Other Information
Image Retention (Burn In) Issue.
The cable/set top box remote control
doesn't turn the TV on or off, or adjust the
Caption on TV menu is greyed out.
A "Mode Not Supported" message
There is a plastic smell from the TV.
The TV Signal Strength is unavailable in
the Self Diagnostic Test menu.
The TV is tilted to the side.
The channel menu is greyed out
Your settings are lost after 30 minutes or
every time the TV is turned off.
You have intermittent loss of audio or
You see small particles when you look
closely at the edge of the frame of the TV.
POP (TV's internal banner ad) appears on
the screen.
Some of above pictures and functions are available at specific models only.
Open Source License Notice
In the case of using open source software, Open Source Licenses are available on the product menu.
Open Source License Notice is written only English.
Solutions and Explanations
• To minimize the possibility of screen burn, this unit is equipped with screen burn reduction technology.
Pixel Shift technology enables you to set picture movement up/down (Vertical Line) and side to side
(Horizontal Dot).
• Program the Cable/Set remote control to operate the TV. Refer to the Cable/Set user manual for the
• Caption can not be selected in the TV menu when connected via HDMI or Component (p. 20).
• Caption must be activated on the external device (p. 20).
• Check the supported resolution of the TV, and adjust the external device's output resolution
accordingly. Refer to the resolution settings on page 10 of this manual.
• This smell is normal and will dissipate over time.
• This function is only available with digital channels from an Antenna / RF/Coax connection (p. 21).
• Remove the base stand from the TV and reassemble it.
• The Channel menu is only available when the TV source is selected.
• If the TV is in the Store Demo mode, it will reset audio and picture settings every 30 minutes. Change
the settings from Store Demo mode to Home Use mode in the Plug & Play procedure. Press the
button to select TV mode, and go to
• Check the cable connections and reconnect them.
• Loss of audio or video can be caused by using overly rigid or thick cables. Make sure the cables are
flexible enough for long term use. If mounting the TV to a wall, we recommend using cables with 90
degree connectors.
• This is part of the product's design and is not a defect.
• Select Home Use under Plug & Play mode. For details, refer to Plug & Play Feature (p. 8).
TruSurround HD, SRS and
TruSurround HD technology is incorporated under license from SRS Labs, Inc.
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are
trademarks of Dolby Laboratories.


symbol are trademarks of SRS Labs, Inc.
→ Setup → Plug & Play → ENTERE (p. 8).
