Infinity RS-4 Technical Manual

Technical Manual
RS-4
ACOUSTIC & ELECTRICAL SPECIFICATIONS
• Nominal Impedance
• Max Amp Power
• Frequency Response
• Sensitivity
• Crossover Frequency
SYSTEM COMPONENTS:
• Cabinet (Black)
(Cherry)
• Grille (Upper)
(Lower)
• Low Frequency
Transducer
DC Resistance
• High Frequency
Transducer
PACKAGING
Top Foam
331081-001
Bottom Foam
333378-001
Outer Carton
333375-001
8 ohms
175 watts
38Hz – 20kHz
90 dB SPL, 1 watt @ 1 meter
2800Hz
(Not for sale)
(Not for sale)
333203-001
330976-001
6 1/2" (160mm) Co-injected
woofer, shielded 333235-001
5.6 ohms ±10%
1" (25mm) Neodymium
Soft Dome 333232-001
Owner's Manual
333374-001
Warranty Card
333715-001
Spiked Foot Set
331360-001
Survey Card
330033-001
OWNER'S
MANUAL
Infinity Systems, Inc. 250 Crossways Park Dr., Woodbury, New York 11797
SYSTEM COMPONENTS: (cont.)
DC Resistance
• Crossover Network
AURAL SWEEP TEST SPECIFICATIONS:
• System Aural Sweep Test 6.0V Input 20 Hz to 20 kHz
• L.F. Aural Sweep Test
• H.F. Aural Sweep Test
PHYSICAL SPECIFICATIONS
• Enclosure dimensions:
SHIPPING WEIGHT:
• 33.9 lbs. (15.2 kg) Each
WARRANTY:
• Refer to Warranty Statement packed with each product.
WIRING DIAGRAM
Driver
High Frequency
333232-001
Black
Driver
Low Frequency
333235-001
Red/Black
RS-4 SCHEMATIC
L1
0.65 mH
+IN
INPUT
—IN
R1
6.8ohm, 5W
3.6 ohms ±10%
333379-001
6.0V Input 20 Hz to 3 kHz
2.0V Input 2 kHz to 20 kHz
35 1/2" x 7 1/2" x 14 3/8"
(H x W x D)
(902x190x365mm)
333379-001
Network
Blue
Red
32" RED
C1
60.0 mfd
50V
L2
0.17 mH C2
30.0 mfd
50V
32" RED/BLACK
C3
6.0 mfd, 50V
34" BLUE
L3
0.09 mH
32" BLACK
.250 +
LF
—
.205
+
.205
HF
.110
—
12-98
