Summary of Contents for Desview P5II
- Page 1 User Manual...
-
Page 2: Table Of Contents
Contents Notice ■ Product Overview ■ Operation ■ Settings ■ Technical Data ■ Disposal and Conformity ■ Warranty ■... -
Page 3: Notice
Desview. Desview is not responsible for any loss of injury or any liability arising from direct or indirect use of the product. Follow all security guidelines, including but not limited to this user manual. -
Page 4: Product Overview
PRODUCT OVERVIEW Front view Rear view Battery slot (NP-F) 152.3 mm Top view Bottom view Exit button 8V DC output Left Right Menu (5.5 x 2.1 mm) 3.5 mm jack 1/4" connection Power on/off switch button button button connection USB connection... - Page 5 PRODUCT OVERVIEW Left view Right view HDMI output DC input 1/4" connection (5.5 x 2.1 mm) HDMI input...
- Page 6 PRODUCT OVERVIEW Rechargeable Batteries The monitor supports batteries of type NP-F550, NP-F750 and NP-F970. NP-F battery series...
-
Page 7: Operation
OPERATION Menu Press the menu button to enter the menu screen. Press the left or right button to select a function. After exiling the menu, the exit, left and right buttons are shortcut buttons and can be configured. Exit button Menu button Right button Left button... - Page 8 OPERATION LUT Import Plug the USB stick into monitors USB connection. USB connection Select "LUT" on the monitor and press the menu button to select "SEARCH USB". Press the left/right buttons to expand the log file on the USB stick and press the menu button to load it. After loading, the icon of the log file will appear.
- Page 9 OPERATION LUT Import Select /\ in the LUT settings, press the left/right buttons to confirm, open the list of loaded LOG files, and press the left/right buttons to select the desired LOG files for automatic loading.
- Page 10 OPERATION Firmware Upgrade Fomate the USB stick as "FAT32 formal" with a computer. Copy the downloaded upgrade file into the USB stick. Insert the USB stick into the monilor's USB connection. Bring up the shortcut key of multi-function adjustment, press the menu button to select software upgrade, and press the left/right buttons to select "OK".
-
Page 11: Settings
SETTINGS False Color Zebra Histogram Waveform Peaking Single Color Short key Battery Anamorphic... - Page 12 SETTINGS Aspect Ratio Grid Lines Center Mark Save Area Mark Ratio Display Flip Audio Meters Zoom Color Other Config Software Update (USB)
-
Page 13: Technical Data
TECHNICAL DATA Screen size 5.5 inch Dimensions 15.2 x 9.8 x 2.8 cm Weight 170 g Resolution 1920x1080 Contrast 1000:1 Brightness 800nits Viewing angle 180° (H/V) Backlight Material ABS engineering plastic Voltage DC 7– 24 V Power ≤ 7 W Signal input HDMI 1.4 Signal output... - Page 14 TECHNICAL DATA HDMI input signal format HDMI ouput signal format 720x480i & 720x480p @ 59.94, 60 Hz 720x480i & 720x480p @ 59.94, 60 Hz 720x576i & 720x576p @ 50 Hz 720x576i & 720x576p @ 50 Hz 1280x720p @ 50, 59.94, 60 Hz 1280x720p @ 50, 59.94, 60 Hz 1920x1080i @ 50, 59.94, 60 Hz 1920x1080i @ 50, 59.94, 60 Hz...
-
Page 15: Disposal And Conformity
Do not dispose old devices into the household waste! If the Desview P5II is no longer used, every consumer is legally obligated to dispose them separately from the household waste, for example, at a collection site of his community / city district. -
Page 16: Warranty
WARRANTY Warranty The statutory liability for defects exists. The statutory warranty applies to the purchased product, except for consumables and wearing parts, which may also be worn out during the warranty period through proper use. The warranty period is two years from delivery of the goods. - Page 17 WARRANTY Warranty Card USER INFORMATION Name Phone: Add: SALES INFOMATION Sale Date: Distributor Name: Distributor Tel: REPAIR LOG Repair Date: Repair name: Issue: Result: repaired not repaired return...
- Page 18 Imported by: Rollei GmbH & Co. KG In de Tarpen 42 D-22848 Norderstedt Service Hotline +49 40 270750277 Item No.: 28808 Production: 2022/05...
