (Rioport Manager): [Start]... -
Page 15: Installing Software (Mac)
Installing Software (Mac) To install the Mac iTunes Plug-in, iTunes 1.1 version or more should be installed in your system. If you have installed by using the Mac OS 9 installation CD or Mac OS X installation CD, the system is basically installed. - Page 16 Double-Click the installation program, then the following screen appears. Press the [Continue] button here. In case of OS 9 In case of OS X The following figure is the main screen of the installation program. To continue installation, press the [Install] button at the right bottom, then installation starts.
-
Page 17: Connecting To Computer
Connecting to Computer System Requirements. Plug one end of the USB cable into the USB port at the back of a computer. Pentium 133MHz or over Windows 98/ME/2000/XP Mac (9 ~ X) Open the USB cover on the right side of yepp 20MB of available hard disk space and connect the other end of the USB cable to the USB port of yepp. -
Page 18: Manual Installation Of Usb Driver
Manual Installation of USB Driver In case of being not installed USB driver automatically, connect yepp to PC and install USB driver manually (How to check USB driver: refer to 39 page) In Windows 98/ME Click [Next] button for a series of windows that appear. Insert installation CD and select drive. - Page 19 In Windows XP Insert Installation CD into CD-ROM Connect yepp to PC. drive. The screen below will appear. Select [Search removable media Select [Install from a list or (floppy, CD-ROM...)] and click [Next] specific location (Advanced)] and click [Next]. Sometimes the message below will appear. This software will not impair or destabilize the correct operation of your system.
-
Page 20: Setting Up Option Function (Pc)
If USB driver is not installed, try one more time after rebooting the PC. (If USB driver is not installed at the second attempt, contact your PC manufacturer.) When USB driver is installed, "SAMSUNG YP-90" will appear in [System Properties] [Device Manager] as shown in the picture on the right. -
Page 21: Copying Files To Yepp (Pc)
Copying Files to yepp (PC) Before copying files, turn on the power of yepp and connect yepp to PC. (To use yepp Audio Manager in the FM mode, change the mode to Music or Voice first.) Run yepp Audio Manager. Double-click yepp Audio Manager icon on your desktop. -
Page 22: Copying Files To Yepp (Mac)
Copying Files to yepp (Mac) Before copying files to yepp, execute iTunes. Connect yepp to Mac, turn on the power of yepp and then proceed. (To use yepp Audio Manager in the FM mode, change the mode to Music or Voice first.) To copy files to yepp, Drag &... -
Page 23: Deleting Files (Pc)
Deleting Files (PC) Before deleting files, turn on the power of yepp and connect yepp to PC. Run yepp Audio Manager. Select the file to delete. Double-click yepp Audio Manager icon on your desktop. Press the ( Select [copy to devices]. Deleting Files (Mac) Before deleting files, execute iTunes. -
Page 24: Formatting (Pc)
Formatting (PC) Before formatting, turn on the power of yepp and connect yepp to PC. Run yepp Audio Manager. Double-click yepp Audio Manager icon. Select [copy to devices]. Click on the [Format Media]. Make sure to connect yepp to PC and refresh before conducting a format. Formatting (Mac) Before formatting files, execute iTunes. -
Page 25: Uploading Files (Pc)
Uploading Files (PC) Before uploading files, turn on the yepp and connect yepp to PC. Run yepp Audio Manager. Double-click yepp Audio Manager icon on your desktop. On the right side window, check the Select [Refresh] file that you’d like to transfer to PC. Click on the [Upload From Portable]. -
Page 26: Make Mp3 File From An Audio Cd (Pc)
Make MP3 files from an Audio CD (PC) Make sure to install yepp Audio Manager on PC before making an MP3 file. You can make MP3 files though yepp Audio Manager. Run yepp Audio Manager. Insert the audio CD into the CD-ROM drive. -
Page 27: Rearranging Files
Rearranging Files (PC) You can change the order that the files are played. Run yepp Audio Manager. Double-click yepp Audio Manager icon on your desktop. Select the file to rearrange. Changing a File Name (Mac) Before changing a file name, execute iTunes. Connect yepp to Mac, turn on the power of yepp and then proceed. -
Page 28: Description Of Buttons
Description of Buttons BUTTON STATUS PRESSING LENGTH Power Off Longer than 1 Second Playback MENU Mode Short Voice Recording Longer than 1 Second Voice Recording Pause Short Intro Playback Playback Short Playback Longer than 1 Second Stop MENU Mode BUTTON RESPONSE Power On, and play Stop(When no button input for 5... -
Page 29: Menu Table
MENU Table Play mode Normal Normal Repeat one Classic Jazz Repeat all Rock Shuffle Intro User mode Go up Go up MENU Setting Hold Confirm Contrast Cancel Backlight Scroll speed Bass Treble Display Go up Go up Select with the button and move with the button. -
Page 30: Precautions
Precautions 1. Do not drop or press on it. 2. Make sure not to let water in it If it got wet, remove batteries, dry it with towel and contact the service center. 3. Keep out of humid, hot or magnetic places. 4. -
Page 31: Security
Security You can get legal MP3 files from a growing number of internet sites. What is SecuMax? With the increasing amount of digital multimedia content, the content providers became concerned with the ease in which the content could be copied and distributed in violation of their copyrights. -
Page 32: Safety Information
City, Kyungki-Do, Korea 442-742 Reorient or relocate the receiving antenna. declares under its sole responsibility that the product Trade Name: Samsung Electronics Co., Ltd Increase the distance between the equipment and receiver. Model Number: YP-90 Connect the equipment to an outlet on a circuit different from has been tested according to the FCC/CISPR22/95 that to which the receiver is connected. -
Page 33: Warranty
The liability of 2. Samsung's obligations are to the repair of the defective Samsung and its appointed maintenance part, and at its discretion, replacement of the product company is limited to the cost of repair and/or (service exchange unit). - Page 34 FIRM OR CORPORATION WITH RESPECT TO THIS PRODUCT, IS NONTRANSFERABLE AND STATES PRODUCT SHALL BE BINDING ON SAMSUNG, YOUR EXCLUSIVE REMEDY. SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS,FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL...
