- Page 1 USER’S MANUAL Decentralized ventilation system AIRRIA- MU1000-0-075 AIRRIA v1.3...
- Page 2 v1.3...
- Page 3 Airria-MU1000-0-075 ventilation unit, and which could accumulate in the unit if it is not the case. Please operate the Airria-MU1000-0-075 ventilation unit at maximum level (level 5) 15 minutes every day to avoid any dust and/or condensates accumulation.
-
Page 4: Precautions And Warnings
In order to ensure the good functioning of the Airria-MU1000-0-075 ventilation unit, Airria-certified filters have to be used. If it is not the case, it could void the warranty, and Airria will not be held responsible for any damages. - Page 5 3. Introduction Airria-MU1000-0-075 ventilation units are conceived to ensure the basic hygienic ventilation, needed for any residential building. The main advantages of decentralized Airria systems with heat recuperation are: - The end of ventilation networks that are hard to maintain, to make airtight, and to calibrate...
- Page 6 Depending upon the installations, a network can be realized: One remote can control several AHU (centralized command) Several remotes (maximum 10) can control the same AHU (co-existence of centralized and local remotes). 5. AHU utilization Make sure that the ventilation unit was correctly installed by an expert, according to the assembly instructions, and that the unit is not damaged.
- Page 7 Figure 2: Turning on the AHU 5.2 Common use By default, the AHU runs at level 1 (minimum level) Figure 3: Control panel To increase the ventilation level: Press R5. Each pressing will lead to an emission of one of more beep(s) corresponding to the ventilation level Level Flow [m³/h]...
- Page 8 To decrease the ventilation level: Press R6. Each pressing will lead to an emission of one or more beep(s) corresponding to the ventilation level. To go into simple flow/double flow mode: Press R4 to go from simple flow mode to double flow mode, or the contrary.
- Page 9 Notes: In some special cases, the moisture may remain too high in the room, even if the flow is at its maximum. This will be seen in those situations: - The momentary abnormal weather conditions make that the indoor relative humidity may not be lower than the set point (very hot and humid weather).
- Page 10 It is recommended to let the AHU in the bedrooms operate a minimal level during the night. Use the “sleep” mode is the AHU represents any discomfort to falling asleep. The R1 switch is only for the installators. It allows them to define the parameters of the Airria- MU1000-0-075 ventilation unit.
- Page 11 5. A long push (2 seconds) on the up arrow (P3) will put the system in boost mode, which puts the ventilation at maximum level for 15 minutes. After this boost period, the AHU operates again at level 1 (minimal level). 6.2 Changing the battery of the remote 1.
-
Page 12: Changing The Filters
3. Link of the remote to the AHU is signaled by the beep of the AHU now being intermittent. You can now let go of the R2 button. 7.3 Removing a remote 1. Push the R3 button and keep it pushed down. The buzzer emits a short beep, followed by a intermittent beep. - Page 13 9.2.1 Open the hood See section 5.1.1 9.2.2 Turn off the unit Turn the Airria-MU1000-0-075 ventilation unit off by pushing the ON/OFF switch (up and left of the AHU) into the OFF position ( Figure 5 ). The unit is off when the little circle of the switch is pushed down.
- Page 14 Figure 5 : Turning OFF the UHA 9.2.3 Wait for 30 seconds Wait for 30 seconds to be sure that the fans are completely stopped. 9.2.4 Take the filters Take both filters out of the unit, as pictured on Figure 6 , by pulling the little handle that is provided.
- Page 15 If the red LED is still lit up, press button R4. 9.2.7 Turning the unit on again. Turn the Airria-MU1000-0-075 ventilation unit back on, by pushing the ON/OFF switch, up and left of the AHU, into the ON position ( Figure 10 ).
-
Page 16: Maintenance
Place the palms of your hands on the front side of the casing, and push it as far as you can. Figure 11: Closing the hood 10. Maintenance The Airria-MU1000-0-075 ventilation unit only requires a little bit of attention. 10.1 Cleaning the external grid It is recommended to clean the external grill, at least once a year, preferably during autumn. - Page 17 11. Performances and technical characteristics - Each receptor can memorize up to 10 emettors - RF remote battery: CR2430 3V 12. Warranty Recording device (for validity) e_mail: Phone number: address: number of devices: v1.3...
