Summary of Contents for Jaspi Inverter Nordic 8
- Page 1 User manual JÄSPI Inverter Nordic 8, 12, 16, 20 Air/water heat pump UHB EN 2214-4 331844...
-
Page 3: Table Of Contents
Table of Contents 1 Important information Installation data Safety information Symbols Serial number JÄSPI Inverter Nordic – An excellent choice 2 Installation function 3 Control of JÄSPI Inverter Nordic 4 Maintenance of JÄSPI Inverter Nordic Regular checks In event of long power cuts Silent mode Updating the software 5 Disturbances in comfort... -
Page 4: Important Information
1 Important information Installation data Product JÄSPI Inverter Nordic Serial number Installation date Installer Serial number must always be given. Certification that the installation is carried out according to instructions in the accompa- nying installer manual and applicable regulations. Date __________________ Signed _________________________... -
Page 5: Safety Information
Safety information This appliance is designed for use in a home environ- ment and not intended to be used by persons (includ- ing children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person respons- ible for their safety. -
Page 6: Symbols
Symbols Explanation of symbols that may be present in this manual. NOTE This symbol indicates danger to person or machine. Caution This symbol indicates important information about what you should observe when maintaining your installation. This symbol indicates tips on how to facilitate using the product. Serial number The serial number can be found at the top left on the rear cover and at the bottom on the side. -
Page 7: Jäspi Inverter Nordic - An Excellent Choice
JÄSPI Inverter Nordic – An excellent choice JÄSPI Inverter Nordic is an air/water heat pump, specially designed for the Nordic climate, which uses the outdoor air as its energy source. The heat pump is intended for connection to water borne heating systems and can both heat hot water effectively at high outdoor temperatures and give a high output to the heating system at low outdoor temperatures. -
Page 8: Installation Function
2 Installation function An air/water heat pump installation uses the outdoor air to heat up a home. The conversion of the outdoor air’s energy into residential heating occurs in three different circuits. From the outdoor air, (1) , free heat energy is retrieved and transported to the heat pump. - Page 9 Outdoor air The outdoor air is sucked into the heat pump. The fan then routes the air to the heat pump’s evaporator. Here, the air releases the heating energy to the refrigerant and the air's temperature drops. The cold air is then blown out of the heat pump.
-
Page 10: Control Of Jäspi Inverter Nordic
3 Control of JÄSPI Inverter Nordic The heat pump is controlled in various ways, depending on your system. You control the heat pump via your indoor module JÄSPI Theowatti Air or control module JÄSPI_MCU40. See the Installer Manual for the indoor module/control module. During installation, the installation engineer adjusts the necessary settings for the heat pump in the indoor module or control module, so that the heat pump works optimally in your system. -
Page 11: Maintenance Of Jäspi Inverter Nordic
4 Maintenance of JÄSPI Inverter Nordic Regular checks When your heat pump is located outdoors some external maintenance is required. NOTE Insufficient maintenance can cause serious damage to JÄSPI Inverter Nordic, which is not covered by the guarantee. Checking grilles and bottom panel on JÄSPI Inverter Nordic Check regularly throughout the year that the grille is not clogged by leaves, snow or anything else. - Page 12 Keep free of snow and ice F2120 F2120 Prevent snow from building up and covering the grilles and drain holes on JÄSPI Inverter Nordic. F2120 Keep free of snow and/or ice. Chapter 4 | Maintenance of JÄSPI Inverter Nordic JÄSPI Inverter Nordic...
-
Page 13: In Event Of Long Power Cuts
Cleaning the outer casing If necessary the outer casing can be cleaned using a damp cloth. Care must be exercised so that the heat pump is not scratched when cleaning. Avoid spraying water into the grilles or the sides so that water penetrates into JÄSPI Inverter Nordic. -
Page 14: Disturbances In Comfort
5 Disturbances in comfort In most cases, the indoor module/control module notes a malfunction (a malfunction can lead to disturbance in comfort) and indicates this with alarms and action instructions in the display. NOTE Work behind covers secured by screws may only be carried out by, or under the supervision of, a qualified installation engineer. -
Page 15: Item Register
Item register Basic actions, 14 Troubleshooting, 14 Ice build-up in the fan, grille and/or fan cone, 14 Control of JÄSPI Inverter Nordic, 10 Water below JÄSPI Inverter Nordic (larger amount), 14 Disruptions to comfort Basic actions, 14 Updating the software, 13 Disturbances in comfort, 14 Troubleshooting, 14 Water below JÄSPI Inverter Nordic (lar-... - Page 20 WS name: -Gemensamt WS version: a954 WS release date: 2022-02-10 09:35 Publish date: 2022-04-06 11:34 Kaukora Oy PL 21, Tuotekatu 11 212 01 Raisio +358 2 437 4600 E-mail: kaukora@kaukora.fi www.jaspi.fi 331844...
