Spectrum Compact v2.0
user manual
API User Manual
Spectrum Compact 0.3-3 GHz v2
Spectrum Compact 2-8 GHz v2
Spectrum Compact 6-20 GHz v2
Spectrum Compact 16–26.5 GHz v2
Spectrum Compact 24–40 GHz v2
Spectrum Compact 24–43 GHz v2
API
v.1.0
(J0SSAP33)
(J0SSAP55)
(J0SSAP52)
(J0SSAP53)
(J0SSAP74)
(J0SSAP54)
0

Advertisement

loading
Need help?

Need help?

Do you have a question about the Spectrum Compact 0.3-3 GHz v2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SAF Spectrum Compact 0.3-3 GHz v2

  • Page 1 Spectrum Compact v2.0 user manual API User Manual v.1.0 Spectrum Compact 0.3-3 GHz v2 (J0SSAP33) Spectrum Compact 2-8 GHz v2 (J0SSAP55) Spectrum Compact 6-20 GHz v2 (J0SSAP52) Spectrum Compact 16–26.5 GHz v2 (J0SSAP53) Spectrum Compact 24–40 GHz v2 (J0SSAP74) Spectrum Compact 24–43 GHz v2...
  • Page 2 If there is any conflict between this document and compliance statements, the latter will supersede this document. SAF Tehnika, JSC has no liability for typing errors in this document or damages of any kind that result from the use of this document.
  • Page 3: Table Of Contents

    Spectrum Compact v2 API user manual v.1.0 1 Contents 2 Introduction ..................... 3 3 Installing Spectrum Compact drivers ........... 3 4 Establish PC connection with Spectrum Compact ......5 5 Spectrum compact API command line commands Table 1 ....8 6 API CLI commands and description Table 2 ........
  • Page 4: Introduction

    Spectrum Compact v2 API user manual v.1.0 2 Introduction Welcome to the Spectrum Compact family! Spectrum Compact is a handheld, field-ready spectrum analyzer. This guide is prepared to show you how to install and use Spectrum Compact via Application Programming Interface (API). The guide will contain two tutorials that show you how to communicate with Spectrum Compact via a USB interface.
  • Page 5 Spectrum Compact v2 API user manual v.1.0 Please note that installing all Spectrum Compact driver installation files is a prerequisite to communicate with Spectrum Compact. Click Extract all, and unzip Windows driver installation file. Choose a supported Operating system. Begin the installation process by double-clicking on install_sc_drivers application file.
  • Page 6: Establish Pc Connection With Spectrum Compact

    Spectrum Compact v2 API user manual v.1.0 4 Establish PC connection with Spectrum Compact Locate and open “Control panel” in Windows OS and choose “Windows Device Manager”. Before connecting Spectrum Compact to PC locate COM ports that have been used by other devices.
  • Page 7 Spectrum Compact v2 API user manual v.1.0 Connect Spectrum Compact to PC and identify COM port that will be used to communicate between PC and Spectrum Compact. Right-click on the new COM port in the “Ports” list. Then choose properties and change default communication settings.
  • Page 8 Spectrum Compact v2 API user manual v.1.0 Open any terminal emulator program such as Termite or Putty. Change connection type to “Serial”. Change the default COM port to the COM port that has been identified as the COM port for Spectrum Compact and also change “Speed” to 115200. Click Open and launch a new Spectrum Compact terminal window.
  • Page 9: Spectrum Compact Api Command Line Commands Table 1

    Spectrum Compact v2 API user manual v.1.0 5 Spectrum compact API command line commands Table 1 Frequency range 0.3-3 GHz 2-8 GHz 6-20 GHz 16-26.5GHz 24-40 GHz 24-43 GHz FW version V 5.2.8.6 V 5.4.3.6 V 5.4.3.6 V 5.3.6.12 V 5.3.6.12 V 5.3.6.12 Product number (P/N) J0SSAP33...
  • Page 10 Spectrum Compact v2 API user manual v.1.0 Frequency range 0.3-3 GHz 2-8 GHz 6-20 GHz 16-26.5GHz 24-40 GHz 24-43 GHz FW version V 5.2.8.6 V 5.4.3.6 V 5.4.3.6 V 5.3.6.12 V 5.3.6.12 V 5.3.6.12 Product number (P/N) J0SSAP33 J0SSAP55 J0SSAP52 J0SSAP53 J0SSAP74 J0SSAP54...
  • Page 11 Spectrum Compact v2 API user manual v.1.0 Frequency range 0.3-3 GHz 2-8 GHz 6-20 GHz 16-26.5GHz 24-40 GHz 24-43 GHz FW version V 5.2.8 V 5.4.3.6 V 5.4.3.6 V 5.3.6.12 V 5.3.6.12 V 5.3.6.12 Product number (P/N) J0SSAP33 J0SSAP55 J0SSAP52 J0SSAP53 J0SSAP74 J0SSAP54...
  • Page 12 Spectrum Compact v2 API user manual v.1.0 Frequency range 0.3-3 GHz 2-8 GHz 6-20 GHz 16-26.5GHz 24-40 GHz 24-43 GHz FW version V 5.2.8 V 5.4.3.6 V 5.4.3.6 V 5.3.6.12 V 5.3.6.12 V 5.3.6.12 Product number (P/N) J0SSAP33 J0SSAP55 J0SSAP52 J0SSAP53 J0SSAP74 J0SSAP54...
  • Page 13: Api Cli Commands And Description Table 2

    Spectrum Compact v2 API user manual v.1.0 6 API CLI commands and description Table 2 API commands Description Displays available commands. Displays information about hardware version, firmware version, and firmware release date. freq Displays selected frequency information in the following format in kHz: Start Freq - selected sweep start frequency...
  • Page 14 Spectrum Compact v2 API user manual v.1.0 API commands Description sweepc Sweeps the specified spectrum range with the minimum allowed <start frequency in kHz> frequency step continuously and returns the power values in dBm*. <end frequency in kHz> Sweeping by default is done using the minimal frequency step for the currently selected RBW.
  • Page 15 Spectrum Compact v2 API user manual v.1.0 API commands Description dtmode Return currently selected detector mode: dtmode Sets detector mode in the following format: < 0 | 1 | 2 > time Returns current Spectrum Compact system time. time Sets time on Spectrum Compact in the following format: <hours>...
  • Page 16 Spectrum Compact v2 API user manual v.1.0 API commands Description trace Returns the currently selected trace mode displayed on the screen of Spectrum Compact: 1 – normal 2 – maxhold 3 – minmaxhold 4 – cumulative 5 – average2 6 – average 4 7 –...
